Allen + Roth 1789VA-30-310 Manual de usuario

ATTACH YOUR RECEIPT HERE

Serial Number__________________ Purchase Date__________________

ALLEN + ROTH and logo design are trademarks or registered

welcoming • sophisticated • inspiring

xxxxxxx

ITEM #2694516

Français p. 11

Español p. 21

VANITY WITH TOP

MODEL #1789VA-30-310

Questions, problems, missing parts? Before returning to your retailer, call our customer service

department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.

You could also contact us at [email protected] or visit www.lowespartsplus.com.

TABLE OF CONTENTS

Package Contents...........................................................................................................................3

Hardware Contents..........................................................................................................................3

Safety Information............................................................................................................................3

Preparation......................................................................................................................................4

Assembly or Installation Instructions...............................................................................................4

Care and Maintenance.....................................................................................................................9

Warranty..........................................................................................................................................9

Replacement Parts List..................................................................................................................10

HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE)

PACKAGE CONTENTS

SAFETY INSTRUCTIONS

Please read and understand this entire manual before attempting to assemble, operate or install the

product.

WARNING

• There are several assembly steps, including unpacking, that require two adults.

CAUTION

• DO NOT try to pry off top from vanity, as damage to top or vanity may occur.

• Follow these instructions closely, take your time, and use care while assembling this vanity.

KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

PART DESCRIPTION QUANTITY

A Vanity 1

BTop (preassembled

to vanity (A)) 1

C Backsplash 1

ETip-out Door (preassembled

to Vanity (A)) 1

FLeft Door (preassembled

to Vanity (A)) 1

GRight Door (preassembled

to Vanity (A)) 1

H Shelf 1

IFloor Plumbing

Cutout Lid 1

Touch Up Pen

Qty. 1

INSTALLATION INSTRUCTIONS

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with

package contents list and hardware contents list. If any part is missing or damaged, do not

attempt to assemble the product.

Estimated Installation Time: 45 minutes (24 hours for silicone caulk to dry).

Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors,

silicone caulk, power drill with drill bit

Helpful Tools (not included): Measuring tape, level

1. Please remove the top (B) from the vanity (A). Place the top (B) and backsplash (C) face

down onto a scratch-free surface such as a foam sheet that came in the packaging.

BACK

INSTALLATION INSTRUCTIONS

Note: A

t this stage it may be easier to install

the faucet and drain kit (not included) to top (B)

per the manufacturer’s instructions, before

moving on to Step 3.

Apply stain free silicone caulk (not included) to

the top edge of vanity (A). With the help of

another adult, gently lower top (B) onto the

vanity (A). Wipe away any excess caulk with a

soft cloth, and wait approximately 24 hours for

it to dry.

WARNING

Vanity (A) MUST be secured to wall.

Note: Clean area where the vanity (A) will be

permanently located prior to beginning installation,

ensuring the vanity (A) will not interfere with any

water supply and drain lines once mounted.

2. With two people, carefully place vanity (A)

against the wall in its final location.

While holding the vanity base firmly against the

wall, use the pre-assembled levelers on the

bottom of each leg of the vanity (A) to level the

item. Twisting the levelers counterclockwise

will raise the height of the vanity (A), and

twisting them clockwise will lower the vanity.

Once the vanity is in place, against the wall,

and level from front to back and side to side,

drill a hole through the vanity mounting area

and into the wall studs (as illustrated in

diagram 2). Using appropriate mounting

hardware (not included), secure the vanity (A)

to a wall stud. If possible, secure the vanity

(A) to two wall studs for increased stability.

INSTALLATION INSTRUCTIONS

4. Apply silicone caulk (not included) to unpolished

side and bottom of backsplash (C). Position

backsplash (C) on top (B) and against wall.

Clean any excess caulk before allowing

to dry.

