Allmatic AV4 Guía

AV4

CONTROL UNIT FOR MANUAL CONTROL UP TO 4 TUBULAR MOTORSCONTROL UNIT FOR MANUAL CONTROL UP TO 4 TUBULAR MOTORS

6-1621227 - rev. 2 - 12/12/2022

ENGLISH - Translated from the original language

INSTALLATION AND USE MANUAL

12/12/2022 - rev. 2 - 6-16212272- English - Translated from the original language

PRODUCT VIEW

Overall dimensions: 140.50 x 182.00 x 80.60 mm

Dimensions of the mounting holes: 114.00 x 156.00 mm

1. Connect the 230vac power supply as shown.

2. If an engine operates in the wrong direction reverse the appropriate Black and Brown cables.

ATTENTION

• Connect all ground wires of tubular motors together with the ground.

• The maximum current absorbed for each output is 4 A.

INSTALLATION

6-1621227 - rev. 2 - 12/12/2022 Translated from the original language - English - 3

WIRING FOR GROUP CONTROL

WIRING FOR INDIVIDUAL CONTROL

Individual Keyswitches: It allows the individual operation of the tubular motors through their corresponding selector.

ATTENTION

• Activate only one engine at a time.

Master Keyswitch: Allows all connected motors to operate simultaneously.

ATTENTION

• The maximum total load allowed for group control is 6.3 A.

ALLMATIC S.r.l

32026 Borgo Valbelluna - Belluno – Italy

Via dell’Artigiano, n°1 – Z.A.

Tel. 0437 751175 – 751163 r.a. Fax 0437 751065

www.allmatic.com - E-mail: [email protected]

WARRANTY

The manufacturer’s warranty is valid from the date stamped on the product and is limited to the repair or replacement free of

charge of the parts recognized by the same as defective due to lack of essential quality in the materials or lack of processing.

The warranty does not cover damage or defects due to external agents, maintenance deﬁciency, overload, natural wear, choice

of incorrect type, assembly error, or other causes not attributable to the manufacturer. Tampered products will not be guaran-

teed or repaired. The data given are purely indicative. No liability may be charged for reductions in scope or malfunctions due to

environmental interference. The liability of the manufacturer for damage caused to anyone by accidents of any nature caused by

our defective products, are only those that derive from the Italian law.

PRODUCT DISPOSAL

This product is an integral part of automation, and therefore must be disposed of together with it. As with installation operations,

even at the end of the life of this product, dismantling operations must be carried out by qualiﬁed personnel. This product consists

of various types of materials: some can be recycled, others must be disposed of. Find out about the recycling or disposal systems

required by the regulations in force in your territory for this category of product.

WARNING

• Certain parts of the product may contain pollutants or dangerous substances which, if dispersed in the

environment, could have harmful eects on the environment and human health.

As indicated by the symbol on the side, it is forbidden to throw this product into household waste. Then

perform the “separate collection” for disposal, according to the methods provided by the regulations in

force in your territory, or return the product to the seller when buying a new equivalent product.

• The regulations in force at local level may provide for heavy penalties in case of improper disposal of this

product.
