ADTRAN SMART/RG SR905ac Manual de usuario

/ Gateway User Manual

Model: SR905ac

Release: 2.2 January 2021

Software Version: 10.8.8.1

501 SE Columbia Shores Boulevard, Suite 500

Vancouver, Washington 98661 USA

+1 360 859 1780 / smartrg.com

Table of Contents

Welcome! 4

Purpose & Scope 4

Intended Audience 4

Getting Assistance 4

Disclaimer 4

Important Safety Instructions 5

WEEE Statement 5

Importantes Mesures de Sécurité 6

DEEE Statement 6

Getting Familiar with your Gateway 7

LED Indicators 7

Connections 8

LAN 8

WAN 8

USB 1 & 2 8

POWER 8

External Buttons 8

WPS Button (5 GHz Band) 9

WiFi Button (2.4 GHz Band) 9

On/Off Button 9

Reset Button 9

Installing your SR905ac Gateway 10

Logging in to the SR905ac Interface 11

User Preferences 12

Saving Your Changes 13

Dashboard 14

Network 15

Status 15

Ethernet WAN 16

Internet 17

DHCP for IPv4 WANs 17

Static Address for IPv4 WANs 18

PPPoE for IPv4 WANs 19

DHCPv6 for IPv6 WANs 20

Static Address for IPv6 WANs 21

IPTV 21

Voice 23

Management 24

Cross-Connect 26

SFP 27

LAN Network 28

DHCP Server 29

Defining a Custom DNS Server 31

Defining a Static DHCP IP Address 32

DHCP Clients 33

Ethernet Ports 34

Guest Network 34

DHCP Server 36

Defining a Static DHCP IP Address 38

DHCP Clients 39

Video Network 40

Static 40

DHCP 41

DHCP Server 42

Defining a Static DHCP IP Address 43

DHCP Clients 45

Multicast 45

Video Analyzer 46

Routing 47

Static Routes 48

DNS 50

Advanced 51

Downstream QoS 51

Firewall 53

Router Access 54

Rules 55

DMZ 58

Port Forwarding 58

WiFi 61

Status 61

Scan 61

Radios 62

Band Steering 64

Networks 64

Mesh 66

Clients 67

MAC Filtering 68

Advanced 70

Devices 71

Intellifi Devices 71

Accessing Device Information 72

Viewing Device Details 72

Viewing Connection Details 73

Pausing Internet Access 74

Connected Devices 74

Device Groups 76

Access Schedule 80

Services 84

UPNP 84

DLNA 85

TR-069 Configuration 85

SNMP 87

Hosts 89

DDNS 90

Cloud Storage 92

File Sharing 92

Content Filter 94

Admin 96

Update 96

Configuration 97

Router Management 99

Passwords 101

Net Tools 102

Event Log 104

Configuring Log Settings 105

Time 106

Operating Mode 106

Table of Contents

Reboot 107

Logging out 109

Appendix: Compliance Statements 110

FCC Interference Statement 110

FCC Radiation Exposure Statement 110

5GHz 110

Revision History 111

Welcome!

Thank you for purchasing this SmartRG product.

SmartRG offers solutions that simplify the complex Internet ecosystem. Our solutions include hardware, software, applications,

enhanced network insights, and security delivered via a future-proof operating system. Based in the USA, SmartRG provides local,

proactive software development and customer support. We proudly offer the best, most innovative broadband gateways available.

Learn more at www.SmartRG.com.

Purpose & Scope

This User Manual provides SmartRG customers with installation, configuration and monitoring information for their SR905ac gateway.

Intended Audience

The information in this document is intended for Network Architects, NOC Administrators, Field Service Technicians and other

networking professionals responsible for deploying and managing broadband access networks. Readers of this manual are assumed to

have a basic understanding of computer operating systems, networking concepts and telecommunications.

Getting Assistance

The ADTRAN Support Community provides how-to information, forums, documentation and software downloads.

lSubscribers: If you require further help with this product, please contact your service provider.

lService providers: if you require further help with this product, please open a support request.

The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system,

translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical,

photocopying, manual, or otherwise, without the prior written permission of SmartRG, Inc.

Disclaimer

SmartRG does not assume any liability arising out of the application or use of any products, or software described herein. Neither

does it convey any license under its patent rights nor patent rights of others. SmartRG further reserves the right to make changes to

any products described herein without notice. This publication is subject to change without notice.

