ADC WorldDSL UTU-701C Manual de usuario

WorldDSL

QUICK INSTALLATION GUIDE

HDSL

G.703

SYNC

ALM

HDSL

I/F

LOCLPBK

V.24

REM

ALM

SYNC

ALM

HDSL

I/F

LPBK

LOC

REM

WorldDSL

UTU-701C List 1

Rate Selectable Line Unit

Part Number: 150-1422-01C

ETU-751C List 1

Rate Selectable Desktop Unit

Part Number: 150-1432-01C

700-701-900-02, Revision 02

ii June 5, 2002 UTU-701C and ETU-751C List 1

Revision History of This Guide

To order copies of this document, use document number 700-701-900-02,

Revision 02.

June 5, 2002

Trademark Information

ADC is a registered trademark and WorldDSL is a trademark of ADC

Telecommunications, Inc. No right, license, or interest to such trademarks is granted

hereunder, and you agree that no such right, license, or interest shall be asserted by

you with respect to such trademark.

Other product names mentioned in this document are used for identification purposes

only and may be trademarks or registered trademarks of their respective companies.

Disclaimer of Liability

Information contained in this document is company private to ADC DSL Systems, Inc.,

and shall not be modified, used, copied, reproduced or disclosed in whole or in part

without the written consent of ADC.

Contents herein are current as of the date of publication. ADC reserves the right to

change the contents without prior notice. In no event shall ADC be liable for any

damages resulting from loss of data, loss of use, or loss of profits, and ADC further

disclaims any and all liability for indirect, incidental, special, consequential or other

similar damages. This disclaimer of liability applies to all products, publications and

services during and after the warranty period.

Revision Release Date Revisions Made

1January 14, 2000 Initial release

2June 5, 2002 ADC rebranding

700-701-900-02, Revision 02 Using This Guide

UTU-701C and ETU-751C List 1 June 5, 2002 iii

USING THIS GUIDE

The following conventions are used in this guide:

•Monospace type indicates screen text.

•Keys you press are indicated by small icons such as or . Key

combinations to be pressed simultaneously are indicated with a plus sign

as follows: + .

•Items you select are in bold.

Three types of messages, identified by icons, appear in text.

UNPACK AND INSPECT YOUR SHIPMENT

Upon receipt of the equipment:

•Unpack each container and inspect the contents for signs of damage. If

the equipment has been damaged in transit, immediately report the extent

of damage to the transportation company and to ADC DSL Systems, Inc.

Order replacement equipment, if necessary.

•Check the packing list to ensure complete and accurate shipment of each

listed item. If the shipment is short or irregular, contact ADC DSL

Systems, Inc. as described in “Product Support” on page 23. If you must

store the equipment for a prolonged period, store the equipment in its

original container.

Notes contain information about special circumstances.

Cautions indicate the possibility of personal injury or

equipment damage.

Warnungszeichen deuten darauf hin, dass Schaden am Gerät

oder eine mögliche Körperverletzung riskiert wird, falls die

Warnungen nicht beachtet werden.

The Electrostatic Discharge (ESD) symbol indicates that a

deviceorassemblyissusceptibletodamagefromelectrostatic

discharge.

YENTER

CTRL ESC

Unpack and Inspect Your Shipment 700-701-900-02, Revision 02

iv June 5, 2002 UTU-701C and ETU-751C List 1

700-701-900-02, Revision 02 Table of Contents

UTU-701C and ETU-751C List 1 June 5, 2002 v

TABLE OF CONTENTS

Overview _______________________________________________ 1

Rate Selectable HDSL ............................................................. 1

UTU-701C Line Unit............................................................... 1

ETU-751C Desktop Unit ......................................................... 2

Transmission Ranges ............................................................... 2

Compatibility ........................................................................... 3

Shelves and Enclosures for UTU-701C .................... 3

Connector Adapters for ETU-751C........................... 3

Front Panels ............................................................................. 4

ETU-751C Rear Panel ............................................................. 7

Installation _____________________________________________ 8

Inspection................................................................................. 8

Safety ....................................................................................... 8

