The Allied Telesis GS950 PS Series of WebSmart network switches

features PoE+ for connectivity with security cameras, VoIP phones, RFID

readers and wireless access points. A cost-effective solution for SMB,

retail stores and at the edge of the network.

Ease of Management and High

Performance

These advanced Allied Telesis WebSmart

switches integrate the simplicity

of unmanaged switches with the

performance and reliability of managed

switches to provide an inexpensive yet

secure and reliable solution for users

to integrate management at the edge

of their networks. With a user-friendly

web-based management, the GS950

Series is an ideal option for integrating

simple management and security into a

network solution.

Power over Ethernet

The GS950 PS Series is available in

congurations of 10, 16 and 48 ports

PoE. All the three switches support

PoE+ (IEEE 802.3at), with ports capable

of delivering up to 30W per port.

Power over Ethernet allows users to

network and power a device, using a

single Ethernet cable, thus eliminating

the need for additional power outlets

and simplifying the network installation.

Also, it is unaffected by any local

variance in AC power, offering a

standardized power infrastructure.

PoE+, with up to double the power of

regular PoE, provides superior power-

management capability, as automatic

power allocation can be made on the

exact requirement of the power device

at any given time.

VLAN

» IEEE 802.1Q tagged

» Port-based

» Up to 256 groups

Quality of Service Classification

» IEEE 802.1p tagging

» Port-based priority

» Four priority queues per port

IP Multicast Support (IPv4)

» IGMP snooping (v1/v2)

» Static multicast group (up to 256)

» Spanning-Tree, IEEE 802.1d/w/s

IEEE 802.3ad Link Aggregation

IEEE 802.1x Port-based and MAC-based

Network Access Control

» Local authentication server (MD5 only)

» Remote authentication through RADIUS

» Dynamic VLAN assignment

RADIUS Client

DHCP Client

DHCP Snooping

Statistics Charts in Web

Jumbo Frames - up to 10K

Others

» IEEE 802.3x ﬂow control or HOL (†) blocking

prevention († when ﬂow control is off)

» Port mirroring

» Destination MAC ﬁltering

» Ingress/egress rate limiting

» Broadcast storming control

» 100FX SFP support

Key Features

Management Features

» Web-based conﬁguration

» Discovery support

» SNMP trap view

» LLDP

» Firmware upgrade by FTP and HTTP

» Conﬁguration backup/restore by FTP and HTTP

» Factory reset

» Password access control and restricted IP access

list

» SNMPv1/v2c/v3

» Management IP: DHCP client for Web

» Management and static IP setting

» Syslog support

» System time conﬁguration (SNTP, manual)

MIBs

» RFC 1213 MIB-II

» RFC 1643 Ethernet MIB

» RFC 1493 Bridge MIB

» RFC 2131 DHCP client

» Private Enterprise MIB (Allied Telesis provides the

spec)

RMON Groups (1, 2, 3, 9)

» Stats

» History

» Alarms

» Events

ACL

» 240 entries (shared)

alliedtelesis.com

GS950 PS Series

GIGABIT WEBSMART POE+ EDGE SWITCHES

GS950 PS Series | Gigabit WebSmart PoE+ Edge Switches

PRODUCT WIDTH DEPTH HEIGHT WEIGHT MTBF (HOURS)

AT-GS950/10PS 330 mm (13 in) 200 mm (7.9 in) 44 mm (1.7 in) 1.9 Kg (4.20 lbs) >250,000

AT-GS950/16PS 430 mm (17 in) 250 mm (9.8 in) 44 mm (1.7 in) 3.56 Kg (7.85 lbs) >250,000

AT-GS950/48PS 440 mm (17.32 in) 430 mm (17 in) 44 mm (1.7 in) 6.62 Kg (14.60 lbs) >250,000