Any trademarks mentioned in this publication are used for identification purposes only and may be properties of their respective

owners.

Important Safety Instructions

When using your telecommunications equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and

injury to persons, including the following:

1. Use only the power adaptor that is included with the device.

2. Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement or near

a swimming pool.

3. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from

lightning.

4. Do not use the telephone to report a gas leak in the vicinity of the leak.

5. CAUTION - To Reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

The socket-outlet shall be installed near the equipment and shall be easily accessible.

WEEE Statement

The WEEE logo (shown at the left) appears on the product to indicate that this product must not be disposed of or dumped with your other

household wastes. You are required to dispose of your electronic or electrical waste equipment by delivering it to the specified collection

point for recycling of such hazardous waste.

Importantes Mesures de Sécurité

tre prises pendant l’utilisation de matérial télécommunications afin de réduire les risques d’incendie, de choc électrique Certaines mesures de

sécurité doivent et de blessures. En voici quelquesunes:

1. Utilisez uniquement l'adaptateur secteur fourni avec l'appareil.

2. Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à laver, dans un sous-sol

humide ou près d’une piscine.

3. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans fil) pendant un orage électrique. Ceci peut présenter un risque de choc

électrique causé par la foudre.

4. Ne pas utiliser l’appareil téléphonique pour signaler une fuite de gaz s’il est situé près de la fuite.

5. ATTENTION - Pour réduire les risques d’incendie, utiliser uniquement des conducteurs de télécommunications 26 AWG au de section

supérleure.

le socle de prise de courant doit être installé à proximité du matériel et doit être aisément accessible.

DEEE Statement

Le logo DEEE (illustré à gauche) apparaît sur le produit pour indiquer que ce produit ne doit pas être jeté ou jeté avec vos autres déchets

ménagers. Vous êtes tenu de vous débarrasser de vos déchets d'équipements électroniques ou électriques en les livrant au point de

collecte spécifié pour le recyclage de ces déchets dangereux.

Getting Familiar with your Gateway

This section explains the SR905ac gateway's lights, ports, and buttons.

LED Indicators

Your SR905ac gateway has several status indicators (LEDs)

on its top which are described below.

Legend: White White blinking Green Green blinking Red

LED Action Explanation

Power Device in CFE mode

Device powered on and ready for use

Internet Data being transferred

Internet authentication / connection has failed

Lan 1-4 LAN Ethernet connected (at 1000 BASE-T)

Data being transferred (at 1000 BASE-T)

LAN Ethernet connected (at 10/100BASE-T)

Data being transferred (at 10/100BASE-T)

WAN Device online (at 1000 BASE-T)

Device online (at 10/100 BASE-T)

WAN Ethernet connected (at 1000 BASE-T)

Data being transferred (at 1000 BASE-T)

WAN Ethernet connected (at 10/100BASE-T)

Data being transferred (at 10/100BASE-T)

2.4 GHz

5 GHz

WiFi enabled

Data being transferred

(locked WiFi / WPS)

WPS enabled

Data being transferred

SS 1 & 2 USB 3.0 device connected

Data being transferred

SFP SFP (fiber optic) connected

Data being transferred

Connections

The SR905ac's exterior ports are shown in the following cabling diagram and explained below.

USB

LAN

WAN DC/

POWER

SFP

LAN

The four yellow RJ45 Ethernet ports located on the back of the gateway (labelled LAN1, LAN2, LAN3, LAN4) are used to connect

client devices such as computers and printers.

WAN

The red RJ45 port labeled WAN is used to connect the SR905ac gateway to another network device using a RJ45/Ethernet cable.

USB 1 & 2

Two USB ports (two 3.0 ports on back) are used to connect USB storage devices to the gateway for transferring data. They also

provide +5 VDC for charging other devices.

POWER

lUse ONLY the dedicated power supply included with your gateway (3-amp 12 v). Intended for indoor use only.

lDo NOT open the device. Opening or removing covers can expose dangerous high voltage points or other risks. ONLY qualified

service personnel can service the device. Please contact your vendor for further information.

External Buttons

The SR905ac gateway provides push-button controls on its exterior for critical features. These buttons provide a convenient means

to trigger WPS mode, toggle the WiFi radios on and off, or reset the gateway. The button functions are described below.

WPS Button (5 GHz Band)

WiFi Protected Setup™ (WPS) is a standard means for creating secure connections between the gateway and various wireless client

devices. It is designed to simplify the pairing process between devices. Thisbutton is located on the left side of the gateway.

