AMD-8151™
HyperTransport™ AGP3.0
Graphics Tunnel Revision
Guide
25912Publication # 3.06Revision:
March 2006Issue Date:
© 2003–2006 Advanced Micro Devices, Inc. All rights reserved.
The contents of this document are provided in connection with Advanced Micro Devices,
Inc. (“AMD”) products. AMD makes no representations or warranties with respect to the
accuracy or completeness of the contents of this publication and reserves the right to make
changes to specifications and product descriptions at any time without notice. The informa-
tion contained herein may be of a preliminary or advance nature and is subject to change
without notice. No license, whether express, implied, arising by estoppel or otherwise, to
any intellectual property rights is granted by this publication. Except as set forth in AMD’s
Standard Terms and Conditions of Sale, AMD assumes no liability whatsoever, and dis-
claims any express or implied warranty, relating to its products including, but not limited
to, the implied warranty of merchantability, fitness for a particular purpose, or infringement
of any intellectual property right.
AMD’s products are not designed, intended, authorized or warranted for use as compo-
nents in systems intended for surgical implant into the body, or in other applications
intended to support or sustain life, or in any other application in which the failure of
AMD’s product could create a situation where personal injury, death, or severe property or
environmental damage may occur. AMD reserves the right to discontinue or make changes
to its products at any time without notice.
Trademarks
AMD, the AMD Arrow logo, and combinations thereof, and AMD-8151 are trademarks of Advanced Micro Devices, Inc.
PCI-X and PCI Express are registered trademarks of PCI-SIG.
HyperTransport is a licensed trademark of the HyperTransport Technology Consortium.
Other product names used in this publication are for identification purposes only and may be trademarks of their respective companies.
Revision History 3
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
25912 Rev. 3.06 March 2006
Revision History
Date Revision Description
March 2006 3.06 Added erratum #28.
August 2004 3.04 Added erratum #27.
June 2003 3.00 Initial public release.
4Revision History
25912 Rev. 3.06 March 2006
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
5
25912 Rev. 3.06 March 2006 AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
AMD-8151™
HyperTransport™ AGP3.0
Graphics Tunnel
Revision Guide
The purpose of the AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel Revision Guide is to
communicate updated product information on the AMD-8151™ HyperTransport™ AGP3.0 graphics
tunnel to designers of computer systems and software developers. This guide consists of three major
sections:
•Revision Determination: This section, which starts on page 6, describes the mechanism by
which the current revision of the part is identified.
•Product Errata: This section, which starts on page 7, provides a detailed description of product
errata, including potential effects on system operation and suggested workarounds. An erratum is
defined as a deviation from product specifications, and as such may cause the behavior of the
AMD-8151 HyperTransport AGP3.0 graphics tunnel to deviate from the published specifications.
•Documentation Support: This section, which starts on page 15, provides a listing of available
technical support resources.
Revision Guide Policy
Occasionally, AMD identifies product errata that cause the AMD-8151 HyperTransport AGP3.0
graphics tunnel to deviate from published specifications. Descriptions of identified product errata are
designed to assist system and software designers in using the AMD-8151 HyperTransport AGP3.0
graphics tunnel. Furthermore, this revision guide may be updated periodically.
6Revision Determination
25912 Rev. 3.06 March 2006
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
Revision Determination
The BIOS checks the PCI revision ID register at DevA:0x08 to determine the version of silicon as
shown in Table 1.
Table 1. AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel Revision IDs
Sequence Revision DevA:0x08
DevB:0x08
5B2 13h
Product Errata 7
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
25912 Rev. 3.06 March 2006
Product Errata
This section documents AMD-8151™ HyperTransport™ AGP3.0 graphics tunnel product errata. A
unique tracking number for each erratum has been assigned within this document for user
convenience in tracking the errata within specific revision levels. Table 2 cross-references the
revisions of the part to each erratum. An “X” indicates that the erratum applies to the revision. The
absence of an “X” indicates that the erratum does not apply to the revision.
Note: There may be missing errata numbers. Errata that have been resolved from early revisions of
the device have been deleted, and errata that have been reconsidered may have been deleted
or renumbered.
Table 2. Cross-Reference of Product Revision to Errata
Errata Numbers and Description
Revision Number
B2
22 Incorrect Value For DevA:0xA4[Host translation#] X
23 Link Electrical Issue When Operating At 800 MHz X
24 Deadlock Scenario With Peer-To-Peer Traffic X
25 Input Leakage Parameter Out Of Spec X
26 DevB:0x00[DevID] Is Read Only X
27 Failure When B-Side Link Is Directed Toward The Host X
28 The AMD-8151™ Tunnel Lacks Extended Configuration Space Memory-Mapped I/
O Base Address Register
X
8Product Errata
25912 Rev. 3.06 March 2006
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
22 Incorrect Value For DevA:0xA4[Host translation#]
Description
DevA:0xA4[Host translation#] is a read-only bit, fixed in the high state in the graphics tunnel. Per the
AGP specification, this indicates that core logic does not translate host transactions addressed to the
Graphics Aperature through the GART. However, on AMD platforms that use the graphics tunnel,
such host transactions can be translated through the GART.
Potential Effect on System
None.
Suggested Workaround
Software should presume that this bit is low for the graphics tunnel.
Fix Planned
Yes
Product Errata 9
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
25912 Rev. 3.06 March 2006
23 Link Electrical Issue When Operating At 800 MHz
Description
The graphics tunnel A-side link may not operate properly at 800 MHz.
Potential Effect on System
Transfer of erroneous data and system deadlocks are possible.
Suggested Workaround
The A-side link should be configured to operate at 600 MHz instead of 800 MHz.
Alternatively, more restrictive system board layout rules for the A-side link may be employed. See the
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel Motherboard Design Guide,
order# 25617 for details.
Fix Planned
No
10 Product Errata
25912 Rev. 3.06 March 2006
AMD-8151™ HyperTransport™ AGP3.0 Graphics Tunnel
Revision Guide
24 Deadlock Scenario With Peer-To-Peer Traffic
Description
Some PCI cards generate peer-to-peer posted-write traffic targeting the AGP bridge (from the PCI
bus, through the graphics tunnel, to the host, back to the graphics tunnel to the AGP bus). The
combination of such cards and some AGP cards can generate traffic patterns that result in a system
deadlock.
Potential Effect on System
The system deadlocks.
Suggested Workaround
Do not support PCI cards that generate peer-to-peer traffic to the AGP bridge.
Fix Planned
Yes
