N5532A Sensor Module

User’s and Service Guide

for the Agilent N5531S and N5530S Measuring Receiver Systems

Manufacturing Part Number: N5532-90005

Supercedes Part Number N5532-90004

Printed in USA

November 2006

Notice

The information contained in this document is subject to change

without notice.

Agilent Technologies makes no warranty of any kind with regard to this

material, including but not limited to, the implied warranties of

merchantability and fitness for a particular purpose. Agilent

Technologies shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the furnishing,

performance, or use of this material.

The following safety symbols are used throughout this manual.

Familiarize yourself with the symbols and their meaning before

operating this equipment.

WARNING Warning denotes a hazard. It calls attention to a procedure

which, if not correctly performed or adhered to, could result in

injury or loss of life. Do not proceed beyond a warning note

until the indicated conditions are fully understood and met.

CAUTION Caution denotes a hazard. It calls attention to a procedure that, if not

correctly performed or adhered to, could result in damage to or

destruction of the instrument. Do not proceed beyond a caution sign

until the indicated conditions are fully understood and met.

NOTE Note calls out special information for the user’s attention. It provides

operational information or additional instructions of which the user

should be aware.

Warranty

This Agilent Technologies instrument product is warranted against

defects in material and workmanship for a period of one year from date

of shipment. During the warranty period, Agilent Technologies will, at

its option, either repair or replace products that prove to be defective.

For warranty service or repair, this product must be returned to a

service facility designated by Agilent Technologies. Buyer shall prepay

shipping charges to Agilent Technologies and Agilent Technologies shall

pay shipping charges to return the product to Buyer. However, Buyer

shall pay all shipping charges, duties, and taxes for products returned

to Agilent Technologies from another country.

Contents

Table of Contents

1. General Information

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

N5532A Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Instruments Covered by Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2. Installation

Initial Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Installing the Calibration Factors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Installing the Cal Factors in the N5530S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Installing the Cal Factors in the N5531S, N5530SE26, and N5530SE50 . . . . . . . . . . . . . . 13

3. Specifications

N5532A Sensor Module Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

N5532A Sensor Module Supplemental Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4. Maintenance and Repair

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Power sensor replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Disassembly Hints for Options 504, 518, and 526 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Re-assembly Hints for Options 504, 518, and 526 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Disassembly Hints for Option 550 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Re-assembly Hints for Option 550 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Replaceable Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Cal Factor Data File Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Contacting Agilent Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Contents

Table of Contents

General Information

1General Information

This user guide contains information about installation, operation,

product specifications, calibration data, maintenance and repair, and

storage conditions of the N5532A Sensor Module.

6Chapter 1

General Information

Description

General Information

Description

The N5532A is intended to be used with the N5531S or N5530S

Measuring Receiver System. It is essentially a power sensor with a

power splitter at the input. See Figure 1-1 on page 7. In use, the sensor

module's two output cables are connected to a power meter (E4418/19,

E4416/17, or N1911/12 Series) and the Performance Spectrum Analyzer

(PSA) RF Input. When using an N1911 or N1912 Series power meter, it

is necessary to use an adapter (N5532A Option 019) to connect the

output cable of the sensor module to the power meter. The sensor

module is calibrated such that the power meter indicates the power

supplied by the source under test.

The N5532A Sensor Module is offered in four frequency configurations:

• Option 504 covers 100 kHz to 4.2 GHz

• Option 518 covers 10 MHz to 18 GHz

• Option 526 covers 30 MHz to 26.5 GHz

• Option 550 covers 30 MHz to 50 GHz

(with adaptor 11903D 2.4mm(f) to Type N(m))

The sensor module accurately measures power levels from -20 dBm to

+30 dBm (10 µW to 1 W). Calibration Factor (Cal Factor) information is

unique to each sensor module and is supplied on a floppy disc included

with each N5532A. Please refer to “Installing the Calibration Factors”

on page 2-12 for more information on using the Cal Factor Data.

Chapter 1 7

General Information

Description

General Information

NOTE The N5532A Sensor Module is compatible ONLY with the newer

E4418/19, E4416/17, or N1911/12 Series power meters. They are NOT

compatible with the earlier 430 Series or 70100 power meters. If used

with an N1911/12 Series power meter, an adapter (N5532A Option 019)

is required to connect the dc cable to the power meter.

N5532A Block Diagram

Figure 1-1 N5532A Sensor Module

8Chapter 1

General Information

Instruments Covered by Manual

General Information

Instruments Covered by Manual

These instruments have a two-part serial number: the prefix (two

letters and the first four numbers), and the suffix (the last four

numbers). The two letters identify the country in which the unit was

manufactured. The four numbers of the prefix are a code identifying the

date of the last major design change incorporated in your Agilent

Technologies product. The four-digit suffix is a sequential number and

coupled with the prefix, provides a unique identification for each unit

produced. The contents of this manual apply directly to all serial

numbers unless otherwise indicated.

Installation

2Installation
