ADC Micro BS Plus UltraWAVE Manual de usuario

UltraWAVE Micro IP BS Plus

IP GSM Base Station Controller and Base Transceiver Station

www.adc.com • +1-952-938-8080 • 1-800-366-3891

Spec Sheet

The UltraWAVE Micro IP BS Plus is an integrated base station controller (BSC) and base transceiver

station (BTS) in a single enclosure.

UltraWAVE R4S softswitch and Micro IP BS Plus work hand-in-hand to reduce the total cost of

network ownership, providing a network growth path for existing and future customers, and

expand the addressable markets of ADC’s GSM products. They serve as the flagship GSM product

line for ADC.

Thanks to its All-IP architecture, Micro IP BS Plus backhauls traffic to carrier networks via an IP

connection over DSL or cable modem networks, this allows for faster and simpler setup and

configuration than any other products.

Key BS Plus Features:

SMS support•

Sectorization supported•

GPRS supported (CS-1, CS-2, CS-3, CS-4)•

2-way combined PA output at the antenna port•

Full alarm reporting to OMC•

10/08•106419AE UltraWAVE Micro IP BS Plus

UltraWAVE Micro IP BS Plus

IP GSM Base Station Controller and Base Transceiver Station

www.adc.com • +1-952-938-8080 • 1-800-366-3891

Features:

Availablein850,900,1800and1900MHzfrequencybands•

Frequencyhopping•

Sectorization•

General Packet Radio Service (GPRS)•

Dynamic power control (uplink and downlink)•

Signiﬁcantly improved BTS sensitivity: -114 dBm (optimal combining diversity) or -111 dBm (no diversity)•

Remote monitoring: Temperature, fan, power supply (PSU), power amp, VSWR can be monitored from•

centralofceenablingremotediagnosisandquickrecovery

Externalalarmsforthirdpartyequipmentarealsosupported.•

Optional redundant power supply with PSU failure alarm support.•

-48 VDC power supply. AC rectiﬁer available.•

Integratedfullracksolutionavailable:UltraWAVEintegratedwithadditionalon-siteequipmentsuchas•

transmission, battery backup, etc. in one rack.

Common hardware modules: single slot TRX, ICP, RFU.•

Supports AMR,EFR, FR codecs. Upgradable to EDGE.•

The Micro product line provides a compact and cost-effective platform, which helps lower the cost

of network ownership. They are easy to upgrade or repair in the field and provide a range of new

monitoring and control functions. The UltraWAVE Micro IP BS Plus supports up to two TRXs in one

chassis. With a single compact chassis, it can support an S11 or O2 site. It has the industry leading

poweramplifierofupto50Wattswhenconfiguredfor850,900,1800and1900MHzGSMnetworks.

MicrosupportsallthekeyBTSfeatures,suchasfrequencyhopping,sectorization,andGPRS.

The Micro IP BS Plus increases the BTS coverage with industry leading power output (50W measured at

antenna port without combining). Receive sensitivity with antenna diversity is up to -114 dBm. Designed

for easy expansion of the BTS capacity, the Micro BS Plus is field upgradable. Operators can start with a

small system and pay as they go to add capacity.

The Micro IP BS Plus is designed for low cost maintenance with remote monitoring, external alarms,

overheating protection, redundant power supply, field replaceable modules, and easy front access. It can

reduce the on-going operation expenses for the operators. An integrated turn-key BTS package option

isavailablewithtransmission,battery,andothersiteequipment.

10/08•106419AE UltraWAVE Micro IP BS Plus

UltraWAVE Micro IP BS Plus

IP GSM Base Station Controller and Base Transceiver Station

www.adc.com • +1-952-938-8080 • 1-800-366-3891

Specifications

BTS Configurations (single cabinet): O1, O2, S11

Frequency Support: GSM850MHz,GSM900MHz,DCS1800MHz,PCS1900MHz

CAPACITY

Number of TRXs: 2 internal

Number of Traffic Channels: 15EFRtrafficchannelsor30AMR/HRtrafficchannels

Traffic Capacity: 9.0Erlangs@2%GoS(O2,EFR)

21.4Erlangs@2%GoS(O2,AMR/HR)

Output Power: Up to 50 Watts

Speech Coding: EFR,AMR/HR5.9kbps

RF Receiver Sensitivity: -111dBm without diversity

-114 dBm with diversity

INTERFACES

RF Interface: GSMCompliantUmInterface;GSMSpec.04.06,04.08,05.01-05.05,

  05.08&05.10;GSMspec03.64,04.60(Rel98)

MSC Interface: Compliant A interface over SIGTRAN

Network Interface: 100 Mbps Ethernet, RJ-45 connector

Serial Port: RS232, RJ-45 connector

OPERATION

Remote Monitoring: Monitor temperature, PA, fan, PSU, VWSR from central office;

External alarms supported

Overtemp Protection: Automatic detection and intervention

Access to Equipment: Front and Rear Access

Field Support: All modules are field replaceable

POWER SUPPLY

Input Voltage: -48 VDC; 110/220 VAC optional

Redundancy: Redundant power supply

Alarm: PSU failure alarm reported OMC

MECHANICAL

Rack Mount: Versatilemountingoptionsfor19”,23”and24”racks

Radio Chassis Dimensions (HxWxD):1051x560x647mm(41.8x22.05x25.5inches)

Weight: 213kg(470lbs)

OPERATING ENVIRONMENT

Temperature: -5° to 55° C (23° to 131° F)

Humidity (non-condensing): 10%to90%

COMPLIANCE: EN60950,UL60950

  FCClicensefor850MHz/1900MHz

  CEmarkingfor900MHz/1800MHz

Spec Sheet

Website: www.adc.com

FromNorthAmerica,CallTollFree:1-800-366-3891•OutsideofNorthAmerica:+1-952-938-8080

Fax:+1-952-917-3237•ForalistingofADC’sglobalsalesofficelocations,pleaserefertoourwebsite.

ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101

Specifications published here are current as of the date of publication of this document. Because we are continuously

improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may

verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.

views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features

containedhereinmaybecoveredbyoneormoreU.S.orforeignpatents.AnEqualOpportunityEmployer
