Airsight XX59A Manual de usuario
Indoor Wireless/Wired
HD P2P Network Camera
(with H.264 image compression)
Model XX59A
User Manual
2
CONTENTS
1. INTRODUCTION......................................................................................................................................... 3
1.1 Features .......................................................................................................................................... 4
1.2 Packing List ..................................................................................................................................... 4
1.3 Product Views.................................................................................................................................. 5
1.4 PC System Requirements ............................................................................................................... 6
1.5 Hardware Installation....................................................................................................................... 6
2. INSTALLATION AND SETTINGS ............................................................................................................... 7
2.1 Network Connection........................................................................................................................... 7
2.2 Browser Settings (For IE only) ........................................................................................................... 8
2.3 UPnP Service..................................................................................................................................... 8
2.4 Search IPCam IP Address Search Tool (for IE browser only) ........................................................... 10
2.5 Install the OCX ActiveX (For IE only)................................................................................................ 11
3. SOFTWARE OPERATION........................................................................................................................ 12
3.1 Functions ......................................................................................................................................... 14
3.2 For Live Video (for IE browser)......................................................................................................... 15
4. PARAMS SETTINGS ................................................................................................................................ 24
4.1 Device Info. ...................................................................................................................................... 24
4.2 Video Info......................................................................................................................................... 25
4.3 Audio Settings .................................................................................................................................. 27
4.4 Motion Detection .............................................................................................................................. 28
4.5 Alarm Settings.................................................................................................................................. 33
4.6 Basic Network Settings .................................................................................................................... 36
4.7 Wireless Lan Settings ...................................................................................................................... 44
4.8 UPNP Settings ................................................................................................................................. 45
4.9 Cruise Settings................................................................................................................................. 46
4.10 Indicator Settings ........................................................................................................................... 48
4.11 User Manage.................................................................................................................................. 49
4.11 Log ................................................................................................................................................. 51
4.12 Date Time Settings......................................................................................................................... 52
4.13 Multi-Device Settings for IE browser .............................................................................................. 53
4.14 Mail Service Settings...................................................................................................................... 54
4.15 FTP Service Settings...................................................................................................................... 55
4.16 P2P settings ................................................................................................................................... 57
4.17 SD Card Info. ................................................................................................................................. 58
4.18 Local Settings for IE browser ......................................................................................................... 59
4.19 System Tool.................................................................................................................................... 60
5. PLAYBACK for IE browser only ............................................................................................................. 61
6. FREQUENTLY ASKED QUESTIONS ....................................................................................................... 64
7. SPECIFICATIONS .................................................................................................................................... 68
8. OBTAINING TECHNICAL SUPPORT....................................................................................................... 69
3
1. INTRODUCTION
It is recommended that you first read the Quick Setup Guide. This shows you how to set up your
camera using Peer to Peer (P2P). This setup method is extremely fast and easy, and will get
you set up in a matter of minutes. You can then refer to this Owner’s Manual for more advanced
features.
IMPORTANT NOTICE
The various screens throughout this owner’s manual will look different depending on the
browser you use. Full functionality is available when using Internet Explorer (IE) with ActiveX
(OCX) installed. Limited functionality is available with other browsers, such as Safari, Chrome,
and Firefox.
Please Read this manual carefully, according to the browser you are using.
This is an integrated wireless IP Camera solution. It combines a high quality digital Video Camera
with network connectivity and a powerful web server to bring clear pictures to your Desktop from
anywhere on your local network or over the Internet.
The main function of the camera is to transmit remote video over IP network. The high quality video
image can be transmitted with 30fps speed on the LAN/WAN by using H.264, MJPEG compression
technology.
It is based on the TCP/IP standard, build-in WEB server which supports Internet Explorer. Therefore
the management and maintenance of your camera becomes simple by using the network to achieve
the remote configuration, start-up and to upgrade firmware.
You can use your IP Camera to monitor your home or your office. Also, controlling and managing
images are simple by visiting the web site.
4
1.1 Features
☆ Powerful high-speed video protocol processor
☆ High-sensitivity 1/4’’ CMOS sensor
☆ Picture total 1000K pixels (1 megapixel)
☆ Supports Pan and Tilt (PT) control, Pan 270°, Tilt 120°
☆ Optimized H.264 MJPEG video compression for transmission
☆ Multi-level user management and passwords definition
☆ Embedded Web Server for users to visit by IE
☆ Supports wireless network (WI-FI/802.11/b/g/n)
☆ Supports Dynamic IP (DDNS) and UPNP LAN and Internet (ADSL, Cable Modem)
☆ Gives an alarm in case of motion detection
☆ Supports image snapshot
☆ Supports multiple protocols：TCP/IP HTTP DNS DHCP PPPoE SMTP FTP SSL TFTP NTP
ARP/RARP NFS RTSP RTP RTCP.
