ADLINK Technology CPCIS-6400U Series Manual de usuario

Advance Technologies; Automate the World.

Manual Rev. 2.01

Revision Date: December 21, 2006

Part No: 50-15044-2000

cPCIS-6400U/6400X

Series

4U Height Subsystem for

6U cPCI and Components

User’s Manual

The information in this document is subject to change without prior

notice in order to improve reliability, design, and function and does

not represent a commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, spe-

cial, incidental, or consequential damages arising out of the use or

inability to use the product or documentation, even if advised of

the possibility of such damages.

This document contains proprietary information protected by copy-

right. All rights are reserved. No part of this manual may be repro-

duced by any mechanical, electronic, or other means in any form

without prior written permission of the manufacturer.

Trademarks

Product names mentioned herein are used for identification pur-

poses only and may be trademarks and/or registered trademarks

of their respective companies.

Getting Service from ADLINK

Customer Satisfaction is top priority for ADLINK Technology Inc.

Please contact us should you require any service or assistance.

ADLINK TECHNOLOGY INC.

Web Site: http://www.adlinktech.com

Sales & Service: [email protected]om

TEL: +886-2-82265877

FAX: +886-2-82265717

Address: 9F, No. 166, Jian Yi Road, Chungho City,

Taipei, 235 Taiwan

Please email or FAX this completed service form for prompt and

satisfactory service.

Company Information

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL FAX:

Web Site

Product Information

Product Model

Environment

OS:

M/B: CPU:

Chipset: BIOS:

Please give a detailed description of the problem(s):

Table of Contents i

Table of Contents

List of Figures ........................................................................ iii

1 Introduction ........................................................................ 1

1.1 Features............................................................................... 1

General ........................................................................... 1

Boards Space ................................................................. 2

CompactPCI Compliancy ................................................ 2

Enclosure ........................................................................ 2

1.2 Specifications....................................................................... 3

1.3 Mechanical Layout............................................................... 4

cPCIS-6400U Series (redundant PSU) ........................... 4

cPCIS-6400X Series (ATX PSU) .................................... 5

1.4 Compatible CPU Modules ................................................... 7

1.5 Customized Systems ........................................................... 7

2 Getting Started ................................................................... 9

2.1 Shipping Contents ............................................................... 9

2.2 CompactPCI Card Installation ............................................. 9

2.3 Rear Transition Module Installation/Removal .................... 11

2.4 Power Supply Unit Replacement

(cPCIS-6400U only)........................................ 12

2.5 Hard Drive Racks............................................................... 13

Hard Drive Installation Procedure ................................. 13

Rack Insertion And Removal ........................................ 14

2.6 Powering Up the System ................................................... 15

3 Backplanes ....................................................................... 17

3.1 cBP-6105R (32-bit/33MHz)................................................ 18

Features ....................................................................... 18

Specifications ................................................................ 18

Mechanical Drawing ..................................................... 19

Connector Pin Assignments ......................................... 20

Jumper Settings ............................................................ 33

3.2 cBP-6405R (64-bit/66MHz)................................................ 34

Features ....................................................................... 34

Specifications ................................................................ 34

Mechanical Drawing ..................................................... 35

Connector Pin Assignments ......................................... 36

Jumper Settings ............................................................ 48

ii Table of Contents

3.3 cBP-3063 CompactPCI Power Backplane......................... 49

Specifications ................................................................ 49

Mechanical Drawing ..................................................... 50

Connector Pin Assignments ......................................... 51

4 Cooling System................................................................. 55

4.1 System Alarm Board .......................................................... 56

4.2 Fan Alarm .......................................................................... 57

4.3 Fan Removal and Replacement Procedure

(cPCIS-6400U only)........................................ 57

4.4 Air Filter Replacement

(cPCIS-6400U only)........................................ 61

4.5 Temperature Alarm ............................................................ 63

4.6 Fan Specifications.............................................................. 63

5 Power Supply Unit ............................................................ 65

5.1 cPCIS-6400U: cPS-H325/AC............................................. 65

Features ........................................................................ 65

Specifications ................................................................ 65

Input Characteristics ..................................................... 66

Output Characteristics .................................................. 66

5.2 cPCIS-6400X: APS940XA ATX 400W............................... 68

Features ........................................................................ 68

Specifications ................................................................ 68

Input Characteristics ..................................................... 68

Output Characteristics .................................................. 69

Important Safety Instructions............................................... 71

Warranty Policy ..................................................................... 73

List of Figures iii

List of Figures

Figure 1-1: cPCIS-6400U Front View .......................................... 4

Figure 1-2: cPCIS-6400U Rear View ........................................... 4

Figure 1-3: cPCIS-6400X Front View........................................... 5

Figure 1-4: cPCIS-6400X Rear View ........................................... 5

Figure 1-5: cPCIS-6400 Series Top View .................................... 6

Figure 1-6: cPCIS-6400 Series Left Side View ............................ 6

Figure 2-1: Installing a 6U SBC module..................................... 10

Figure 2-2: Latching the cPCI module handles securely. .......... 11

Figure 2-3: Unlatch the PSU module handle ............................. 12

Figure 2-4: Pull outwards to remove the PSU............................ 13

Figure 2-5: Hard drive rack keylock positions ............................ 13

Figure 2-6: Remove the hard drive rack from the drive bay....... 14

Figure 2-7: cPCIS-6400U Series switches and LEDs................ 15

Figure 2-8: cPCIS-6400X Series switches and LEDs ................ 16

Figure 3-1: cBP-6105R Backplane Front View .......................... 19

Figure 3-2: cBP-6105R Backplane Rear View........................... 19

Figure 3-3: cBP-6405R Backplane Front View .......................... 35

Figure 3-4: cBP-6405R Backplane Rear View........................... 35

Figure 3-5: cBP-3063 Power Backplane Front View.................. 50

Figure 3-6: cBP-3063 Power Backplane Rear View .................. 50

Figure 4-1: System Alarm Board Mechanical Drawing .............. 56

Figure 4-2: Alarm LEDs and reset button .................................. 57

Figure 4-3: Remove the front-access intake fan module ........... 58

Figure 4-4: Remove the rear exhaust fan module (small).......... 59

Figure 4-5: Remove the rear exhaust fan module (PSU)........... 59

Figure 4-6: Disconnect the rear exhaust fan module (PSU) power ca-

ble............................................................................ 60