PRODUCT MAX POWER

CONSUMPTION

MAX HEAT

DISSIPATION NOISE VOLTAGE FREQUENCY

AT-GS950/10PS 13.58W 316.107 (BUT/hr) Fanless 100-240V AC 50-60Hz

AT-GS950/16PS 21.8W 779.185 (BUT/hr) Low-speed 33 dB

High-speed 47.1 dB 100-240V AC 50-60Hz

AT-GS950/48PS 55.5W 1520.86 (BUT/hr) Low-speed 38.3 dB

High-speed 51.6 dB 100-240V AC 50-60Hz

POWER SUPPLY UNIT POE POWER AVAILABLE

MAXIMUM POE PORTS SUPPORTED

IEEE 802.3af CLASS 2 IEEE 802.3af CLASS 3 IEEE 802.3at CLASS 4

AT-GS950/10PS 75W 8 4 2

AT-GS950/16PS 185W 16 12 6

AT-GS950/48PS 370W 24 24 12

PRODUCT SWITCHING CAPACITY FORWARDING RATE

AT-GS950/10PS 20Gbps 14.88Mpps

AT-GS950/16PS 32Gbps 23.80Mpps

AT-GS950/48PS 96Gbps 71.42Mpps

Specifications

Performance

14,880pps for 10Mbps Ethernet

148,800pps for 100Mbps Ethernet

1,488,000pps for 1000Mbps Ethernet

MAC addresses 8,000

VLAN ID’s available 4,000

Max VLANs 256

Packet buffer 1MB

DRAM 64MB

Flash 16MB

Interface Connections

10/100/1000T RJ-45

SFP 100TX, 100FX, 1000T,

1000SX or 1000LX

Environmental Compliance

RoHS

Eu-RoHS

China RoHS

WEEE

MTBF

263,000 hours

Telcordia SR-332

Environmental Specifications

Operating temperature: 0ºC to 40ºC (32ºF to 104ºF)

Non-operating temperature: -25ºC to 70ºC

(-13ºF to 158ºF)

Operating humidity: 5% to 90% non-condensing

Storage humidity: 5% to 95% non-condensing

Vibration: IEC 68-2-36

Shock: IEC 68-2-29

Drop: IEC 68-2-32

Flammability: UL94V-0

Technical Specifications

Wall-mount or desktop

All units come with wall /19” rack-mount brackets

Standards and Compliance

IEEE 802.3 CSMA/CD IEEE 802.3i 10T

IEEE 802.3u 100TX

IEEE 802.3z 1000SX/LX

IEEE 802.3z/ab 1000T

IEEE 802.3x Flow control

IEEE 802.1p Prioritization (four queues)

IEEE 802.1x Authentication

IEEE 802.1x Local authentication server

(MD5)

IEEE 802.1x Remote authentication

through RADIUS

IEEE 802.1x Dynamic VLAN assignment

IEEE 802.1x MAC-based authentication

IEEE 802.1x RADIUS

IEEE 802.1d Bridging

IEEE 802.3ad Link aggregation

IEEE 802.3ad Port trunking and LACP

IEEE 802.1Q Tagged VLAN

IEEE 802.1d Spanning-Tree

IEEE 802.1w Rapid Spanning-

Tree

IEEE 802.1s Multiple Spanning-Tree

Electrical/Mechanical Approvals

UL60950-1 2nd edition (UL)

FCC/EN55022/CISPR 22 Class A

VCCI Class A

C-Tick

EN60950 (TUV)

EN55024

CE Mark

CSA / cUL

Physical Specifications and MTBF Figures

Power and Noise Characteristics

Power over Ethernet Port Support

Product Contents

Switch unit

Rack-mount brackets and screws

Power cord

Rubber feet

alliedtelesis.com

GS950 PS Series | Gigabit WebSmart PoE+ Edge Switches

Fast Ethernet Switches

AT-GS950/10PS -x x

10-port 10/100/1000T WebSmart switch with 2 SFP

combo ports and PoE+

AT-GS950/16PS -x x

16-port 10/100/1000T WebSmart switch with 2 SFP

combo ports and PoE+

AT- GS950/48PS -xx

48-port 10/100/1000T WebSmart switch with 4 SFP

combo ports and PoE+

Where xx =

10 for US power cord

20 for no power cord

30 for UK power cord

40 for Australian power cord

50 for European power cord

Small Form Pluggable Optics Modules

AT-SPSX

SFP, MMF, 1000Mbps, 220/500 m, 850 nm, LC

AT-SPL X10

SFP, SMF, 1000Mbps, 10 km, 1310 nm, LC

AT-SPFX/2

SFP, MMF, 100Mbps, 2 km, 1310 nm, LC

AT-SPFX/15

SFP, SMF, 100Mbps, 15 km, 1310 nm, LC

AT-SPBD10 -13

SFP, SMF, 1000Mbps, 10 km, 1310/1490 nm,

LC-BiDi

AT-SPBD10-14

SFP, SMF, 1000Mbps, 10 km, 1490/1310 nm,

LC-BiDi

Ordering Information

GS950 PS Series

617-000478 Rev.A

alliedtelesis.com

© 2013 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.

North America Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacic Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830
