Alcatel Y850 Manual de usuario

Quick Start Guide

CJB18R0ALAAA

www.sar-tick.com

This product meets applicable national SAR limits of 2.0W/kg.

The specific maximum SAR values can be found in the section of this

user guide.

When carrying the product or using it while worn on your body, either

use an approved accessory such as a holster or otherwise maintain a

distance of 5 mm from the body to ensure compliance with RF

exposure requirements. Note that the product may be transmitting

even if you are not making a phone call.

Safety and use

We recommend that you read this chapter carefully before using this device. The manufacturer

disclaims any liability for damage, which may result as a consequence of improper use of this device

or of use contrary to the instructions contained herein.

Do not switch on your device when its use is prohibited or when using the device may

cause interference or danger.

Follow rules or regulations in hospitals and health care facilities. Switch off your device

near medical apparatus.

Switch off your device in an aircraft. The device may cause interference to aircraft

control signals.

Switch off your device near high-precision electronic devices. The device may affect

the performance of these devices.

Do not attempt to disassemble your device or its accessories. Only qualified personnel

are allowed to service or repair the device.

Do not place your device or its accessories in containers with a strong electromagnetic

field.

Do not place magnetic storage media near your device. Radiation from the device may

erase the information stored on them.

Do not subject your device to high temperatures or use it in a place with flammable gas

such as a petrol station.

Keep your device and its accessories away from children. Do not allow children to use

your device without guidance.

Only use approved batteries and chargers to avoid the risk of explosion.

Observe the laws or regulations on device use. Respect others’ privacy and legal rights

when using your device.

It is recommended that the equipment only be used in an environment where the temperature is

between -10°C and 50°C and humidity is between 10% to 90%.

1. Overview

ALCATEL ONE TOUCH LINK Y850 is a portable wireless router, providing a simple way to share 4G

with any Wi-Fi embedded device.

1.1 Package contents

●ONE TOUCH Y850

●USB cable ●Quick start guide

●USB Wall charger

●Car Charger*

●USB Adapter*

●USB Cradle charger *

Note: *depending on your region and market.

1.2 Application

1.3 Device overview

Number

Description

①

Power on/off Key

②

WPS Key

③

Reboot Button

④

Charging Pin*

⑤

SIM Card Cover

⑥

OLED screen

⑦

Micro USB Interface

①

②

⑥

④

③

⑤

⑦

Note: *depending on your region and market

Use the device’s 3 buttons as follows:

Button

Description

①Power On/Off

Long press to turn on/off the device

Short press to put the OLED screen in either active or sleep mode.

②WPS

Long press to turn on WPS

Short press to display SSID and password

③Reboot

Long press to reboot the device if the system freezes.

1.4 Turning on the device

Step 1: Push down on the SIM Card cover and install your SIM card as indicated on the device.

Step 2: Press the Power On/Off button

1.5 Screen display

The screen display is interpreted as follows:

1 Network Signal (dynamic graphic symbol )

2 Network type (4G/H+/3G/2G)

3 SMS status (full, unread, incoming)

4 Connection status(connected and disconnected )

5 Wi-Fi (number of user connected/WPS connection)

6 Battery level (dynamic graphic symbol when charging)

7 Name of the network registered

Screen description:

Category

Icon Display

Signal Strength

From 1 bar to excellent signal strength

Network type

: EDGE/GPRS : UMTS/HSDPA/HSUPA,

H+: HSPA+,4G:LTE

SMS status

: SMS is available

: Unread SMS

: SMS full

Connection Status

connected
