Alliance Laundry Systems 802733R4 Guía

Installation/Operation

www.comlaundry.com

Frontload Washers

Metered Commercial

FLW1525C

Part No. 802733R4

October 2011

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

Para bajar una copia de estas instrucciones

en español, visite www.comlaundry.com.

802733 1

NOTE: The WARNING and IMPORTANT instructions appearing in this manual are not meant to cover all

possible conditions and situations that may occur. It must be understood that common sense, caution, and

carefulness are factors which cannot be built into these washers. These factors MUST BE supplied by the

person(s) installing, maintaining, or operating the washer.

Always contact the distributor, service agent, or the manufacturer about any problems or conditions you do not

understand.

Failure to install, maintain, and/or operate this machine according to the manufacturer's

instructions may result in conditions which can produce bodily injury and/or property

damage.

W030

WARNING

means without the expressed written consent of the publisher.

802733

2© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Table of

Contents

Safety Information.............................................................................. 4

Explanation of Safety Messages........................................................... 4

Important Safety Instructions ............................................................... 4

Installation........................................................................................... 6

Dimensions and Specifications............................................................. 6

Before You Start ................................................................................... 7

Tools ................................................................................................ 7

Installing the Washer ............................................................................ 8

Step 1: Position Washer Near Installation Area .............................. 8

Step 2: Position and Level the Washer ............................................ 8

Step 3: Connect Fill Hoses............................................................... 9

Step 4: (Non-Gravity Drain Models Only)

Connect Drain Hose to Drain Receptacle....................................... 11

Step 5: (Gravity Drain Models Only)

Connect Drain Outlet to Drain System........................................... 12

Step 6: Remove the Shock Sleeves and Shipping Brace ................. 13

Step 7: Wipe Out Inside of Wash Drum .......................................... 13

Step 8: (Supply Injection Models Only)

Connect External Supplies to Washer ............................................ 13

Control Function Test ...................................................................... 14

Step 9: Plug In the Washer............................................................... 15

Step 10: Check Installation .............................................................. 16

Operation............................................................................................. 17

Operation Instructions for MDC Washers............................................ 17

Step 1: Load Laundry....................................................................... 17

Step 2: Close Loading Door............................................................. 17

Step 3: Add Laundry Supplies ......................................................... 18

Step 4: Set Fabric Selector and Wash Temperature......................... 18

Step 5: Insert Coin(s) or Card .......................................................... 19

Step 6: Start Washer......................................................................... 19

Indicator Lights................................................................................ 20

Operation Instructions for NetMaster Washers .................................... 21

Step 1: Load Laundry....................................................................... 21

Step 2: Close Loading Door............................................................. 21

Step 3: Add Laundry Supplies ......................................................... 22

Step 4: Set Fabric Selector............................................................... 22

Step 5: Set Wash Temperature......................................................... 22

Step 6: Insert Coin(s) or Card .......................................................... 23

Step 7: Start Washer......................................................................... 23

Indicator Lights................................................................................ 23

Maintenance ........................................................................................ 25

User-Maintenance Instructions............................................................. 25

Lubrication....................................................................................... 25

Cold Weather Care........................................................................... 25

Care of Your Washer ....................................................................... 25

Cleaning Glass Sealing Area ........................................................... 25

Replacing Hoses............................................................................... 25

802733 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Filter Screens ................................................................................... 25

Vacations and Extended Non-Use ................................................... 25

Reinstallation of Shipping Materials ............................................... 26

Cleaning Foreign Object Trap ......................................................... 26

Troubleshooting .................................................................................. 27

Contact Information........................................................................... 29

Installer Checklist................................................................ Back Cover

4802733

Safety Information

Explanation of Safety Messages

Throughout this manual and on machine decals, you

will find precautionary statements (“DANGER,”

“WARNING,” and “CAUTION”) followed by specific

instructions. These precautions are intended for the

personal safety of the operator, user, servicer, and

those maintaining the machine.

Additional precautionary statements (“IMPORTANT”

and “NOTE”) are followed by specific instructions.

IMPORTANTE: The word “IMPORTANT” is used

to inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTA: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

Important Safety Instructions

(Save These Instructions)

1. Read all instructions before using the washer.

2. Install the washer according to the

INSTALLATION INSTRUCTIONS. Refer to the

GROUNDING INSTRUCTIONS in the

INSTALLATION manual for the proper

grounding of the washer. All connections for

water, drain, electrical power and grounding must

comply with local codes and be made by licensed

personnel when required. Do not do it yourself

unless you know how!

3. Do not install or store the washer where it will be

exposed to water and/or weather.

4. Do not add the following substances or textiles

containing traces of the following substances to

the wash water: gasoline, kerosene, waxes,

cooking oils, vegetable oils, machine oils, dry-

cleaning solvents, flammable chemicals, thinners

or other flammable or explosive substances.

These substances give off vapors that could

ignite, explode or cause the fabric to catch on fire

by itself.

