Installation/Operation

www.comlaundry.com

Clothes Dryer

Nonmetered and Metered

Electric and Gas Models

D677I

Part No. 512680R7

September 2011

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

IMPORTANT: Purchaser must consult the local gas supplier for suggested instructions to be followed if the

unit user smells gas. The gas utility instructions plus the SAFETY and WARNING note directly above must

be posted in a prominent location near the unit for customer use.

The following information applies to the state of Massachusetts, USA.

•This appliance can only be installed by a Massachusetts licensed plumber or gas fitter.

•This appliance must be installed with a 36 inch (91 cm) long flexible gas connector.

•A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance.

•This appliance must not be installed in a bedroom or bathroom.

• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this

or any other appliance.

• WHAT TO DO IF YOU SMELL GAS:

– Do not try to light any appliance.

– Do not touch any electrical switch; do not use any phone in your building.

– Clear the room, building or area of all occupants.

– Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s

instructions.

– If you cannot reach your gas supplier, call the fire department.

• Installation and service must be performed by a qualified installer, service agency or the

gas supplier.

W052

FOR YOUR SAFETY, the information in this manual must be followed to minimize the risk

of fire or explosion or to prevent property damage, personal injury or death.

W033

WARNING

• Installation of unit must be performed by a qualified installer.

• Install clothes dryer according to manufacturer’s instructions and local codes.

• DO NOT install a clothes dryer with flexible plastic venting materials. If flexible metal (foil

type) duct is installed, it must be of a specific type identified by the appliance manufacturer

as suitable for use with clothes dryers. Refer to section on connecting exhaust system.

Flexible venting materials are known to collapse, be easily crushed, and trap lint. These

conditions will obstruct clothes dryer airflow and increase the risk of fire.

W729R1

WARNING

FOR YOUR SAFETY

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or

any other appliance.

W053

means without the expressed written consent of the publisher.

512680

Table of

Contents

Safety Information.............................................................................. 4

Explanation of Safety Messages........................................................... 4

Important Safety Instructions ............................................................... 4

Installation........................................................................................... 6

Dimensions ........................................................................................... 6

Nonmetered Models......................................................................... 6

Metered Models ............................................................................... 7

Before You Start ................................................................................... 8

Tools ................................................................................................ 8

Card Reader Models ........................................................................ 8

Installing the Dryer ............................................................................... 9

Step 1: Position and Level the Dryer ............................................... 9

Step 2: Connect Dryer Exhaust System ........................................... 11

Exhaust Direction............................................................................. 12

Exhaust System................................................................................ 13

Multi-Dryer Installation Exhaust Requirements.............................. 14

Step 3: (Gas Dryer Only) Connect Gas Supply Pipe ....................... 16

Step 4: (Electric Dryer Only) Connect Electrical Plug.................... 17

Step 5: Reverse Door, if Desired ..................................................... 23

Step 6: Wipe Out Inside of Dryer .................................................... 24

Step 7: Plug In the Dryer ................................................................. 24

Step 8: Recheck Steps 1-7................................................................ 26

Step 9: Check Heat Source .............................................................. 26

Vending................................................................................................ 27

Meter Case............................................................................................ 27

Coin Slide Control ................................................................................ 27

Power-Up Mode............................................................................... 27

Ready Mode ..................................................................................... 27

Start Mode........................................................................................ 27

Run Mode......................................................................................... 27

Door Open Mode ............................................................................. 27

End of Cycle Mode .......................................................................... 27

Topoffs............................................................................................. 27

Temperature Selector Switch........................................................... 27

Error Display Mode ......................................................................... 28

Setting Dry Time Dipswitches.............................................................. 28

Models Through Serial No. 0908..................................................... 28

Models Starting Serial No. 0909...................................................... 28

All Models ....................................................................................... 28

Models Starting Serial No. 0909...................................................... 28

Dipswitch Settings................................................................................ 29

Models Through Serial No. 0908..................................................... 30

Models Starting Serial No. 0909...................................................... 31

Test Setting ...................................................................................... 31

Slide Extension ..................................................................................... 32

Additional Dryer Security..................................................................... 34

Operation............................................................................................. 35

512680

Operation Instructions for Nonmetered and Coin Slide Dryers ........... 35

Step 1: Clean Lint Filter................................................................... 35

Step 2: Load Laundry....................................................................... 35

Step 3: Close Loading Door............................................................. 35

Step 4: Set Fabric Selector............................................................... 36

Step 5: Start Dryer ........................................................................... 36

Operation Instructions for Electronic Display Control Dryers............. 37

Step 1: Clean Lint Filter................................................................... 37

Step 2: Load Laundry....................................................................... 37

