Airlink101 AR670W Manual de usuario
150N Draft 802.11n Wireless Router
Model #AR670W
Quick Installation Guide
Ver. 1A
This Quick Installation Guide only provides the basic instructions. For more
detailed information, please refer to the User’s Manual on the supplied CD.
Note: Priortoconnectingtherouter,besuretopoweroffyourcomputer,DSL/Cablemodem,
andtherouter.Youshouldsetuptherouterwitha wired connectionfirstbeforeattempting to
setupany wirelessconnections.
Step 1 Connectoneendofthenetworkcableto the WAN portofthe router and connect the
otherendofthe cable to the DSL/Cable modem.
Step 2 Withanother networkcable,connectoneend of the cable to your computer’snetwork
cardand connect the other endtooneof the LAN (Ethernet) portson the router.
Step 3 Power on the DSL/Cable modem and wait for the lights on the modem to settle
down.
Step 4 Power on the router by connecting one end of the supplied power adapter to the
power jack of the router and connecting the other end to an electrical outlet.
Step 5 Power on your computer.
Step 6 Makesure the WAN,Wireless,and the LAN portsthat the computer is connected to
arelit. If not, trytheabovesteps again.
ConnectingtheRouter
Section 1
Section 1
AR670W Icon Illustrations:
Power
On: Power on
Status
Blinking: Function properly.
WAN
On:Link established / Blinking: Data transmission
Wireless
On: Wireless is ready / Blinking: Data transmission
LAN
On: Link established / Blinking: Data transmission
WPS (WiFi Protected Setup)
Blinking Green: WPS setting in progression
Static Green: WPS successfully set up
BlinkingRed:Errorfound
Section 2
Step 1 Go to Start, Run, type command (for Windows 95/98/ME) or cmd (for Windows
2000/XP) and click OK. You will see the command prompt as below.
Step 2 Type ping 192.168.1.1 and press Enter. You should get four reply responses back.
Step 3 If you get Request timed out, or Destination host unreachable, double-check the
network cable connection between the computer and the router and try Step 2 again. If you
stillencounterproblem,go to the next step; otherwise proceed to Section 3, Configuring the
Router.
Step 4 For Windows 2000/XP, type ipconfig/release and press Enter. (Windows 98se/ME
skip to Step 6)
VerifyingConnection to theRouter
Step 5 Type ipconfig/renew and press Enter. You should get anIP addressof 192.168.1.x
(where xis a number between 2 - 254). Proceed to Section 3, Configuring the Router. If
youdon’t get an IP address, resettherouterbyholding in the reset button onthebackof the
routerfor10seconds while it is ON and try ipconfig/renew again.
Step 6 For Windows 95/98/ME go to Start, Run, type winipcfg and click OK. (Not
necessaryforWindows2000/XP Users)
Step 7 Select your network card from the drop-down menu and click Release.
Step 8After your IPaddress is released, click Renew. You should get an IP address of
192.168.1.x (where x is a number between 2 - 254). If you don’t get an IP address, reset
therouterby holding in the reset button on the backoftherouterfor10seconds while it is ON
and try Renew again.
Section 3
Step 1 Opena web browser(InternetExplorer)andtype192.168.1.1 in the URLAddressfield
andpressEnter.
Step 2 Enter admin for both username and password fields and click OK.
ConfiguringtheRouter
Cable Modem
For most cable modem users, you should be able to connect to the Internet without any
configuration. If your ISP has provided you with a host name, enter it in the optional Host
Name field.
ClickontheClone MACAddress button.Click Apply and OK to save the settings.
GototheStatus tab,Internet connection sectiontoverifythatyouaregetting valid IP
addressinformation. If youhavetrouble connectingtothe Internet,pleasego throughthe
Troubleshooting section at the end of this installationguide.
Step 3 Selectthe proper region, NorthAmerica orSouthAmerica, and clickApply.
Warning: Incorrectly selecting thecurrentregion of operation mayresultinillegal operation
andmay causeharmfulinterference toothersystems.You canreferto theusermanual onthe
provided CD for more details.
Step 2 Enter your username and password provided by your ISP.
DSL
ForDSLusers, followthestepsbelowtoconfiguretherouter.
Step 1 Select PPPoE from the drop-down menu.
Note: Dependingon the ISP,youmayneedto include the domain namewithyourusername.
Example: [email protected]
Connecting the Router Wirelessly
Beloware the defaultwirelesssettings of therouter.You must configureyourwireless network
cardtothesamesettingsinordertoestablisha wireless connection to the router. Please refer
toyour wireless networkcard’smanualon how toconfigurethesesettings.
SSID:default
Operating Mode: Infrastructure
Authentication:Open System
Channel #: 6
WEP: disabled
If you want to change the router’s wireless settings, log in to the router and select the
Wireless tab.Be sure to click Apply and OK to save the settings.
Forinformation on changing the router’sloginpasswordand enabling wirelessencryption,
pleaserefertotheUser’sManualonthe provided CD.
Step 3 Click Apply andOK to save the setting.
GototheStatus tab,Internet connection sectiontoverifythatyouaregetting valid IP
addressinformation. If youhavetrouble connectingtothe Internet,pleasego throughthe
Troubleshooting section at the end of this installationguide.
Section 4
Section 5 (Optional)
Wi-Fi Protected Setup
Wi-FiProtectedSetup™(WPS)isanewandeasy way to configure the encryption for your
wirelessnetwork clients.In ordertouse itwithyour router,firstly, youmustconfigure the
wirelessencryption ontherouter.Youcan findinstructionsfor configuring itinthe UserManual
locatedon the CD thatcamewithyour router. Secondly,youwillneed to have wireless
adaptersthat support this feature. Ifyourwirelessadapters do not support WPS,youwillneed
toset up the wirelesssecuritymanuallyand you can skipthissection.
In theinstructions below, we aregoing to usethe utility, Wireless Monitor thatcomes with the
Airlink101 300N or 150N WirelessAdapters (AWLC6070,AWLC6080,AWLH6070,
AWLH6080,AWLL6070,andAWLL6080) astheexample.
Step 1 Goto the computer with theAirlink101 150N wireless adapter and open theWireless
Monitor. UnderAPList,click on the wireless network you want toconnecttoandclickon the
WPS Connect button.
Note: If you do not see the WPS Connect button, you can go to www.airlink101.com to
download the latest utility and driver.
Step 2 Choose your configuration method, either Push Button or Pin Code, and click Next.
Step 3a Write down the PIN if you choose Pin Code method and click Next.
Step 3b Ifyouchoose Push Button method, click on the Wi-Fi Protected Setup button.
