Airlink101 AR625W Manual de usuario

Rev. 1.0

Quick Installation Guide

Model # AR625W

300N Draft 802.11n Wireless Router

Section 1

Connecting the Router

Note: Priortoconnectingtherouter,besuretopoweroff your computer,DSL/Cablemodem,andthe

router.Toachievemaximum wireless coverage, tilttherouter’santennasoutwardat45°angle.

Step 1 Connectoneendofanetworkcabletothe WAN portoftherouterandconnecttheotherendof

the cable to the DSL/Cable modem.

Step 2 Withanothernetworkcable,connectoneendofthecabletoyour computer’snetworkcardand

connecttheotherendto one of theLAN portsoftherouter.

Step 3 Power on the DSL/Cable modem and waitfor the lights on the modem tosettledown.

Step 4 Powerontherouterbyconnectingoneend of the supplied power adapter to the power jack of the

routerandconnecting theotherendtoan electrical outlet.

Step 5 Poweronyourcomputer.

Step 6 MakesuretheWAN,WLAN,andtheLAN portthatthecomputerisconnectedtoare lit. If not, try

theabovestepsagain.

This Quick Installation Guide only provides the basic instructions. For more

detailed information, please refer to the User’s Manual in the supplied CD.

Section 2

Configuring the Router

Step 1Openthewebbrowser(InternetExplorerorNetscape),type 192.168.1.1 in theAddressbar and

pressEnter.

Step 2 Enter admin for both the username and password fields and click OK.

Cable Modem

Formostcable modemusers,youshould be abletoconnectto theInternetwithoutany configuration. If

yourISPhas provided you with a host name, enter it in the optional Host Name field.Click Apply to save

thesetting.

If your ISP requires a registered MACAddress, click on the MACAddress Clone tab, select Enabled,

andclickonthe Clone My PC’s MAC button. Click Apply tosavethesetting.

Ifyouhavetrouble connecting to the Internet,pleaserefertoSection 4, Verifying Connection.

DSL

ForDSLusers, followthestepsbelow to configure the router.

Step 1 SelectPPPoE from the drop-down menu.

Step 2 Enteryourusernameand password provided by your ISP.

Note: DependingontheISP, you mayneedtoincludethedomain name with your username.

Example: [email protected]

Step 3Click Apply to save the setting.

Ifyouhavetrouble connecting to the Internet,pleaserefertoSection 4, Verifying Connection.

Section 3

Connecting to the Router Wirelessly

Belowarethe default wireless settingsoftherouter.Youmustconfigureyourwireless network card tothe

samesettingsinordertoestablishawirelessconnectiontotherouter.Please refer to your wireless

networkcard’smanual on how toconfigurethesesettings.

SSID(NetworkName):default

OperatingMode:Infrastructure

Authentication:Auto

Channel#:6

Encryption:disabled

Ifyouwanttochangethe router’swirelesssettings,log in to the router and select theWireless tab.Be

suretoclickApply tosavethesetting.

Forinformationonchangingtherouter’slog in password and enabling wireless encryption, please refer

totheUser’sManualintheprovidedCD.

Section 4

Verifying Connection

Step 1 Poweroffthe Cable/DSLmodem, router,and computer and wait for5 minutes.

Step 2 TurnontheCable/DSLmodem and wait for the lightson the modem to settledown.

Step 3 Turnontherouterandwait for the lights on theroutertosettledown.

Step 4Turnonthecomputer.

Step 5 Reconfigure the router as described in Section 2.

Step 6 Log in to the router and select the Statustab.

Step 7Verify that the Internet IPAddress, Default Gateway, and at least one of the DNS fields have

validnumbersassignedtothem(insteadofall0’s).

Ifyou havetroubleconnectingtotheInternettrythestepsbelows.

Ifyousee all 0’s,click ontheIPAddress Renew button (for Cable Modem users) or theConnect button

(forDSLusers).

Ifeachfield has avalidnumberassigned,the router is connectedtotheInternet.

Section 5

TechnicalSupport

E-mail:[email protected]

Toll Free:1-888-746-3238

WebSite:www.airlink101.com

*Theoretical maximum wireless signal rate derived from IEEE 802.11g standard and IEEE 802.11n draft specification version 1.0. Actual data

throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, mix of

wireless products used, radio frequency interference (e.g., cordless telephones and microwaves) as well as network overhead lower actual data

throughput rate. Specifications are subject to change without notice. All products and trademarks are the property of their respective owners.