Line and Desktop Unit Installation.......................................... 9

Jumper Settings ......................................................... 9

Line Unit Installation............................................... 10

Desktop Unit Installation......................................... 11

HDSL Startup and Synchronization....................................... 12

System Configuration____________________________________ 13

Maintenance Terminal Connection........................................ 13

Logging On ............................................................................ 14

Navigating Menus.................................................................. 15

System Settings...................................................................... 16

LTU and NTU Interface Settings........................................... 17

HDSL Payload Rates ............................................................. 18

Table of Contents 700-701-900-02, Revision 02

vi June 5, 2002 UTU-701C and ETU-751C List 1

Viewing Status __________________________________________18

Main Console Screen..............................................................18

Monitor Screens .....................................................................20

Monitor LTU and NTU Interface Screens ...............20

Monitor HDSL Span 1 Screen.................................22

Product Support_________________________________________23

Certification and Warranty _________________ Inside Back Cover

700-701-900-02, Revision 02 List of Figures

UTU-701C and ETU-751C List 1 June 5, 2002 vii

LIST OF FIGURES

UTU-701C Front Panel .......................................................................... 4

ETU-751C Front Panel........................................................................... 4

ETU-751C Rear Panel............................................................................ 7

Line and Desktop Unit Jumper Settings................................................. 9

UTU/ETU Console Port and Maintenance Terminal Pinouts.............. 14

LIST OF TABLES

Transmission Ranges with ETSI Noise.................................................. 2

UTU and ETU Front Panel Components ............................................... 5

UTU and ETU Front Panel LED Indications ......................................... 6

ETU-751C Rear Panel Components....................................................... 7

G.703 75ΩOutput Connector Pinouts.................................................. 11

G.703 75ΩInput Connector Pinouts .................................................... 11

G.703 120ΩInterface Connector Pinouts............................................. 11

HDSL Line Connector Pinouts............................................................. 12

Console Screen Navigation Keys......................................................... 15

Settings in Config System Settings Menu............................................ 16

Settings in Config LTU and Config NTU Interface Menus................. 17

Actual HDSL Payload Rates – Rate Selectable G.703 ........................ 18

Information Displayed in Main Console Screen.................................. 19

Information Displayed in Monitor LTU and NTU Interface Screens.. 21

Information Displayed in Monitor HDSL Span 1 Screen.................... 22

List of Tables 700-701-900-02, Revision 02

viii June 5, 2002 UTU-701C and ETU-751C List 1

700-701-900-02, Revision 02 Overview

UTU-701C and ETU-751C List 1 June 5, 2002 1

OVERVIEW

This guide contains installation information for the ADC WorldDSL™RS

UTU-701C List 1 and ETU-751C List 1 Rate Selectable HDSL line and

desktop units.

RATE SELECTABLE HDSL

WorldDSL RS (rate selectable) is a single pair High-bit-rate Digital

Subscriber Line (HDSL) solution that offers extended reach capabilities

through the use of industry-leading multi-rate DSL technology. The

UTU-701C and ETU-751C deploy HDSL in networks using a single pair of

copper wires running at speeds between 256 kbps and 2048 kbps. The HDSL

payload rates are menu selected in time slot increments of 64 kbps, ranging

from 64 kbps to 2048 kbps. Transmission ranges vary according to the rate

selected. Depending on noise environment, ranges of up to 7.1 km (4.4 miles)

are possible at the lowest-selectable HDSL payload rates (256 kbps), using

0.51 mm wire. Longer ranges are possible with larger wire.

UTU-701C LINE UNIT

The UTU-701C can be configured as a Line Termination Unit (LTU) or

Network Termination Unit (NTU). The default configuration is NTU.

When configured as an LTU, the UTU-701C serves as the Exchange Office

side of a repeaterless, HDSL transmission system. The LTU-configured unit

connects to an NTU-configured unit (UTU-701C or ETU-751C) over one

twisted-pair of copper wires, completing the HDSL transmission system.

Use of this product in a manner other than defined in this

installation guide may cause damage to equipment or injury

to personnel.

Falls der Gebrauch von diesem Produkt nicht gemaess der

Definition im Installations Handbuch eingehalten wird,

besteht die Gefahr, dass Schaden am Geraet oder sogar

Koerperverletzungen entstehen koennten.

