Handheld Microphone

LC “Light Condenser”

Vocals

Recording

Live Sound

Sound/AV company

•Slender and elegant silhouette

•PB 1000 Presence boost adapter for increased intelligibility

•Condenser vocal microphone for onstage use

•XLR connector module with 24-carat gold plated pins for optimized connectivity

•24-carat gold plated transducer case for optimum conductivity and resistance to

corrosion and humidity

•Spring steel wire-mesh grill for extreme ruggedness incl. reliable control of pops and wind noise

•Internal elastic suspension

This professional condenser vocal microphone will make your voice cut through the loudest mix - on any

stage. Its cardioid polar pattern ensures maximum gain before feedback and has been optimized for use

with in-ear monitor systems. LC is custom-designed with piano black painting to address the aesthetic

preferences of special performances: a slim line premium condenser microphone.

Delivering an extremely accurate, detailed and natural sound, the AKG LC features an XLR connector

module with 24-carat gold plated pins for optimized connectivity, as well as resistance to corrosion and

humidity. Additionally, the LC features a spring steel wire-mesh grill for extreme ruggedness offering

reliable control of pops and wind noise while an artist is on stage.

The resulting LC microphone features a frequency range of 60 to 20,000 Hz and premium 24-carat gold

plated transducer case for optimum conductivity. Offering a slender and elegant silhouette, the

lightweight unit has a subtle piano black finish to visually complement any performance.

L C

Handheld Microphone

o

Specifications

Polar pattern cardioid

Frequency range 60 to 20,000 Hz

Sensitivity 4 mV/Pa (-52 dBV)

Max. SPL for 1%/3% THD 140/145 dB SPL

Equivalent noise level 25 dB-A

Signal/noise ratio (A-weighted) 69 dB

Impedance/load Impedance ≤200 ohms

Recommended load impedance: >2000 ohms

Powering: 9 to 52 V phantom power to DIN 45596

Current consumption: typ.3 mA

Finish Piano Black

Dimensions length: 185 mm (7.3 in.);

diameter: 34 mm (1.3 in.)

Net/shipping weight: 260 g (9.2 oz.)/ 620 g (1.4 lbs.)

Standard accessories: Microphone bag, SA 45, PB 1000

Optional accessories: B 18, H 30, H 50, SA 44, SA 61, ST 1, ST 45,

ST 46, ST 305, W 23, W 1000

Item number L C

Order Number 3133A00030
