AGPtek S33B Manual de usuario

USER MANUAL

S33B Waterproof

Music Player

CONTENTS

01/07

08/13

14/21

22/29

30/35

36/41

English

Deutsch

Italiano

Español

Français

日本語

For detailed user manual, please visit:

http://www.agptek.com/support/download.html

Safety Warnings

Before using this product, read and follow all warnings and

instructions.

This product is not intended for use by children under

10-year-old. Young children should be properly supervised.

This product is intended for household use only and not for

commercial or industrial use.

No naked flame sources, such as lighted candles, should be

placed on the product.

Ventilation should not be impeded by covering ventilation

openings with items such as newspapers, table cloths,

curtains and the like.

Make sure the unit is adjusted to a stable position. Damage

caused by using this product in an unstable position or by

failure to follow any other warning or precaution contained

within this user manual will not be covered by warranty.

Brief View of Player

A. Outlook and Controls

1. Status LED: For charge / play status

2. 3.5mm Jack: Multi-Function;

:For Charge / PC Connection / Earphone set

3. button: To increase volume or play next song

4. button: To On / Off, Play / Pause, Reset

5. button: To decrease volume or play previous song

6. Rotatable Clip

B. About the provided water resistant in-ear earphone set

Precautions:

1.The earbuds seal your ears. Therefore, be aware that there is

a risk of damage to your ears or eardrums if strong

pressure is applied to the earbuds or the earbuds are

suddenly removed from your ears.

2.After use, be sure to take the earbuds off your ears gently.

3.Sound may become muffled if water gets inside the

earphone set.

4.If this happens, hold the earphones and pat it to remove the

water.

C. About player’s battery

S33B Player has an internal, non – user-replaceable

rechargeable lithium battery. For best results, the first time you

use the player, let it charging for about 1 ~ 2 hours or until the

charging“Status LED (1)”long light from blinking before you

use it.

1 Charging the Battery:

1.1 You can charge the Player’s battery in two ways;

1.2 Connect player to your computer. Or;

1.3 Use the 5V 500mA USB power charger.

(not included)

2 To Charge battery

2.1 Plug the 3.5mm jack plug of USB cable to the Player

multi-function earphone jack;

2.2 The “Status LED (1)” will light blinking, for every

second, it is in charging.

2.3 The“Status LED (1)”will long light when the battery

is fully charged.

2.4 Disconnect the USB cable when it is done.

D. Getting start player

1 Turn On / Off

1.1 Plug-in the earphone set into Player’s “3.5mm jack

(2)”.

1.2 Press and hold the “ (4) ” button for until the

“Status LED (1)” light On, the player is turning On

and the music will play in seconds automatically.

1.3 To Turn Off, press and hold the “ (4)” button until

“Status LED (1)” light Off.

2 Play / Pause Music

2.1 Press the“ (4)”button to pause the playing music,

2.2 Press the “ (4)” button again to resume.

2.3 If player is in pause state for 3 minutes, it will be

turned to Off automatically.

2.4 When press the “ (4)” button, if no music files are

stored in player ’s memory, the status LED blinking

fast for few seconds and the player will turn to Off

automatically.

3 Adjust Volume

3.1 Press and hold the “ (3) ” button to increase

volume level.

3.2 Press and hold the “ (5) ” button to decrease

volume level.

3.3 For hearing protection; a beep warning will be heard

from earphone every time you increase the volume

level and reach to the default setting level, which may

exceed 85dB. Press the “ (4)” button to accept the

warning then press and hold the “ (3)” button

again to increase the level until to maximum level.

4 Play Next / Previous Music

4.1 Press the “ (3)” button to select next music.

4.2 Press the “ (5)” button to select previous music.

5 Shuffle

5.1 During playback, quick press the “ (4)” twice to

activate the shuffle and the light will blink every 3

seconds.

5.2 Quick Press the “ (4)” twice again to deactivate

the shuffle and the light will blink every second.

E. Indicator light function

Playing Mode: LED light flashing once per second.