5. Under certain conditions, hydrogen gas may be

produced in a hot water system that has not been

used for two weeks or more. HYDROGEN GAS

IS EXPLOSIVE. If the hot water system has not

been ug23sed for such a period, before using a

washing machine or combination washer-dryer,

turn on all hot water faucets and let the water

flow from each for several minutes. This will

release any accumulated hydrogen gas. THE

GAS IS FLAMMABLE, DO NOT SMOKE OR

USE AN OPEN FLAME DURING THIS TIME.

6. To reduce the risk of an electric shock or fire, DO

NOT use an extension cord or an adapter to

connect the washer to the electrical power

source.

Indicates an imminently hazardous

situation that, if not avoided, will cause

severe personal injury or death.

DANGER

Indicates a hazardous situation that, if not

avoided, could cause severe personal

injury or death.

WARNING

Indicates a hazardous situation that, if not

avoided, may cause minor or moderate

personal injury or property damage.

CAUTION

To reduce the risk of fire, electric shock,

serious injury or death to persons when

using your washer, follow these basic

precautions:

W023

WARNING

Safety Information

802733 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

7. Do not allow children to play on or in the washer.

Close supervision of children is necessary when

the washer is used near children. This appliance

is not intended for use by persons (including

children) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning the use of

the appliance by a person responsible for their

safety. This is a safety rule for all appliances.

8. Do not reach into the washer if the washtub is

moving.

9. Never operate the washer with any guards, panels

and/or parts removed or broken. DO NOT tamper

with the controls or bypass any safety devices.

10. DO NOT operate individual units if they have

been separated from a stack unit.

11. Use your washer only for its intended purpose,

washing clothes. Always follow the fabric care

instructions supplied by the garment

manufacturer.

12. Always read and follow manufacturer’s

instructions on packages of laundry and cleaning

aids. To reduce the risk of poisoning or chemical

burns, keep them out of the reach of children at

all times (preferably in a locked cabinet). Heed

all warnings or precautions.

13. Do not use fabric softeners or products to

eliminate static unless recommended by the

manufacturer of the fabric softener or product.

14. Loading door MUST BE CLOSED any time the

washer is to fill, tumble or spin. DO NOT bypass

the loading door switch by permitting the washer

to operate with the loading door open.

15. Be sure water connections have a shut-off valve

and that fill hose connections are tight. CLOSE

the shut-off valves at the end of each wash day.

16. Keep your washer in good condition. Bumping or

dropping the washer can damage safety features.

If this occurs, have your washer checked by a

qualified service person.

17. Do not repair or replace any part of the washer, or

attempt any servicing unless specifically

recommended in the user-maintenance

instructions or in published user-repair

instructions that you understand and have the

skills to carry out. ALWAYS disconnect the

washer from electrical supply before attempting

any service.

18. Disconnect the power cord by grasping the plug,

not the cord. If the supply cord is damaged, it

must be replaced by a special cord or assembly

available from the manufacturer or its service

agent.

19. Before the washer is removed from service or

discarded, remove the door to the washing

compartment.

20. Failure to install, maintain, and/or operate this

washer according to the manufacturer’s

instructions may result in conditions which can

produce bodily injury and/or property damage.

NOTA: The WARNING and IMPORTANT

SAFETY INSTRUCTIONS appearing in this

manual are not meant to cover all possible

conditions and situations that may occur. Common

sense, caution and care must be exercised when

installing, maintaining, or operating the washer.

Always contact your dealer, distributor, service agent

or the manufacturer about any problems or conditions

you do not understand.

6802733

Installation

Dimensions and Specifications

FLW2199N

2 in.

(5.1 cm)

43 in. (109.2 cm)

29.6 in. (75.1 cm)

28 in. (71.1 cm)

24 in.

(61.0 cm)

26.875 in. (68.3 cm)

31.1 in. (79 cm)

2 in.

(5.1 cm)

36.94 in. (93.83 cm)

14.6 in.

(37.08 cm)

13.1 in.

(33.3 cm)

MODELS EQUIPPED WITH DRAIN HOSE

1.5 in.

(3.8 cm)

FLW2200N

11.5 in. (3.81 cm) Inside Diameter

1.86 in. (4.72 cm) Outside Diameter

FLW2200N

2 in.

(5.1 cm)

43 in. (109.2 cm)

29.6 in. (75.1 cm)

28 in. (71.1 cm)

24 in.

(61.0 cm)

26.875 in. (68.3 cm)

31.1 in. (79 cm)

4.1 in.

(10.41 cm)

36.94 in. (93.83 cm)

14.6 in.

(37.08 cm)

13.1 in.

(33.3 cm)

MODELS WITH GRAVITY DRAIN

4.2 in.

(10.67 cm) 1

1.5 in.

(3.8 cm)

Installation

802733 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Before You Start

Tools

For most installations, the basic tools you will need

are:

Figure 1

NOTA: An 8 in. (20.32 cm) coin drawer is required

for coin operated models.

