Ameriwood HOME 3417335COM Manual de usuario

3417335COM

2DoorAccentCabinet

B343417335COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

33417335010

RightPanel

33417335020

Top

33417335030

Bottom

33417335040 AdjustableShelf

33417335050

TopRail

33417335060

LeftFrontLeg

33417335070

RightFrontLeg

33417335080 LeftRearLeg

33417335090

RightRearLeg

33417335100

Door(x2)

33417335110

BackPanel

K341733500

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butis

requiredfortheassemblyofyourunit.

BACK

PNL

6

ameriwoodhome.com

BoardIdentification

Notactualsize

BACK

PNL

7

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x8)

#A22700

camlock

(x8)

#A22710

cambolt

(x8)

#A21670

wooddowel

(x2)

#A22770

quicklock

(x12)

#A22795

lockingsleeve

(x12)

#A22790

lockingbolt

(x10)

#A12120

7/16"screw

(x12)

#A21110

nail

(x2)

#A11080

7/16"screw

(x2)

#A35200

strikeplate

8910

(x4)

#A17400

bolt

(x2)

#A89370

doorbumper

(x4)

#A80250

shelfsupport

12d

12a

12b

12c

(x1)

#A84050

safetybracket

(x4)

#A65640

hinge

(x2)

#A51715

handle

8

ameriwoodhome.com

STEP1

(x12)

9

ameriwoodhome.com

STEP2

(x12)

PleaseNote:Yourlockingpinmayhaveaphillipsdriveor

aTorxdrive.IfTorxdrive,youwillhaveaTorxdrivebit

includedinyourhardware.

10

ameriwoodhome.com

STEP3

Positionandinsertthelockingbolts(6)ofLeftFronLegG)intoedgeholesofleftpanel(A)asshown.

Besurebothpartsarepositionedasshown.Placethehammerblockontopoflegineachofthe3

lockingboltlocationsandgiveafirmstriketolocktogether.Thelockingbolt(6)willsnapintothe

lockingsleeve(5).

IMPORTANTNOTICE:Oncelockedtogether,partscannotbeseparated.

Note:Arubbermalletcanbeusedinplaceofahammerandhammerblock.