Step 3: Close Loading Door............................................................. 37

Step 4: Set Fabric Selector............................................................... 38

Step 5: Insert Coin(s) or Card .......................................................... 38

Step 6: Start Dryer ........................................................................... 39

Indicator Lights................................................................................ 39

Operation Instructions for MDC Dryers............................................... 40

Step 1: Clean Lint Filter................................................................... 40

Step 2: Load Laundry....................................................................... 40

Step 3: Close Loading Door............................................................. 40

Step 4: Set Fabric Selector............................................................... 41

Step 5: Insert Coin(s) or Card .......................................................... 41

Step 6: Start Dryer ........................................................................... 41

Indicator Lights................................................................................ 41

Operation Instructions for NetMaster Dryers....................................... 42

Step 1: Clean Lint Filter................................................................... 42

Step 2: Load Laundry....................................................................... 42

Step 3: Close Loading Door............................................................. 42

Step 4: Set Fabric Selector............................................................... 43

Step 5: Insert Coin(s) or Card .......................................................... 43

Step 6: Start Dryer ........................................................................... 44

Indicator Lights................................................................................ 44

Maintenance ........................................................................................ 45

Lubrication............................................................................................ 45

Care of Your Dryer............................................................................... 45

Dryer Interior ................................................................................... 45

Cabinet ............................................................................................. 45

Control Panel ................................................................................... 45

Exhaust System................................................................................ 45

Lint Filter .............................................................................................. 46

Motor Overload Protector..................................................................... 46

For Energy Conservation...................................................................... 46

Troubleshooting .................................................................................. 47

Contact Information........................................................................... 48

Installer Checklist ............................................................... Back Cover

512680

Safety Information

Explanation of Safety Messages

Throughout this manual and on machine decals, you

will find precautionary statements (“DANGER,”

“WARNING,” and “CAUTION”) followed by specific

instructions. These precautions are intended for the

personal safety of the operator, user, servicer, and

those maintaining the machine.

Additional precautionary statements (“IMPORTANT”

and “NOTE”) are followed by specific instructions.

IMPORTANT: The word “IMPORTANT” is used

to inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTE: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

Important Safety Instructions

Save These Instructions

1. Read all instructions before using the dryer.

2. Install this dryer according to the

INSTALLATION INSTRUCTIONS. Refer to the

GROUNDING INSTRUCTIONS in the

INSTALLATION manual for the proper

grounding of the dryer. All connections for

electrical power, grounding and gas supply must

comply with local codes and be made by licensed

personnel when required. Do not do it yourself

unless you know how!

3. Do not install or store the dryer where it will be

exposed to water and/or weather.

4. Do not dry articles that have been previously

cleaned in, washed in, soaked in, or spotted with

gasoline or machine oils, vegetable or cooking

oils, cleaning waxes or chemicals, dry-cleaning

solvents, thinner or other flammable or explosive

substances as they give off vapors that could

ignite, explode or cause fabric to catch on fire by

itself.

5. Items that have been soiled with substances such

as cooking oil, acetone, alcohol, petrol, kerosene,

spot removers, turpentine, waxes and wax

removers, should be washed in hot water with an

extra amount of detergent before being dried in

the tumble dryer.

6. To reduce the risk of fire, DO NOT DRY plastics

or articles containing foam or latex rubber or

similarly textured rubberlike materials, such as

shower caps, water proof textiles, rubber-backed

articles, and clothes or pillows filled with foam

rubber pads.

7. Do not tumble fiberglass curtains and draperies

unless the label says it can be done. If they are

dried, wipe out the cylinder with a damp cloth to

remove particles of fiberglass.

Indicates an imminently hazardous

situation that, if not avoided, will cause

severe personal injury or death.

DANGER

Indicates a hazardous situation that, if not

avoided, could cause severe personal

injury or death.

WARNING

Indicates a hazardous situation that, if not

avoided, may cause minor or moderate

personal injury or property damage.

CAUTION

To reduce the risk of fire, electric shock,

or injury to persons when using your

dryer, follow these basic precautions:

W034

WARNING

Safety Information

512680

8. Do not allow children to play on or in the dryer.

Close supervision of children is necessary when

the dryer is used near children. This appliance is

not intended for use by persons (including

children) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning the use of

the appliance by a person responsible for their

safety. This is a safety rule for all appliances.

9. Do not reach into the dryer if the cylinder is

revolving.

10. Use the dryer only for its intended purpose,

drying clothes. ALWAYS follow the fabric care

instructions supplied by the garment

manufacturer and only use the dryer drum to dry

textiles that have been washed in water.

