Allnet ALL8845PD Manual de usuario

ALL8845PD

5 Port PoE Gigabit Switch

Manual

- 1 -

FCC Warning

This device has been tested and found to comply with

limits for a Class B digital device, pursuant to Part 15

of FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when

the equipment is operated in a commercial environment.

This equipment generates and radiates radio frequency

energy and, if not installed and used in accordance with

the user’s manual, it may cause interference in which

case users will be required to correct interference at

their own expenses.

CEWarning

This is a Class B product. In a domestic environment,

this product may cause radio interference in which case

the user may be required to take adequate measures.

- 2 -

Introduction

ExtendingPoE power to another 100M.

This PoE switch provides 1-port 10/100/100M PD

input and 4-port 10/100/1000M PSE output with 48V

which is compliant with IEEE 802.3af/at standard. It

can extend the distance via Cat. 5/5e/6 cable without any

special equipment.

The PD port can be connected via Cat. 5/5e/6 cable to

other PSE/PoE and get the power source from other PSE

devices through Cat. 5/5e/6 cable. The PSE/PoE port can

be connected to other PD via Cat. 5/5e/6 cable and

extend a distance to another 100M through this device.

It is designed for easy installation and high performance

to an environment where the traffic is on the network

and the number of users is increased continuously.

- 3 -

Package Contents

Before you start to install this switch, please verify

your package that contains the followingitems:

PoE+ Gigabit Switch

User’s Manual

Optional:48V/ 1.45AExternal Adaptor

Note: Ifany ofthese items is missing or damaged, please contact your

local supplier for thereplacement.

Key Features

5 Port 10/100/1000M(Auto-negotiation) Switch

with 1-port PD and 4-port PSE.

1-port PD/PoE can get power source from an

upper PoE/PSE (IEEE 802.3at) device.

4-port PSE/PoE shares Max. 25 W or Max. 25W

for one port

Optional: 48V/1.45A 4-port PSE shares

Max. 70W or Max. 25 per port.

Palm size with metal case

Auto-learn of networking configurations

Auto-detect full/half-duplexmodes for anyport

Dedicated full-duplex2000Mbps bandwidth

Store-and-Forward switching methods

IEEE 802.3xflow control for full-duplexand

back-pressure flow control for half-duplex

Non-blocking & Non-head-of-line blocking full

wire speed forwarding

Auto-MDI/MDI-Xfunction for anyport

- 4 -

Front Panel (LEDs)

LED Indicators of 5 Port 10/100/1000M with 1-port

PD and 4-port PSE Switch

LED

Status

Description

Power

(Yellow)

Power is on.

Off

Power is off.

100M

LINK/ACT

(Green)

Connected on 100M

Off

Not connected on 100M

Flashing

Data is transmitting or

receiving

1000M

LINK/ACT

(Green)

Connected on 1000M

Off

Not connected on

1000M

Flashing

Data is transmitting or

receiving

PoEIN

(Yellow)

Port is connected to

PoE/PSE

Off

No PSEconnected.

PoEOUT

(Yellow)

Port is connected to

PoE/PD

Off

No Power Device is

connected

Loop

(Red)

Flashing

A loop is detected

Off

No loop is detected

- 5 -

Rear Panel (Power)

Port 5 PD

(Getting Power Source)

This PoE switch provides automatic crossover

detection functionality. It is simple and friendly to

up-link to another device without crossover cable.

Via a twisted pair cable straight through, this PoE switch can be

connected to PCs, servers and other PSE/PD devices.

Optional : Power is supplied by an external

48V/DC power adapter.

- 6 -

Technical Specifications

Standards

IEEE802.3af

IEEE802.3at

IEEE802.3 10BaseT

IEEE802.3u 100BaseTX

IEEE802.3ab 1000BaseT

IEEE802.3x Flow control

Features

Number of Ports: 5

10/100/1000BaseT(X) :

1-port PDand 4-port PSE

MACAddress: 2K

Buffer Memory: 1Mbits

Method: Store and

Forward

Filtering/

Forwarding

Rates

1000Mbps port –

1,488,000pps

100Mbps port –148,800pps

10Mbps –14,880pps

Transmission

Media

10/100/1000BaseTX Cat. 5

UTP/STPor above

LEDIndicators

Per Port:100M LINK/ACT,

1000MLINK/ACT, PoE

Per Unit: Power

Power Source

PD( Port 5 ) getting power

source from a connected

PoE/ PSE (IEEE 802.3at)

devices.

4-port shares Max. 25W

- 7 -

Power Input

Optional : DC48V / 1.45A

4-port shares Max. 70W

or Max. 25W per port

Power Output

48V/DCto PDdevices

Dimensions

130 × 97 × 24 mm

(L x W x H)

Weight

0.33 kg

Operating

Temperature

0 to 40℃

Storage

Temperature

-20 to 90°C

Humidity

10 to 90% RH (non-

condensing )

Certifications

FCCClass B, CE

- 8 -

EC - Declaration of Conformity

for the following equirement:

ALL8845PD

5 Port Poe Gigabit Switch

The safety advice in the document accompanying the

p products shall be obeyed. The conformity to the above

directive is indicated by the CE sign on the device .

The ALLNET ALL8845PD conforms to the Council Directives of EC EMC

2004/108/EC with CE marking requirement. This equipment meets the

the following conformance standards:

T his equipment is intended to be operated in all c ountries .

T his dec laration is made by

A L LN E T Deuts c hland G mbH

M ais tr. 2

8 2 1 1 0 Germering

Germering, 12.05.2012