Press this button for 1-3 seconds, the 5 GHz LED starts to flash. If no client pairs with the gateway after 2 minutes, the 5 GHz LED

turns off. When the gateway pairs successfully with a client, the 5 GHz LED glows solid for 5 minutes and then turns off.

WiFi Button (2.4 GHz Band)

The WiFi button toggles the 2.4 GHz WiFi radio on and off. This button is located on the left side of the gateway. Look at the 2.4 GHz

LED indicator to determine the current state of the WiFi radio.

To activate the radio, press and hold the WiFi button for 3-5 seconds then release. Expect a 1-3 second delay before the 2.4 GHz

LED turns on. The WiFi radio is now on.

To deactivate the radio, press and hold the WiFi button for 3-5 seconds then release. Expect a 1-3 second delay before the 2.4 GHz

LED turns off. The WiFi radio is now off.

On/Off Button

The On/Off button turns the gateway on and off. This button is located on the left side of the gateway.

Reset Button

Warning: Do not press the Reset button unless you want to clear the current settings.

The Reset button returns the gateway to its default settings. This button is in a small circular hole in the back of the gateway with

the actual button mounted behind the surface. This style of push button prevents the gateway from being inadvertently reset

during handling.

To restore the current default settings, insert a thin wire (such as a paper clip) into the hole, press for 1 second, then release the

button. The gateway reboots and returns to the current defaults.

To return the gateway to factory default settings, press the Reset button until the LEDs flash red and orange. The gateway reboots

and returns to the default settings applied in the factory. This process may take a few minutes.

Installing your SR905ac Gateway

1. Connect the gateway to incoming services:

lFor Ethernet services, connect one end of an Ethernet cable to the WAN port on the gateway and connect the other

end of the cable to the wall jack installed by your provider.

lFor fiber services:

a. Slide open the small door at the right end of the gateway's back.

b. Insert the SFP transceiver (included with the gateway) into the port.

c. Connect one end of the fiber cable to the SFP transceiver and connect the other end of the cable to the wall

jack installed by your provider.

2. Connect a LAN port on the gateway to your PC using an Ethernet cable.

3. Plug the power adapter to the wall outlet and then connect the other end of it to the Power port of the gateway.

4. Turn on the unit by pressing the Power button on the side of the gateway.

The gateway is now automatically being set up to connect to the Internet. This process may take a few minutes to complete before

you can begin using your Internet applications (browser, email, etc.).

If connection to the Internet is unsuccessful, verify that all cable connections are in place and the gateway’s power is turned on.

Tabla de contenidos

Otros manuales de Puerta de ADTRAN

ADTRAN

ADTRAN Pseudowire Gateway MX408e Manual de usuario

ADTRAN

ADTRAN SDG-ST1 Manual de usuario

ADTRAN

ADTRAN NetVanta 1355 Manual de usuario

ADTRAN

ADTRAN SmartRG SR400ac Manual de usuario

ADTRAN

ADTRAN SMART/RG SR516ac Manual de usuario

ADTRAN

ADTRAN 825-v6 Manual del propietario

ADTRAN

ADTRAN 7310-8 Manual de usuario

ADTRAN

ADTRAN SR905acv Manual de usuario

ADTRAN

ADTRAN jobAid+ Total Access 324 Manual de usuario

ADTRAN

ADTRAN 17600072F1S Manual de usuario

ADTRAN

ADTRAN 324RG Manual de usuario

ADTRAN

ADTRAN NetVanta 3140 Desktop Manual de usuario

ADTRAN

ADTRAN SmartRG SR400ac Manual de usuario

ADTRAN

ADTRAN SDX810-RG Manual de usuario

ADTRAN

ADTRAN Type 400 Manual de usuario

ADTRAN

ADTRAN NetVanta 6240 Series Manual de usuario

ADTRAN

ADTRAN Total Access 900 Series Manual

ADTRAN

ADTRAN 6304W Manual de usuario

ADTRAN

ADTRAN jobAid 424RG3 Manual de usuario

ADTRAN

ADTRAN 434 RG Manual de usuario

ADTRAN

ADTRAN NetVanta 6360 Manual

ADTRAN

ADTRAN NetVanta 6310 Manual de usuario

ADTRAN

ADTRAN NetVanta 1355 Manual de usuario

ADTRAN

ADTRAN Total Access 912 Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