11. Always read and follow manufacturer’s

instructions on packages of laundry and cleaning

aids. Heed all warnings or precautions. To reduce

the risk of poisoning or chemical burns, keep

them out of reach of children at all times

(preferably in a locked cabinet).

12. Remove laundry immediately after the dryer

stops.

13. DO NOT operate the dryer if it is smoking,

grinding or has missing or broken parts or

removed guards and/or panels. DO NOT tamper

with the controls or bypass any safety devices.

14. DO NOT operate individual units if they have

been separated from a stack unit.

15. Dryer will not operate with the loading door

open. DO NOT bypass the door safety switch by

permitting the dryer to operate with the door

open. The dryer will stop tumbling when the door

is opened. Do not use the dryer if it does not stop

tumbling when the door is opened or starts

tumbling without pressing the START

mechanism. Remove the dryer from use and call

the service person.

16. ALWAYS clean the lint filter after every load. A

layer of lint in the filter reduces drying efficiency

and prolongs drying time. Keep area around the

exhaust opening and adjacent surrounding area

free from the accumulation of lint, dust and dirt.

The interior of the dryer and the exhaust duct

should be cleaned periodically by qualified

service personnel.

17. Do not repair or replace any part of the dryer, or

attempt any servicing unless specifically

recommended in the user-maintenance

instructions or in published user-repair

instructions that you understand and have the

skills to carry out. ALWAYS disconnect the

electrical power to the dryer before attempting

service. Disconnect the power cord by grasping

the plug, not the cord.

18. If supply cord is damaged, it must be replaced by

a special cord or assembly available from the

manufacturer or its service agent.

19. Before the dryer is removed from service or

discarded, remove the door to the drying

compartment.

20. Failure to install, maintain, and/or operate this

machine according to the manufacturer’s

instructions may result in conditions which can

produce bodily injury and/or property damage.

IMPORTANT: Solvent vapors from dry-cleaning

machines create acids when drawn through the

heater of the drying unit. These acids are corrosive

to the dryer as well as to the laundry load being

dried. Be sure make-up air is free of solvent vapors.

IMPORTANT: Have your dryer installed properly.

Don’t do it yourself unless you know how!

NOTE: The WARNING and IMPORTANT

SAFETY INSTRUCTIONS appearing in this

manual are not meant to cover all possible

conditions and situations that may occur. Common

sense, caution and care must be exercised when

installing, maintaining, or operating the dryer.

Always contact your dealer, distributor, service agent

or the manufacturer about any problems or conditions

you do not understand.

512680

Installation

Dimensions

Nonmetered Models

DRY2471N

*With leveling legs turned into base.

NOTE: Exhaust openings are 4 inch (10.2 cm) metal ducting.

DRY2472N

*With leveling legs turned into base.

NOTE: Exhaust openings are 4 inch (10.2 cm) metal ducting.

13/8 in. N.P.T. Gas Connection

DRY2471N

23.5 in.

(59.7 cm)

8.0 in.

(20.3 cm) 0.4 in.

(1.02 cm)

*4.5 in. (11.4 cm)

28 in.

(71.1 cm)

*36 in. (91.4 cm)

*15.44 in.

(39.2 cm)

15.4 in.

(39.1 cm)

ELECTRIC MODELS

4.0 in.

(10.2 cm)

26.875 in.

(68.3 cm)

21.56 in.

(54.8 cm)

*40.19 in. (102 cm)

*43 in. (109.2 cm)

DRY2472N

23.5 in.

(59.7 cm)

8.0 in.

(20.3 cm) 0.4 in.

(1.02 cm)

*4.5 in. (11.4 cm)

28 in.

(71.1 cm)

*36 in. (91.4 cm)

*40.19 in. (102 cm)

15.4 in.

(39.1 cm)

GAS MODELS

2.8 in.

(7 cm)

26.875 in.

(68.3 cm)

2.3 in.

(6 cm)

*15.44 in.

(39.2 cm)

4.0 in.

(10.2 cm)

21.56 in.

(54.8 cm)

*43 in. (109.2 cm)

Installation

512680

Metered Models

NOTE: Side, rear and bottom exhaust openings are

4 inch (10.2 cm) ducting. Gas models cannot be

vented out left side of cabinet because of burner

housing.

IMPORTANT: The dryer should have sufficient

clearance around it for needed ventilation and for

the ease of installation and servicing. For maximum

drying performance, we recommend that more

clearance be allowed around the dryer than the

clearances that are listed throughout this manual.

DRY2096N

*With leveling legs turned into base.

NOTE: Exhaust openings are 4 inch (10.2 cm) metal ducting.

DRY2238N

*With leveling legs turned into base.

