Ameriwood HOME 5276340COM Manual de usuario

5276340COM

Kitchen Cart

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B345276340COM

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Follow Ameriwood Home

Tube

You

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Helpful Hints

ameriwoodhome.com

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Tube

You

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Tube

You

ameriwoodhome.com

Board Identification

Not actual size

Tube

You

Left Panel

35276340010

Right Panel

35276340020

Partition

35276340030 Left Back Panel

35276340040

Right Front Panel

35276340050

Right Back Panel

35276340060 Center Back Panel

35276340070

Top

35276340080

Left Shelf (x5)

35276340100

Center Shelf

35276340120

Bottom

35276340090

Right Shelf (x2)

35276340110

Center Rail (x2)

35276340130 Right Rail (x2)

35276340140

Right Bottom Rail

35276340150 Door

35276340160

ameriwoodhome.com

Board Identification

Tube

You

ameriwoodhome.com

Part List

Actual Size

Tube

You

Not Actual Size

(x20)

#A22610

cam bolt

(x20)

#A22620

cam lock

(x20)

#A21660

wood dowel

(x2)

#A17400

7/8" bolt

(x20)

#A80250

shelf support

(x2)

#A65640

hinge

(x8)

#A12120

7/16" pan head

(x4)

#A53510

angle bracket

(x12)

#A13410

1-3/4" flat head

(x1)

#A51925

handle

(x4)

#A42590

caster

ameriwoodhome.com

STEP1

(x2)

#A22620

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP2

1211

(x2)

#A65640

(x2)

#A22620

(x4)

#A22610

Loosen to seperate

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP3

(x4)

#A22610

(x2)

#A22620

Proper orientation of CAM LOCK

Tip

Assembly

Quick