NOTA: If the washer is delivered on a cold day

(below freezing), or is stored in an unheated room

or area during the cold months, do not attempt to

operate it until the washer has had a chance to

warm up.

NOTA: Install dryer before washer. This allows

room for attaching exhaust duct.

NOTA: Some moisture in the wash drum is normal.

Water is used during testing at the manufacturer.

D074I

1Wrench

2Screwdriver

3Pliers

4Socket Wrench

5Level

123

Installation

802733

8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Installing the Washer

Step 1: Position Washer Near Installation

Area

Move washer so that it is within 4 feet (1.2 meters) of

the desired area of installation.

NOTA: For best performance and to minimize

vibration or movement, install washer on a solid,

sturdy and level floor. Some floors may need to be

reinforced, especially on a second floor or over a

basement. Do not install the washer on carpeting,

soft tile, a platform or other weakly supported

structures.

Figure 2

Step 2: Position and Level the Washer

Position washer so it has sufficient clearance for

installation and servicing.

NOTA: Use of the dispenser drawer or washer door

as a handle in the transportation of the washer may

cause damage to the dispenser or door.

Place washer in position on a solid, sturdy and level

floor. Installing the washer on any type of carpeting,

soft tile, a platform or other weakly supported

structures is not recommended.

Place a level on the cabinet top and check if the

washer is level from side to side and front to back.

NOTA: Level must rest on raised portion of top

panel. Refer to Figure 3.

If washer is not level, tilt washer to access the front

and rear leveling legs. For easier access to leveling

legs, prop up washer with a wooden block. Refer to

Figure 3. Loosen 7/8 in. locknut and adjust legs until

the washer is level from side to side and front to back

(using a level). Washer should not rock.

Tighten the locknuts securely against the washer

base using the 7/8 in. wrench. If the locknuts are not

tight, washer will move out of position during

operation.

H054I

Washers elevated above floor level must

be anchored to that elevated surface,

base or platform. The material used to

elevate the washer should also be

anchored to the floor to ensure that the

washer will not walk or that the washer

can not be physically pulled, tipped or

slid from its installed position. Failure to

do so may result in conditions which can

produce serious injury, death and/or

property damage.

W306

WARNING

Tabla de contenidos

Otros manuales de Arandela de Alliance Laundry Systems

Alliance Laundry Systems

Alliance Laundry Systems WF065B Guía de mantenimiento y servicio

Alliance Laundry Systems

Alliance Laundry Systems BA4121 Instrucciones de montaje

Alliance Laundry Systems

Alliance Laundry Systems TLW22C_SVG Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 802715 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems UW35PV Series Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems HC18 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems StGeorge Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems NetMaster HWTB21 Manual del propietario

Alliance Laundry Systems

Alliance Laundry Systems TR7104WN Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems DCG020ND Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems FLW1526C Instrucciones de funcionamiento originales

Alliance Laundry Systems

Alliance Laundry Systems WB2 350B Series Guía de mantenimiento y servicio

Alliance Laundry Systems

Alliance Laundry Systems ATE50FWP431AW01 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems UW35P2 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems F232145R7EN Manual del propietario

Alliance Laundry Systems

Alliance Laundry Systems BWNBC2PP112TW01 Manual del propietario

Alliance Laundry Systems

Alliance Laundry Systems TC5102WN Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems AFNE9BSP303XW01 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems LWN432SP113TW04 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems UX55PVXF6 Manual del propietario

Alliance Laundry Systems

Alliance Laundry Systems UW35TV Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems HC18MC2 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems UW POCKET HARDMOUNT UW35B2 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems HWNLX2SP111CW01 Instrucciones de funcionamiento

Manuales populares de Arandela de otras marcas

Tricity Bendix

Tricity Bendix AW 1000 W Guía del producto

Panasonic

Panasonic NA-F60L5WRB Manual de usuario

GE WSLP1500 Manual

Electrolux

Electrolux EWF1284EDW Manual de usuario

Bosch

Bosch WAN2829BSN Manual de usuario

LG TV2516DV3B Manual de usuario

LG TH2517DSAV Manual de usuario

VESTEL

VESTEL CMH-XL 7510 TE Manual de usuario

AEG

AEG 74335 Manual de operación

Johnson

Johnson JWF721A Manual de usuario

Beko

Beko WTE7604XLW0 Manual de usuario

Danby

Danby DTT100A1WDB Instrucciones de montaje

Amica

Amica WA 14 Ex Manual de usuario

Daewoo

Daewoo DWD-F1222 Manual de usuario

Bosch

Bosch WAS28461AU Manual de usuario

Miele

Miele PW 6080 Vario Manual de usuario

Finlux

Finlux FLX108CF220 Manual de usuario

Whirlpool

Whirlpool 3LBR5132AN0 Manual de usuario
