Ameriwood HOME 8620335COM Manual de usuario

8620335COM

Fireplace/TVStand

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B348620335COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

5

ameriwoodhome.com

BoardIdentification

Notactualsize

This piece is

paperboard

construction.It is

not made from

wood, but is

required for the

assembly of your

unit.

LeftPanel

38620335010

RightPanel

38620335020

LeftPartition

38620335030

RightPartition

38620335040

Top

38620335050

Bottom

38620335060

Adjustableshelf

38620335070

TVRail

38620335080

VerticalRail

38620335090

HorizontalRail

38620335100

Kick

38620335110

BackPanel

K862033500

6

ameriwoodhome.com

BoardIdentification

Notactualsize

7

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x16)

#A22610

cambolt

(x16)

#A22620

camlock

(x12)

#A21670

wooddowel

(x4)

#A23030

confirmatscrew

(x2)

#A21960

hiddenfastener

(x4)

#A22910

connectorbolt

(x4)

#A22920

connector

(x4)

#A53510

anglebracket

(x15)

#A12120

7/16"round

headscrew

(x8)

#A80250

shelfsupport

(x36)

#A21110

nail

Note:Yourmodelmaycontain

extrahardware.

(x1)

#A53655

largebracket

(x1)

#A95020

18"fireplaceinsert

6789

10 11

(x1)

TVWarningLabel

#B64358

8

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x3)

#A22620

(x3)

#A22610

(x2)

#A21670

9

ameriwoodhome.com

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x3)

#A22610

(x2)

#A21670

(x3)

#A22620

10

ameriwoodhome.com

STEP3

(x4)

#A22910
