Agilent N2757A GPIB Interface Module
Publication number N2757-92001
Printed June 2000
$
© Copyright Agilent echnologies 2000
All Rights Reserved
Installation Guide
2
Introduction
he Agilent N2757A GPIB Interface Module provides remote
communication with fast data transfers and full programmability for the
following Agilent 54600-series Oscilloscopes:
54621A Oscilloscope
54621D Mixed-Signal Oscilloscope
54622A Oscilloscope
54622D Mixed-Signal Oscilloscope
54624A Oscilloscope
he GPIB port can be used for remote programming and to link your pc
to the oscilloscope when using the BenchLink XL 54600 connectivity
software. For programming specifics, refer to the 54600-series
Oscilloscope Programmer’s Guide shipped with your oscilloscope. For
connectivity, refer to the BenchLink XL 54600 software for complete
instructions.
he following are recommended GPIB cards you can purchase for your
pc.
Part number Description
82341C High-Performance GPIB Interface for Windows 3.1/95/98/NT
82341D High-Performance plug&play GPIB Interface for Windows 95/98
82350A PCI High-Performance GPIB Interface Card for Windows 95/98/NT
3
Installation Guide
To install the interface module
To install the interface module
1Turn the oscilloscope power off.
2Insert the ta s on top of the module into the holes on the ack of the
oscilloscope as shown elow.
3Push the module down until the connector-aligning ta on the ack of
the module snaps into the alignment slot on the ack of the oscilloscope.
4Secure the module to the oscilloscope using the screw on the module.
QPFGU
Tabs
Screw
Alignment slot
4
Installation Guide
To connect the GPIB cable
To connect the GPIB ca le
Connect your GPIB cable to the GPIB module and to your pc/controller. he
following list shows recommended GPIB interface cables.
If you need additional clearance between the GPIB socket on the pc GPIB
interface card and the pc chassis you can purchase the 10834A GPIB adapter.
Part Number Cable length
10833A 1 meter
10833B 2 meters
10833D 0.5 meter
RFI shielding
The 10833 cables feature an improved shielding design to help reduce RFI levels in
systems. To further reduce RFI levels, the interface module is shipped with a clip-on
ferrite bead that you can attach to your GPIB cable. Lay the ferrite bead under the
GPIB cable as shown below, then snap the two halves of the ferrite bead together.
The ferrite bead should be attached as close to the interface module connection as
possible.
Note: shape of ferrite
bead may vary from
that pictured
5
Installation Guide
To verify the module is properly connected
To verify the module is properly connected
1Turn the oscilloscope power on.
2Press the oscilloscope Utility key, then press the Service softkey.
3Press the About Oscilloscope softkey.
he Option Module: line should display as shown below.
Service softkey
About Oscilloscope
softkey
6
Installation Guide
To set the GPIB address
To set the GPIB address
1Turn the oscilloscope power on.
2Press the oscilloscope Utility key, then press the I/O softkey.
3Press the Controller softkey and select GPIB.
4Turn the Entry kno to set the GPIB address. The selected address is
displayed in the Address softkey.
IO softkey
used for
RS-232 only Address
softkey
Controller
softkey
DECLARATION OF CONFORMITY
According to ISO/IEC Guide 22 and CEN//CENELEC EN 45014
Manufacturer’s Name: Agilent Technologies, Inc. / Digital Design PGU
Manufacturer’s Address: 1900 Garden of the Gods Road
Colorado Springs, CO 80907, U.S.A.
Declares, that the product
Product Name: Digitizing Oscilloscope Module
Model Number(s): N2757A
Product Option(s): This declaration covers all options of the above products(s)
Conforms to the following product standards:
EMC Standard Limit
IEC 61326-1:1997+A1:1998 / EN 61326-1:1997+A1:1998
CISPR 11:1990 / EN 55011:1991 Group 1, Class A [1]
IEC 61000-4-2:1995+A1:1998 / EN 61000-4-2:1995 4 kV CD, 8 kV AD
IEC 61000-4-3:1995 / EN 61000-4-3:1995 3 V/m, 80-1000 MHz
IEC 61000-4-4:1995 / EN 61000-4-4:1995 0.5 kV signal lines, 1 kV power Lines
IEC 61000-4-6:1996 / EN 61000-4-6:1996 3 V, 0.15-80 MHz
Canada: ICES-001:1998
Safety IEC 61010-1:1990+A1:1992+A2:1995 / EN 61010-1:1994+A2:1995
Canada: CSA C22.2 No. 1010:1:1992
Conformity / Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and
the EMC Directive 89/336/EEC (including 93/68/EEC) and carries the CE-marking accordingly
(European Union)
[1] The product was tested in a typical configuration with Agilent Technologies test systems.