☆Supports WEP/WPA/WPA2 encryption
☆ Supports IE, Firefox, Safari, and Google chrome browsers
1.2 Packing List
●IPCamera
●Wi-Fi Antenna
●User Manual & Quick Setup Guide
●DC Power Supply
●CD
●Network Cable
●Mounting bracket
5
1.3 Product Views
1.3.1 Rear View
1.3.2 Bottom View
Note QR code label for easy P2P setup. (See Quick Setup Guide).
6
1.4 PC System Requirements
System configuration requirements:
CPU: 2.06 GHZ or above.
Memory: 256M or above.
Network Card: 10M or above.
Display Card: 64M or above memory.
Recommended Operating system: Windows XP, Windows Vista, Windows 7.
1.5 Hardware Installation
Follow the steps below to set up your camera hardware.
1. Install the Wi-Fi antenna.
2. Plug the power adaptor into the camera and into an AC outlet.
3. Plug the network cable into the camera and router/switch.
4. It takes approx 30 seconds to boot up the camera, then you will find the IP address from Search
IP Cam Tool (Figure 1.5).
5. When the power is on and the network cable is connected, the green LED on the rear panel will
stay on.
The yellow LED will keep flashing, and the Indicator LED on the front of the camera will flash.
(The indicator LED can be controlled by software).
7
2. INSTALLATION AND SETTINGS
System Requirement:
Operating System: Windows 2000 / XP / Vista / 7 / 8
Network Protocol: TCP/IP
Network Structure: Applies to all network connections 10/100M LAN platform
Browser: Internet Explorer 6.0 or above. Firefox, Google, Safari, or Chrome.
2.1 Network Connection
Intranet and Extranet Connection Reference:
Extranet means public IP (i.e. The Internet), Intranet means private IP. If your IP belongs to the follow range, then
it’s a private IP :
Category A: 10.0.0.0 - 10.255.255.255
Category B: 172.16.0.0 - 172.31.255.255
Category C: 192.168.0.0 - 192.168.255.255
Intranet Connection: The IP camera and your computer (device) should be under the same network environment,
and both of the IPs should be under the same subnet, pictured as below:
Figure 1.0
Extranet Connection: there are 2 ways as below:
(1). IP camera connects to the Internet via a router, here camera’s IP is a private IP, client needs to connect to the
IP camera through a router, with port forwarding to be connected correctly, as below:
Figure 1.1
8
(2). IP camera connects to the Internet directly, if it’s a fixed IP provided by your ISP, just input it. If it’s a dynamic IP,
then input the account and password provided by your ISP for broadband connection.
Figure 1.2
2.2 Browser Settings (For IE only)
OCX will be downloaded automatically when you login to the IP Camera, but you might have to set the IE browser
to enable the OCX to be downloaded automatically after signing in. Steps as below:
1. Close the firewall of your computer.
2. Change the ActiveX settings, open your IE browser, select Tools then Internet Options then Security then
Custom Level (See Figure 1.3).
Figure 1.3
Then set the ActiveX controls and plug-ins. Set the ActiveX options to Enable or Prompt as indicated in Figure
1.4.
Note especially:
Prompt: Download unsigned ActiveX controls
Prompt: Initialize and script ActiveX controls not marked as safe
Enable: Run ActiveX controls and plug-ins
9
Figure 1.4
Click OK and restart the browser.
You can also click the Start menu then Internet Explorer, and choose Internet attributes, or via Control Panel
select Internet Explorer to access Security settings.
NOTE: Make sure that your firewall or anti-virus software doesn’t block the software or ActiveX. If you couldn’t see
live video, please close your firewall or anti-virus software, and try again.
2.3 UPnP Service
UPnP could help you to find your camera’s IP more quickly. For Window XP, from Control Panel > Add or remove
applications > Add or remove Windows component > Network service > Detailed data > UPnP users
interface, the factory default settings is disabled. Enable it, then it can allow your operating system to support
UPnP.
You can also click the Start menu then Internet Explorer, and choose Internet attributes, or via Control Panel
select Internet Explorer to access Security settings.
10
2.4 SearchIPCam IP Address Search Tool (shown for IE browser below)
Step 1: Use tool SearchIPCam.exe to find IP address of LAN.
Figure 1.5
Step 2: Double click Search IPCam on your desktop, the camera’s IP & MAC address will be displayed. If you want
to search again, click Search.
Figure 1.6
Step 3: Double-click the IP address of your camera to enter the login interface.
