Advantech PCI-1713 Manual de usuario

PCI-1713

32-ch Isolated Analog Input Card

User Manual

PCI-1713 User Manual ii

The documentation and the software included with this product are copy-

righted 2006 by Advantech Co., Ltd. All rights are reserved. Advantech

Co., Ltd. reserves the right to make improvements in the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd.

Information provided in this manual is intended to be accurate and reli-

able. However, Advantech Co., Ltd. assumes no responsibility for its use,

nor for any infringements of the rights of third parties, which may result

from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of

Microsoft Corp.

All other product names or trademarks are properties of their respective

owners.

Part No. 2003171300 2nd Edition

Printed in Taiwan January 2006

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any

onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows

us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for war-

ranty service.

5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

PCI-1713 User Manual iv

Declaration of Conformity

This product has passed the CE test for environmental specifications

when shielded cables are used for external wiring. We recommend the use

of shielded cables. This kind of cable is available from Advantech. Please

contact your local supplier for ordering information.

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning.

Use a damp cloth. Do not use liquid or spray detergents for clean-

ing.

4. For plug-in equipment, the power outlet socket must be located

near the equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Drop-

ping it or letting it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before con-

necting the equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not

place anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the

power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or elec-

trical shock.

13. Never open the equipment. For safety reasons, the equipment

should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked

by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work

according to the user's manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

WHERE THE STORAGE TEMPERATURE MAY GO BELOW -

PCI-1713 User Manual vi

20° C (-4° F) OR ABOVE 60° C (140° F). THIS COULD DAM-

AGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A

CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS

INCORRECTLY REPLACED. REPLACE ONLY WITH THE

SAME OR EQUIVALENT TYPE RECOMMENDED BY THE

MANUFACTURER, DISCARD USED BATTERIES ACCORD-

ING TO THE MANUFACTURER'S INSTRUCTIONS.

The sound pressure level at the operator's position according to IEC 704-

1:1982 is no more than 70 dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1.

Advantech disclaims all responsibility for the accuracy of any statements

contained herein.

vii Table of Contents

Contents

Chapter 1 Overview .......................................................... 2

1.1 Introduction ....................................................................... 2

1.2 Features ............................................................................. 3

1.3 Specifications .................................................................... 3

1.4 Block Diagram .................................................................. 5

Chapter 2 Installation ....................................................... 8

2.1 Initial Inspection................................................................ 8

2.2 Unpacking ......................................................................... 8

2.3 Installation Instructions ..................................................... 9

Chapter 3 Signal Connections ........................................ 12

3.1 Overview ......................................................................... 12

3.2 I/O Connector.................................................................. 12

Figure 3.1:I/O Connector Pin Assignments ................. 13

3.3 Analog Input Connections............................................... 14

Figure 3.2:Single-ended Input Ch. ............................... 14

Figure 3.3:Differential Input Ch. - Grounded .............. 15

Figure 3.4:Differential Input Ch. - Floating ................ 16

3.4 Field Wiring Considerations ........................................... 17

Chapter 4 Calibration ..................................................... 20

4.1 Introduction ..................................................................... 20

4.2 VR Assignments.............................................................. 20

Figure 4.1:PCL-1713 VR Assignments ....................... 20

4.3 A/D Calibration ............................................................... 21

PCI-1713 User Manual viii

CHAPTER

Overview

Sections include:

• Introduction

• Features

• Specifications

• Block Diagram

PCI-1713 User Manual 2

Chapter 1 Overview

1.1 Introduction

The PCI-1713 is a 12-bit 32-channel analog input card for the PCI bus. It

provides 32 analog input channels with a sampling rate up to 100k sam-

ples/s, 12-bit resolution and isolation protection of 2500 VDC.

PCI-bus Plug and Play

The PCI-1713 uses a PCI controller to interface the card with the PCI bus.

The controller fully implements the PCI bus specification Rev 2.1. All

bus relative configurations, such as base address and interrupt assign-

ment, are automatically controlled by software.

Flexible Input Types and Range Settings

The PCI-1713 features an automatic channel/gain scanning circuit. The

circuit, rather than your software, controls multiplexer switching during

sampling. The on-board SRAM stores different gain values and configu-

rations for each channel. This design lets you perform multi-channel

sampling with different gains for each channel and with free combination

of single-ended and differential inputs.

High-speed Data Acquisition

The PCI-1713 provides a sampling rate up to 100k samples/s. It has an

on-board FIFO buffer, which can store up to 4K A/D samples and gener-

ates an interrupt signal when the FIFO is half full. This feature provides

continuous high-speed data transfer and more predictable performance on

Windows systems.

Supports S/W, Internal and External Pacer Triggering

The PCI-1713 supports three kinds of trigger modes for A/D conversion:

software triggering, internal pacer triggering and external pacer trigger-

ing. The software trigger allows users to acquire a sample when it is

needed; the internal pacer triggers continuous high-speed data acquisi-

tion. The PCI-1713 also accepts external trigger sources, allowing syn-

chronous sampling with external devices.