WorldDSL RS units are not backward compatible with

standard HDSL or management unit firmware. The installed

firmware must be that designed for rate selectable units.

Overview 700-701-900-02, Revision 02

2 June 5, 2002 UTU-701C and ETU-751C List 1

The UTU-701C accepts the DTE payload at its G.703 port and transports the

data to the remote unit at the selected HDSL rate. The UTU-701C requires

-36 to -72 Vdc from a local power supply or an enclosure’s AC-to-DC power

supply; it does not supply power to other HDSL units.

ETU-751C DESKTOP UNIT

The ETU-751C is housed in a plastic enclosure with interface and power

connectors for use as an integrated desktop unit. All functions of the

ETU-751C, with exception of power requirements, are identical to the

UTU-701C. The ETU-751C requires a source of 100 to 240 Vac at

50 or 60 Hz.

TRANSMISSION RANGES

Transmission ranges assume the presence of noise according to the ETSI

model described in TS 101 135. The expected Bit Error Rate (BER) under this

model is 1x10-7. The transmission ranges in such a noise environment at the

various HDSL payload rates over one twisted-pair of 0.4 mm and 0.51 mm

copper wire are listed below.

‘

Transmission Ranges with ETSI Noise

Wire Size and Transmission Range (with ETSI Noise)

HDSL Payload

Rate (kbps) (a)

0.4mm (26 AWG)

Single Twisted-Pair

Copper Wire

0.51mm (24 AWG)

Single Twisted-Pair

Copper Wire

256 4.1 km (13,451 ft.) 5.1 km (16,730 ft.)

384 3.9 km (12,795 ft.) 4.7 km (15,420 ft.)

512 3.5 km (11,483 ft.) 4.5 km (14,760 ft.)

768 3.2 km (10,499 ft.) 4.2 km (13,779 ft.)

1152 2.6 km (8,530 ft.) 3.4 km (11,155 ft.)

1536 2.2 km (7,218 ft.) 2.9 km (9,515 ft.)

2048 1.9 km (6,234 ft.) 2.4 km (7,874 ft.)

(a) A selected HDSL payload rate of 64 or 128 kbps is transmitted at

256 kbps (see “HDSL Payload Rates” on page 18).

(b) The maximum no-noise transmission range is approximately 7.1 km

(4.4 miles).

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de ADC

ADC

ADC H4TU-C-231-L1 Manual de usuario

ADC

ADC H2TU-C-388 HiGain Instrucciones de funcionamiento originales

ADC

ADC HiGain Wideband 3190 Manual de instalación y operación

ADC

ADC FlexWave WMX 300 Manual de usuario

ADC

ADC H2TU-C-388 HiGain Manual de usuario

ADC

ADC High Density Position Panel LSX 288 Manual de usuario

ADC

ADC Fiber Optic Panel FL2000 Series Manual de usuario

ADC

ADC OmniReach oFDT-48 Manual de usuario

ADC

ADC HiGain HLU-432 Manual de usuario

ADC

ADC InterReach Fusion Manual de usuario

ADC

ADC HiGain HLU-200 Manual de usuario

ADC

ADC 75 Ohm Interconnect Manual de usuario

ADC

ADC PG-FlexPlus ARL-942 Manual de usuario

ADC

ADC H2TU-C-388 HiGain Manual de usuario

ADC

ADC HiGain HDSL2 Manual de usuario

ADC

ADC ADCP-90-216 Manual de usuario

ADC

ADC PRL-783 Manual de usuario

ADC

ADC HiGain H2TU-C-319 List 4E Instrucciones de funcionamiento originales

ADC

ADC HiGain HLU-231 LIST 8D Instrucciones de funcionamiento originales

ADC

ADC The DSX Value Solution (Japanese) LDX154 Manual de usuario

ADC

ADC OmniReach MDU Rapid Fiber System Manual de usuario

ADC

ADC H4TU-C-319 List 1 Line Unit Instrucciones de funcionamiento originales

ADC

ADC Release 3.1 Manual de usuario

ADC

ADC Carrier-Grade WiMAX Base Station WMX 5000 Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario

Lanner

Lanner NCA-1525 Manual de usuario