5. The back of the vanity is open for accessibility

for drain(s) and water line(s) hookup. If your

plumbing comes out of the back wall, insert

the floor plumbing cutout lid (I), as shown in

Illustration 5. This will close the hole and

increase your storage space.

If your plumbing comes out of the floor, this

hole provides accessibility for drain and water

line hookup.

INSTALLATION INSTRUCTIONS

6. From the front of the assembly, insert shelf

pins at desired height, ensuring they are

level. Place shelf (H) on top of shelf pins.

If you need to adjust the doors, do so in the following manner.

To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws.

To adjust door left or right, turn screws (b) on both hinges, in or out.

To adjust door in or out, loosen screws (c) on both hinges, adjust door, and retighten screws.

INSTALLATION INSTRUCTIONS

Gently open the top tip-out door (E).

Gently push up to close the top tip-out door (E).

Assembly is now complete. Install desired

faucet and drain assemblies (neither included)

per the manufacturers’ instructions to

complete the installation.

CARE AND MAINTENANCE

WARRANTY

IMPORTANT

• Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product.

• You can clean the vanity with a gentle, non-abrasive household cleaner.

• Make sure to dry the wood immediately with a soft cloth or towel.

• The stone top can be cleaned using standard marble cleaning agents available at your local

supplier.

• Tips for using touch-up pen (AA): For scratches, stroke in direction of scratch. Rub off excess

colorant promptly with a soft cloth.

• Shade variations and patterns are an inherent characteristic of stone (e.g. granite, marble,

engineered stone). Stone tops will vary from product to product. Use caution placing items

such as soap or any fragranced material on the stone surface. Use a soap dish, coaster or

similar item to protect the surface if placing any soap or fragranced products on the stone.

• If soap or fragranced products come in contact with the stone top, rinse the surface with water

and dry using a soft non-abrasive cloth.

• WARNING: Must use cleaning agents safe for stone. Check your cleaning agents use

restrictions before using on any stone. Damage to the stone may result. Vanity manufacturer not

responsible for damage caused by improper cleaning agents or soaps used. Warranty will not

cover damage caused by the use of improper soaps or cleaning agents.

• DO NOT use products to clean the stone top that contain acetone, lemon, vinegar or other

acids as these may cause damage to the stone surface.

• Periodically reseal the stone top using an appropriate stone sealer available from your local

home store. Follow the manufacturer’s directions on how to apply.

The manufacturer warrants this item against defects in materials and workmanship for a period of

one (1) year from the date of original retail purchase. This warranty applies only to the original

purchaser. This warranty does not apply to any damage on the product by accident, misuse, or

modified, improper installation or by affixing accessories not produced by the manufacturer. The

manufacturer will not be held liable for damages caused from cleaners or soaps that etch or stain

the stone top. The manufacturer is not accountable whatsoever for product installation during the

warranty period. There is no further expressed warranty. The manufacturer shall not be legally

responsible for incidental, consequential or special damages arising at or in connection with

product use or performance except as may otherwise be accorded by law. The manufacturer

disclaims any and all implied warranties.

REPLACEMENT PARTS LIST

For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m.,

EST, Monday - Sunday.

ALLEN + ROTH and logo design are trademarks or registered

Printed in Vietnam

AA Touch-up pen M-1128

1789VA-BN HANDLE

T-1007

CC Pull (with screw)

B1044

BB Shelf Pin

Leveler

C-90-107

Hinge

PART DESCRIPTION PART#

Left Door

1789VA-30-926 TOP

C 1789VA-30-926 BS

F 1789VA-30-310

DOOR SET

GRight Door

H Shelf 1789VA-30-310-SHELF

310 FP LID

I Floor Plumbing Cutout Lid

1789VA-30-310-TRAY

J Tip-out Tray

926 Engineered

Calacatta Top

926 Engineered

Calacatta Backsplash

D PU17-18X14-SQUARE

Sink

E 1789VA-30-310-TIP-OUT DOOR

Tip-out Door

BBAA CC DD EE