NOTE: Exhaust openings are 4 inch (10.2 cm) metal ducting.

13/8 in. N.P.T. Gas Connection

23.5 in.

(59.7 cm)

8.0 in.

(20.3 cm) 0.4 in.

(1.02 cm)

28 in.

(71.1 cm)

*36 in. (91.4 cm)

15.4 in.

(39.1 cm)

ELECTRIC MODELS

4.0 in.

(10.2 cm)

26.875 in.

(68.3 cm)

22.06 in. (56 cm)

Electronic Control Models

*40.19 in. (102 cm) Coin Slide Models

*4.5 in. (11.4 cm)

*15.44 in.

(39.2 cm)

21.56 in. (54.8 cm)

Coin Slide Models *38.19 in. (97 cm) Electronic Control Models

*43 in. (109.2 cm)

Standard Capacity Meter case

*43.875 in. (111.4 cm)

High Capacity Metercase

DRY2238

GAS MODELS

23.5 in.

(59.7 cm)

8.0 in.

(20.3 cm)

28 in.

(71.1 cm)

*38.19 in. (97 cm) Electronic Control Models

15.4 in.

(39.1 cm)

2.3 in.

(6 cm)

26.875 in.

(68.3 cm)

0.4 in.

(1.02 cm)

2.8 in.

(7 cm)

22.06 in. (56 cm)

Electronic Control Models

*4.5 in. (11.4 cm)

*40.19 in. (102 cm) Coin Slide Models

4.0 in.

(10.2 cm)

*15.44 in.

(39.2 cm)

*36 in. (91.4 cm)

21.56 in. (54.8 cm)

Coin Slide Models

*43 in. (109.2 cm)

Standard Capacity Meter case

*43.875 in. (111.4 cm)

High Capacity Metercase

Installation

512680

Before You Start

Tools

For most installations, the basic tools you will need

are:

Figure 1

NOTE: An 8 in. (20.32 cm) coin drawer is required

for coin operated MDC and NetMaster models with

standard capacity meter case and high capacity

meter case models starting with Serial Nos.

beginning 1010. High capacity meter case MDC

and NetMaster models with Serial Nos. beginning

0910 through 1010 require a 7.21 in. (18.31 cm)

coin drawer.

Card Reader Models

The machine is shipped from the factory with the

Electronic Control Diagnostic Harness Assembly

unplugged. To avoid unauthorized manual

programming or vending perform the following steps.

1. Open service door. Refer to Figure 2.

2. Locate diagnostic harness on electronic control.

3. Plug connectors for “white/black” wire and “red/

blue” wire together.

D818I

1Wrench

2Screwdrivers

3Level

4Teflon Tape

5Duct Tape

FLW6R

1 Service Door

Figure 2

Any disassembly requiring the use of

tools must be performed by a suitably

qualified service person.

W299

WARNING

Otros manuales para D677I

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Secadora de Alliance Laundry Systems

Alliance Laundry Systems

Alliance Laundry Systems D310IE3B Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems DRY710C Guía

Alliance Laundry Systems

Alliance Laundry Systems DR5004WE Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems DRY684C Guía

Alliance Laundry Systems

Alliance Laundry Systems ADE3TFWS431AW01 Instrucciones de funcionamiento

Alliance Laundry Systems

Alliance Laundry Systems SDE807 Guía

Alliance Laundry Systems

Alliance Laundry Systems 510977R9 Guía

Alliance Laundry Systems

Alliance Laundry Systems 602004144 Guía de solución de problemas

Alliance Laundry Systems

Alliance Laundry Systems LTS87A*H Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 506126R5 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems HAT30N Instrucciones de funcionamiento

Alliance Laundry Systems

Alliance Laundry Systems IGHP190E Manual del propietario

Alliance Laundry Systems

Alliance Laundry Systems BD3LLFGS401UW01 Instrucciones de funcionamiento

Alliance Laundry Systems

Alliance Laundry Systems 70444901R3 Manual del propietario

Alliance Laundry Systems

Alliance Laundry Systems DRY725C_SVG Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems CTSA9AWN Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems T477C Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems EE1010 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems Drying Tumblers 50 Pound Capacity 75 Pound Capacity Model Identification Part No.... Manual del propietario

Alliance Laundry Systems

Alliance Laundry Systems ADEE8B BLACK Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems JE2870 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems CHD25G2 Instrucciones de funcionamiento

Alliance Laundry Systems

Alliance Laundry Systems UT025 Manual del propietario

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario

Frigidaire

Frigidaire CAQE7077KW0 Manual del propietario

Bosch

Bosch WTX8HKM9SN Manual de usuario