Date: 05/02/2000
For further information, please contact your local Agilent Technologies sales office, agent, or distributor.
Name
Ken Wyatt, Product Regulations Manager
Agilent echnologies
P.O. Box 2197
1900 Garden of the Gods Road
Colorado Springs, CO 80901
© Copyright Agilent
echnologies 2000
All Rights Reserved.
Reproduction, adaptation,
or translation without prior
written permission is
prohibited, except as
allowed under the copyright
laws.
Restricted Rights
Legend.
Use, duplication or
disclosure by the U.S.
Government is subject to
restrictions as set forth in
subparagraph (c) (1) (ii) of
the Rights in echnical Data
and Computer Software
clause at DFARS 252.227-
7013 for DOD agencies, and
subparagraphs (c) (1) and
(c) (2) of the Commercial
Computer Software
Restricted Rights clause at
FAR 52.227-19 for other
agencies.
Agilent echnologies
3000 Hanover Street
Palo Alto, California 94304
U.S.A.
Document Warranty
he information contained
in this document is subject
to change without notice.
Agilent Technologies
makes no warranty of
any kind with regard to
this material including
but not limited to the
implied warranties of
merchantability or
fitness for a particular
purpose.
Agilent echnologies shall
not be liable for errors
contained herein or for
damages in connection with
the furnishing,
performance, or use of this
material.
Product Warranty
his Agilent echnologies
product has a warranty
against defects in material
and workmanship for a
period of 90 days from date
of shipment. During the
warranty period, Agilent
echnologies will, at its
option, either repair or
replace products that prove
to be defective.
For warranty service or
repair, this product must be
returned to a service facility
designated by Agilent
echnologies.
For products returned to
Agilent echnologies for
warranty service, the Buyer
shall prepay shipping
charges to Agilent
echnologies and Agilent
echnologies shall pay
shipping charges to return
the product to the Buyer.
However, the Buyer shall
pay all shipping charges,
duties, and taxes for
products returned to
Agilent echnologies from
another country.
Agilent echnologies
warrants that its software
and firmware designated by
Agilent echnologies for
use with an instrument will
execute its programming
instructions when properly
installed on that
instrument. Agilent
echnologies does not
warrant that the operation
of the instrument software,
or firmware will be
uninterrupted or error free.
Limitation of Warranty
he foregoing warranty
shall not apply to defects
resulting from improper or
inadequate maintenance by
the Buyer, Buyer-supplied
software or interfacing,
unauthorized modification
or misuse, operation outside
of the environmental
specifications for the
product, or improper site
preparation or
maintenance.
No other warranty is
expressed or implied.
Agilent Technologies
specifically disclaims the
implied warranties of
merchantability or
fitness for a particular
purpose.
Exclusive Remedies
he remedies provided
herein are the buyer’s sole
and exclusive remedies.
Agilent echnologies shall
not be liable for any direct,
indirect, special, incidental,
or consequential damages,
whether based on contract,
tort, or any other legal
theory.
Assistance
Product maintenance
agreements and other
customer assistance
agreements are available for
Agilent echnologies
products.
For any assistance, contact
your nearest Agilent
echnologies Sales Office.
Certification
Agilent echnologies
certifies that this product
met its published
specifications at the time of
shipment from the factory.
Agilent echnologies
further certifies that its
calibration measurements
are traceable to the United
States National Institute of
Standards and echnology,
to the extent allowed by the
Institute’s calibration
facility, and to the
calibration facilities of other
International Standards
Organization members.
Safety
his apparatus has been
designed and tested in
accordance with IEC
Publication 1010, Safety
Requirements for
Measuring Apparatus, and
has been supplied in a safe
condition. o ensure safe
operation and to keep the
