Akuvox R29C Instrucciones de montaje
Installation Tips for R29C & R29S
Content
1. Step-by-Step Instructions...................................................................................... 1
2. Guidelines................................................................................................................ 1
3. Some specifications are recommended.............................................................. 2
4. Installation................................................................................................................ 3
5. Test Relays...............................................................................................................3
1
1. Step-by-Step Instructions
1. Please check the version you got and verify the Integrity of the package.
2. Ensure wiring min. specs are met:
a. We recommend using PoE for power. If using the 12 vdc power
source, MUST be power conditioned by UPS.
b. Internet: CAT5e/6 < 328'）to router/switch.
3. Secure the panel by tamper-proof screws.
4. Indoor and outdoor installation are supported.
5. Test door release.
6. Pay attention to the installation environment:
a. Outdoor: Don't place under direct sunlight.
b. Indoor: Keep the panel at least 2 meters away from light, and at least
3 meters away from window and door.
2. Guidelines
1. NO AC POWER.
2. Confirm network communication from mount point to main headend.
3. For retrofit installations, check existing wiring for the network and power.
4. Akuvox provides the following:
Smart Intercom
Installation kits (Optional)
Wall mounting
Flush mounting
Plasterboard mounting
Wall mounting rain cover
Flush mounting rain cover
5. Akuvox does not provide:
2
RF Card
Cat cable
UPS device
Extension cable for power
6. Provide room behind the mounting location for excess wiring.
7. Never introduce two power sources for lock release in parallel.
3. Some specifications are recommended
If you choose to use the following accessories, please use formal accessories
that meet the certification standards.
Power Supply AC to DC adapter
Input: 100-240V AC (mains)
Output: 12V/1A
Locking barrel connector
Power Cable
USA: NEMA 5-15 (typical 3-prong male)
IEC320-C13 (to power supply)
EU: CEE 7/4, Type F (“Schuko plug”)
IEC320-C5 (to power supply)
Uninterrupted Power Supply (UPS)
Minimum specs: 600VA / 300W
3
4. Installation
1. Connect Ethernet to the available ports.
2. Connect the panel’s relays to the building’s door strike.
3. Connect Panel to PoE OR> Power Supply > UPS > Wall Outlet.
The Panel will start up like a computer. After loading, you should see the
Akuvox software.
5. Test Relays
1. In the Dial interface, press "9999"->"Dial key"->"3888"->"OK" to enter the
system setting.
2. Press "RFCard"->"Add Card" to add RF Card by putting the which near the
RF card reader.
3. Back to home page to place the predefined users card in RF card reader to
unlock.
If successful, you will hear a chime "Welcome, please coming" from the panel
and see a message "Opening door succeeded" on the panel. The door strike
(or other connected system) should respond
Tip: For more installation details, please refer to the Quick Guide.
