AIPTEK PenCam Mini 1.3 Guía
E-Manual
Mega Camera
Manager
Chapter 1: Installation
English
Mega Camera Manager Installation
Place the CD into your CD-ROM and click on the Mega Camera Manager
Icon to begin the installation. If the CD does not automatically display,
simply go to "Start" then "Run" and select the path "D:\Setup.exe". You
may need to replace "D" with the letter that corresponds to your CD-ROM
drive. Mega Camera Manager
After the welcome screen appears, click
"Next".
The dialog box that appears asks if you
would like to restart your computer now
or later. Press "Finish" to complete
installation.
Software Installation
English
Connect the smaller end of the USB cable to
the USB port of your camera.
Plug the larger end of the USB cable to
the USB port of your PC.
Hardware Installation
USB
Chapter 2: How to Use Your Digital Camera
Introduction
The built-in memory of your camera is 128Mbits Flash memory plus
128Mbits SDRAM memory. It supports two kinds of resolution - high
(1248x960) pictures and low (640x480) pictures. It also
supports AVI Movie mode( 624x480) and (304x240) for high and
low . With a USB cable, you can transfer all the pictures to your PC.
resolution resolution
resolution
resolution
Installing batteries
Your camera is powered by 2 AAA Alkaline batteries or by a PC via a USB
cable.
When batteries are removed, all the stored AVI Movies are
cleared; however, still pictures will remain.
With 2 AAA Alkaline batteries, you are able to take 160 pictures.
Battery standby works for approximately 10 days.
English
English
Your camera
USB port
Shutter Switch
View Finder
Lens
Mode Switch
LCD Display
Battery Cover
Focus
AVI Movie Mode
Self Timer
Good Battery
Still Image
Erase All
Erase Last
Resolution
Digit Counter
LCD Display
Plug in USB
Cable
Turning on / off your camera
Pressthemodebuttontoturnonthecamera.
Press the mode button, the LCD indicates still image, AVI movie,
Self-timer, erase last, erase all, resolution and good battery icons
in order.
To use the function of the icons, press the shutter button.
Your camera turns off automatically when idle over 60
Seconds.
H
L888
English
Icon Functions Description
Still Image mode - takes still pictures
AVI Movie mode - takes AVI Movie
Self Timer - starts 10 second self-timer to take a picture
Erase Last - erases the last picture or AVI Movie
Erase All - erases all of the pictures or AVI Movie
in the memory
Low Resolution
Digit Counter - displays the number of the pictures you take
Good battery - indicates good battery status
Low battery - indicates low battery status
High Resolution
Still image mode
(1248x960), up to 40 pictures
AVI Movie mode
( 624x480 ), up to 30sec/10fps
(640x480), up to160 pictures
( 304x240 ), up to 120sec/10fps.
Still image mode
AVI Movie mode
- indicates USB cable is plugged in
Plug in USB Cable
H
L
Description of LCD Display
English
Chapter 3: Taking Pictures
Press the mode button.
The LCD shows the Still
Image Mode icon.
Press the shutter button
to take a single picture.
Still Image Mode
AVI Movie Mode
Press the mode button.
The LCD shows the AVI
Movie Mode icon.
Press the shutter button
to take AVI Movie.
Press the shutter button
again to stop AVI Movie.
You've taken a picture when LCD shows the first flashing
number. When the sixth flashing number appears, the
whole image storing process is completed.
Two beeps with blinking number suggests that there is no
room for storing further AVI Movie.
H0
0
H
English
Taking a picture
Press the mode button.
The LCD shows the Self
Timer icon.
Press the shutter button.
Your camera starts a 10-
second countdown and
takes a picture.
Self Timer
Erase Last
Press the mode button.
The LCD shows the Erase Last icon.
Press the shutter button.
The Erase Last icon starts to blink.
Press the shutter button again and the last stored picture
or AVI Movie is cleared.
H0
H0H0
Erase the last still picture Erase the last AVI Movie
Press the mode button to leave Erase Last mode.
English
Digit Counter
It shows the total images and AVI Movie .taken
The digit counter is also a second counter when
taking AVI Movie.
Press the mode button.
The LCD shows the Erase All icon.
Press the shutter button.
The Erase All icon starts to blink.
Press the shutter button again and all the stored picture
and AVI Movie are cleared.
Erase All
Erase all still pictures Erase all AVI Movie
H0
Blinking number indicates that the data is being
processed.
H0
Press the mode button to leave Erase All mode.
English
