CABINET PARTS
1
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel) (Stainless Steel)
05−08 Litho in U.S.A. (MAT) (eeb) Part No. W10205146 Rev. B
CABINET PARTS
2
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10175445
Owners Manual
W10183296
Energy Tag
W10165418
Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
67001131 Black
4 67005064 Label, Fill Tube
5 67006118 Roller Assembly
6 12627302 Clip, Grille
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Rear)
9 67006521 Screw
10 67001098 Cover, Fill Tube
11 67006380 Screw
12 67006473 Screw (8)
13 A3076901 Plug, Button
14 67006303 Screw (3)
15 Hinge, Center
67007043 Black
16 67003868 Foot Brake (2)
17 Cover, Corner
67003485 Black
18
12566604ED
Hinge, Top
19 12479901 Plate, Cover
20 67006564 Screw (8)
21 Cover, Hinge
67001012 Black
22 Grille Assembly
(Includes Clips)
67006886 Black
24 67006662 Screw
25 67006425 Screw (9)
26 67007174 Bracket, Foot
27 67001173 Cover, Water Valve
28 67006101 Cover, Unit
29 67003796 Insulation, Sound
30
W10164397
Tube, Drain
31
W10157973
Clip, Drain Tube
33 B5759649 Gasket
(Stainless Steel)
REFRIGERATOR LINER PARTS
3
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
(Stainless Steel)
REFRIGERATOR LINER PARTS
4
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2
Y67003896
Bracket, Control
and Lights
3 67004279 Overlay
4
W10185244
Housing,
Electronic Control
5
W10165748
Board, Control
6 C3680310 Switch, Light
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701
Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw (2)
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429
Control, Damper
16 12002355 Thermistor
17 M0310343 Plug Button
Following Parts Not Illustrated
67004033 Harness, Controls
(Refrigerator)
(Includes # 16)
(Stainless Steel)
FREEZER LINER PARTS
5
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
(Stainless Steel)
FREEZER LINER PARTS
6
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam (2)
3 12002497 Gear (2)
(Includes RH & LH)
4 67003905 Cover, Light
5 67004067 Shaft
6
Y12570701
Socket, Light
8 67006473 Screw (8)
9 A0282812 Bulb, Light
10 67001035 Housing, Frz. Light
11 67005871 Cover, Evaporator
12 67005822 Screw (7)
13 Bracket, Door
W10122147
Left
W10122148
Right
14 67003906 Housing, Lighting
15
W10167028
Clip, Evap. Motor
16 67005653 Switch, Light
18 Bracket, Basket
W10187668
Left
W10187667
Right
19
W10120018
Slide, Drawer (2)
20 67002286 Gasket, Bottom
21 Bracket, Slide
W10128118
Left
W10128119
Right
22
W10175909
Cover, Fan Shroud
23
W10167023
Shroud, Evap.Fan
24 2169142 Fan, Evaporator
25
W10121318
Grommet (2)
26 67003636 Motor, Evaporator
27 D7753903 Funnel, Drain
(Incl. # 28 & 29)
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
32 67006406 Screw (6)
33 67006530 Screw
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)
(Stainless Steel)
REFRIGERATOR DOOR PARTS
7
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
(Stainless Steel)
REFRIGERATOR DOOR PARTS
8
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(w/ Insulation)
Stainless Steel
W10203482
Left
W10182772
Right
2 Plug, Vent
67004838 Black
3 67003819 Door, Compartment
4 67001279 Tray, Dairy
5 67001021 Bucket (2)
(Medium)
6
Y12528501
Nameplate
7 Plug, Button (2)
67001131 Black
8 Gasket, Door
Magnetic
12683815B
Black
9 Handle, Door
W10159105
Stainless Steel
10 67002935 Screw
11 Closure, Door
67003639 Black
12 67004124 Bucket (1)
(Short)
13 Bushing
67004978 Black
14 67001296 Retainer, Door
15 67006287 Screw
16 10423131 Bin, Utility
17 Stop, Door
67003780 Black
18 67006113 Mount, Handle
19 67005626 Caddy, Can
20 67001141 Bucket (2)
(Small)
21 10436404 Lid, Utility
22 10436506 Tray, Egg
(Stainless Steel)
FREEZER DOOR PARTS
9
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
(Stainless Steel)
FREEZER DOOR PARTS
10
For Model: ABL1922FES12, ABR1922FES12
(Stainless Steel)
W10205146
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(w/ Insulation)
W10174587
Stainless Steel
2 Handle, Door
W10159105
Stainless Steel
3 67006113 Mount, Handle
4 Gasket, Door
W10153328
Black
5 67006682 Screw
6 Plug, Vent (2)
67004838 Black
(Stainless Steel)