Pause Mode: LED light bright.

PC Connecting Mode: LED light blinking rapidly in data

transferring(Charging in background)

Recharging Mode: LED light blinking in every second.

Recharge complete: LED light will long light.

F. Reset the device

1. In some circumstances the device ’ s function may

hanging and need to reset. To reset the device;

2. To reset the device, press and hold the “ (4)” button

for 8 ~ 10 seconds, the player should turn off from

hanging.

3. After reset, press and hold the “ (4)” button to restart

the Player.

G. For Swimming

1. Make sure that you use only the provided water resistant

in-ear earphone set for swimming;

2. Choose the best fitting earbuds. There are different type

and size earbuds supplied inside the box;

3. You need to use seal earbuds on left and right earphones

and gently wear them in your ears;

4. When fitted correctly, you should be able to notice while

the player is not playing music that surrounding sounds

will be significantly muted.

5. Now plug the 3.5mm jack plug of earphone set into

Player earphone output for connection. Make sure it fit

the Player firmly.

6. The earbuds seal your ears. Therefore, be aware that

there is a risk of damage to your ears or eardrums if

strong pressure is applied to the earbuds or the earbuds

are suddenly removed from your ears. Due to this risk, do

not do vigorous exercise, dive into a swimming pool, etc.,

while wearing your Player.

H. Not use and exposure to seawater

S33B waterproof device, put you at ease, use in the rain

or under the hose flush and swimming pool water, but

please keep in mind that you’re not placing it exposed to

seawater, salt water or liquids (such as drinks).

Excessive or improper use of appliance may invalidate the

maintenance.

I. Troubleshooting

Play

cannot

turn ON

Check whether battery have enough energy.

No sound

is heard

Check whether Volume is set to “minimum”

and connect the earphone plugs firmly.

Check whether the earphone plug is dirty.

Corrupted WMA / MP3 may make a static

noise and the sound may cut off. Make sure

that the music files are not corrupted.

Check whether music files format are

support.

Download

music files

fail

Check whether player’s 3.5mm plug and/or

USB plug is connected properly.

Check whether driver is installed correctly.

Check whether the player’s memory is in full.

J. Specifications

Dimension 50.6mm (H) x 33.4mm (W) 25.5mm (D)

Weight 20.8g

PC Connection USB 2.0 (High Speed)

Internal Memory 8G(No expandable memory)

Power Source DC Input: DC 5V 500mA

Battery 115mAh Lithium-Polymer

Supports Music

Format

MP3 32kbps - 320kbps

WMA 32kbps - 384kbps

WAV IMA-ADP

PCM

32kbps - 384kbps

128kbps - 1536kbps

Earphone Output 2mW x 2 channels (at 32 Ohm)

Freq. Response 20Hz – 20,000Hz

SNR 80dB

Water Resistant IPX8 2 meters, 30 minutes

Operation

Temperature

0℃ - 40℃

If you have any questions about this product, please feel free

to contact us at support@agptek.com.

Für detaillierte Bedienungsanleitung besuchen Sie bitte:

http://www.agptek.com/support/download.html

Anleitung

A. Über die Taste

1. LED-Status: Aufladen/Abspielen-Status

2. 3.5mm Buchse: Multi-Funktionen: Aufladen, mit PC

verbinden, Kopfhörer Buchse

3. + Taste: Die Lautstärke+, Nächtes Lied

4. Taste: Ein/ Ausschalten, Anhalten/Abspielen, Reset

5. - Taste: Die Lautstärke-, Letztes Lied

6. Der Clip

B. Über die mitgelieferte wasserdichte In-Ear-Kopfhörer

Vorsichtsmaßnahmen:

1. Die Ohrhörer versiegeln die Ohren. Seien Sie bitte bewusst,

dass es eine Gefahr der Beschädigung Ihrer Ohren oder

Trommelfelle gibt, wenn stark auf die Ohrhörer drücken oder

die Ohrhörer plötzlich aus den Ohren entfernt werden.
