AGFA HEALTHCARE

DICOM Conformance Statement

"Workstation NX 2.0"

Status : Released

Revision 2.0

NodeID Livelink : 14140190

HE/001132 Page 2of 92

Document No. 001132, Revision 2.0

Agfa HealthCare NodeID Livelink : 14140190 14 June, 2007

Document Information

Service-related contact

information worldwide

All service-related contact information

is available on this URLà

http://www.agfa.com/en/he/support/support_service/index.jsp

Issued by:

Agfa HealthCare

SIV Connectivity

Septestraat 27

B-2640 Mortsel

Belgium

Agfa shall not be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing, performance

or use of this publication. Agfa reserves the right to revise this

publication and to make changes to its content at any time, without

obligation to notify any person or entity of such revisions and changes.

This publication may only be used in connection with the promotion,

sales, installation and use of Agfa equipment.

tel: 32.3.444.7338

email: [email protected]

Agfa HealthCare

HE/001132 Page 3of 92

Document No.001132, Revision 2.0

NodeID Livelink : 14140190

Agfa HealthCare 14 June, 2007

Conformance Statement Overview

"Workstation", implements the necessary DICOM services to facilitate receiving of unprocessed CR images

from an AGFA Digitizer, performing image processing and sending the processed images to a remote

storage or print device over a Medical Imaging Systems network. "Workstation" may also acquire patient

information from a Radiology Information System (RIS) for use in identifying processed images.

The table below provides an overview of the network services supported by "Workstation"

Table 1.1-1: Network Services Supported

SOP Classes User of Service (SCU) Provider of Service (SCP)

Transfer

Computed Radiography Image Storage Option No

Digital X-Ray Image Storage –For Presentation Option No

Digital X-Ray Image Storage –For Processing Option No

Grayscale Softcopy Presentation State Storage SOP Class Option No

Digital Mammography Image Storage –For Presentation Option No

Digital Mammography Image Storage –For Processing Option No

Workflow Management

Storage Commitment Push Model SOP Class Option No

Modality Performed Procedure Step SOP Class Option No

Modality Worklist Information Model –FIND Option No

Print Management

Basic Grayscale Print Management Meta SOP Class Option No

Basic Film Session SOP Class Option No

Basic Film Box SOP Class Option No

Basic Grayscale Image Box SOP Class Option No

Printer SOP Class Option No

Print Job SOP Class Option No

Presentation LUT SOP Class Option No

"Workstation" does support Media Services.

Table 1.1-2: Media Services Supported

Media Storage Application Profile Write Files (FSC or FSU) Read Files (FSR)

Compact Disk -Recordable

General Purpose CD-R Yes No

HE/001132 Page 4of 92

Document No. 001132, Revision 2.0

Agfa HealthCare NodeID Livelink : 14140190 14 June, 2007

Table of Contents