Figure 4-7: Remove the left-side exhaust fan module screws ... 60

Figure 4-8: Remove the left exhaust fan module and

disconnect the power cables .................................. 61

Figure 4-9: Air filter removal and replacement........................... 62

Introduction 1

1 Introduction

The cPCIS-6400U/6400X Series subsystems are designed for 6U

cPCI boards with 80mm RTMs. The chassis is 4U in height and

standard 19” rack mount width.

The cPCIS-6400U provides 2+1 hot swappable 500W+250W

redundant power supplies with universal AC input, while the

cPCIS-6400X has a built-in 400W AC-input ATX power supply

with cooling fan. Both series have PICMG 2.1 Hot Swap compliant

32/64-bit 5-slot CompactPCI backplanes and a PICMG 2.5 H.110

CT Bus.

1.1 Features

General

X19” rackmount, 4U height for 6U cPCI cards with 80mm rear

RTMs for I/O

XStandard 6U CompactPCI and optional PICMG 2.5 H.110

CT bus

XPICMG 2.1 Hot Swap compliant 32-bit/33MHz or

64-bit/66MHz 5-slot CompactPCI backplane with P3 & P5

rear I/O

X2+1 hot swappable 500W+250W redundant power supplies

with universal AC input (cPCIS-6400U)

XBuilt-in 400W AC-input ATX power supply (cPCIS-6400X)

XDual removable ATA-100 or SCSI 3.5” hard drive racks

(cPCIS-6400US and cPCIS-6400XS models are SCSI

equipped)

XFront drive bay space for one slim type EIDE CD-ROM and

one slim type floppy.

XOne front-access intake fan, two (three for cPCIS-6400U)

rear-access and four side exhaust fans are used for system

cooling. Air-filter is replaceable on front-access fan module.

(Only cPCIS-6400U fans support hot swap).

2Introduction

XGuarded power switch and reset button

XVoltage LEDs allow convenient monitoring: +12V, -12V,

+5V, +3.3V

XSuitable for both rackmount and benchtop applications

XBuilt-in alarm module to monitor chassis temperature, fan

status.

XComprehensive EMC shielding: EMC gaskets are installed

on top and bottom edges of both front and rear panel aper-

tures

Boards Space

XBoard space supports standard 6U height and 6-slot width

XOne 8HP system slot accommodates single or dual-slot

system boards.

XBoth front and rear access possible

CompactPCI Compliancy

XPICMG 2.0 R3.0 CompactPCI Core Specification

XPICMG 2.1 R2.0 CompactPCI Hot Swap

XPICMG 2.5 R1.0 CompactPCI Computer Telephony

XPICMG 2.9 R1.0 CompactPCI System Management

XPICMG 2.11 R1.0 CompactPCI Power Interface

(cPCIS-6400U only)

Enclosure

XEIA RS-310C 19” 4U high rackmount enclosure

XCoated metal plate outer covering

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de computadora de ADLINK Technology

ADLINK Technology

ADLINK Technology DLAP-211-JNX Series Manual de usuario

ADLINK Technology

ADLINK Technology VPX3-TL Series Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-6530 Series Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-A3525 Series Manual de usuario

ADLINK Technology

ADLINK Technology cPCIS-1100 Series Manual de usuario

ADLINK Technology

ADLINK Technology 6216-GL Series Manual de usuario

ADLINK Technology

ADLINK Technology ETX-BT Manual de usuario

ADLINK Technology

ADLINK Technology MCM-100 Manual de usuario

ADLINK Technology

ADLINK Technology PCIe-U30 Series Manual de usuario

ADLINK Technology

ADLINK Technology VPX3000 Series Manual de usuario

ADLINK Technology

ADLINK Technology NuDAQ ACL-8454 Manual de usuario

ADLINK Technology

ADLINK Technology COM Express cExpress-BL Manual de usuario

ADLINK Technology

ADLINK Technology NuPRO-840 DV Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-3630 Series Manual de usuario

ADLINK Technology

ADLINK Technology EOS-1200 Manual de usuario

ADLINK Technology

ADLINK Technology VPX3-TL Series Manual de usuario

ADLINK Technology

ADLINK Technology Com Express nanoX-BT Manual de usuario

ADLINK Technology

ADLINK Technology EBP-13E2 Manual de usuario

ADLINK Technology

ADLINK Technology arm AMPERE COM-HPC-ALT Manual de usuario

ADLINK Technology

ADLINK Technology ROScube-I Series Manual de usuario

ADLINK Technology

ADLINK Technology Q7-AL Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-8586 Manual de usuario

ADLINK Technology

ADLINK Technology DMI-1210 Manual de usuario

ADLINK Technology

ADLINK Technology LEC-BASE MINI Manual de uso y cuidado

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

ADLINK Technology cPCIS-6400U Series Manual de usuario

Manuales populares de Hardware de computadora de otras marcas
