Spec Sheet

LoopStar®750

Cost-Effective Ethernet/TDM Services at the Metro Edge

With customers demanding higher speed Ethernet services at lower price points, carriers are

looking for ways to offer new services while maintaining the current revenue streams from existing

services. In addition, service providers would like to extend the life of current infrastructures and

be able to migrate to the next generation of networks at the appropriate time. ADC’s LoopStar®

700 product family addresses all of these requirements with a cost-effective, multiservice access

platform designed specifically to enable new customer edge applications while maintaining the

viability of current services and infrastructures.

The LoopStar 750 is optimized for medium to large enterprises, multi-tenant buildings or service

aggregation. This powerful unit is NEBS 3 certified and accommodates up to four plug-in interface

cards with a full range of Ethernet and TDM interfaces to support a variety of

multiservice applications:

• Ethernet services over DS1, DS3 and SONET/SDH

• Multiservice Gigabit Ethernet

• T1, E1 or J1 transport over packet networks

• Transparent LAN service

• Supports Multiprotocol Label Switching (MPLS)

• Virtual Private LAN Service (VPLS)

Benefits

• Reduces capital, operational and

provisioning expenses

• Increases revenue through new data services

• Achieves quick return on investment

• Extends life of existing network investments

• Provides migration path to next generation

IP/MPLS networks

• Transports ILEC-quality T1/E1/J1 services

without compromise

• Low cost, flexible, easy to manage

and faster to provision

• Compact, reliable stackable solution

• Centralized management and provisioning

saves significant time and money

www.adc.com • +1-952-938-8080 • 1-800-366-3891

LoopStar®750

Cost-Effective Ethernet/TDM Services at the Metro Edge

Innovation for Next Generation Ethernet and IP Services

Based on a flexible, IP-centric architecture, the LoopStar 750 uses programmable processors to support

new protocols, interfaces and features as they emerge. Incorporating ADC’s suite of management tools,

the LoopStar 750 can support diverse topologies, scale quickly and easily as the network evolves, and

deliver differentiated services on a per-customer basis.

With this versatile platform, the LoopStar 750 enables service providers to:

• Deliver high-speed, business-class Ethernet services (such as Internet access, transparent LAN, storage,

VLANs and tag stacking for traffic management, and VPLS).

• Support traditional T1 (E1 or J1) circuit-based voice/data/video services over Ethernet/IP with the same

no compromise quality and robustness as a circuit delivered in native TDM over SONET/SDH.

• Use their installed SONET/SDH or Ethernet networks to support traditional voice and leased-

line traffic, while moving toward a data-optimized network that can keep pace with customers’

bandwidth needs.

• Transport multiservice traffic efficiently across a single network to reach all customers with the same

services and the same service levels.

With the management suite’s full range of performance statistics, fault indication, loopback diagnostics,

and differentiated service provisioning and definition, the LoopStar 750 allows service providers to

create a secure, reliable network that resolves today’s multiservice challenges while setting the stage for

migration to next-generation networking.

9/06 • 102156AE LoopStar®750

Features

• Business-class metro Ethernet services

• Carrier-class circuit emulation over

packet networks

• IP-centric architecture

• DS1, DS3, SONET/SDH or Ethernet for

transport

• High density NEBS 3 platform

• LoopStar 700 In-band or out-of-band

management

Ethernet

TDM

Ethernet

PBX

TDM

GigE with Sub-50 msec PSR

PSTN

IP/MPLS Core

Class 5

Central Office

DS3

NxT1/E1

Ethernet

NxT1/E1

Ethernet

750

745

718

714

www.adc.com • +1-952-938-8080 • 1-800-366-3891

Specifications

Interface Modules (4 slots) • 1-port GigE (SFP)

• 2-port GigE (SFP, Ring only)

• 1-port OC-12c/STM-4c (SFP)

• 1-port OC-3c/STM-1 (SFP)

• 3-port DS3 (BNC)

• 8-port T1/E1 (RJ48c)

• 8-port 10/100 Base-T (RJ45)

• 8-port 100 Base-FX (Duplex LC)

• Channelized DS3

Management • In-band or out-of-band

• SNMP

• CLI (RS-232 / Telnet)

• FTP to download multiple software images and configurations

• 10/100 Base-T management port (RJ48c)

• 2-port BITS timing interface (RJ48c)

• LoopStar 700 intelligent management

Ethernet Services • 802.1d bridging

• 802.1p prioritization

• 802.1q VLAN tagging/stacking

• VLAN switching

• MPLS/VPLS option

• Rate-limiting per port or VLAN:

- 1 Mb/s increments (1 to 100M)

- 50 Mb/s increments (100 to 1000M)

• 802.3ad Link Aggregation

• Protected Switching Ring (50 m/sec)

• Spanning Tree Protocol

Circuit Emulation Services

Framed or unframed mode • Fixed or Adaptive Jitter Buffer

• Adaptive, BITS, Loop or Internal (Stratum 4) timing modes

• Round-trip and one-way delay measurements

• Local and remote loopbacks

• ANSI t1.231 reports

Physical • 2.2” x 17” x 20” (h x w x d)

• Dual hot-swappable power supplies

• -AC: 90-264 VAC auto ranging

• DC: -36 VDC to -75 VDC

• 75-Watt maximum power consumption

• 0° to 50° C (operating)

• -20° to 80° C (storage)

• FCC Part 15—Class A

• UL 60950

• CE Mark

• CLEI codes

• NEBS 3 certified

LoopStar®750

Cost-Effective Ethernet/TDM Services at the Metro Edge

9/06 • 102156AE LoopStar®750

Spec Sheet

Description Catalog Number

LPS-750 AC Package

*Includes: 1 AC power supply and AC power cord, blanking plates, 19" and 23"

rack mount brackets, console cable, License for Basic Software and documentation

LPS-750-AC L1

LPS-750-48VDC Package

*Includes: 1 -48VDC power supply, blanking plates, LPS-750-48DC L1 19" and 23"

rack mount brackets, console cable, License for Basic Software and documentation

LPS-750-48DC L1

Interface Cards

LoopStar 5000/2200/2100 Blank Interface Slot Faceplate

10/100 BaseT Ethernet-8 port

100BASE FX SM-8 port, fixed optics

100BaseFX MM-8 port, fixed optics

Gigabit Ethernet, SFP-1 port, w/o optics

T1/E1/J1-8 port (with NxT1/E1 Uplink)

DS3, Clear Channel-3 port

Dual Gigabit Ethernet Ring, SFP-2 port w/o optics

DS3, Channelized, MLPPP only, support 8 bundles of up to 8 T1s

OC-3/STM-1, Clear Channel-1 port, w/o optics

OC-12/STM-4, Clear Channel-1 port, w/o optics

LPS-7INF-BLNK L1

LPS-7INF-FE L1

LPS-7INF-100SM L1

LPS-7INF-100MM L1

LPS-7INF-Gig L1

LPS-7INF-T1E1 L1

LPS-7INF-DS3 L1

LPS-7INF-2Gig L1

LPS-7INF-DS3C L1

LPS-7INF-STM1 L1

LPS-7INF-STM4 L1

Ordering Information

Web Site: www.adc.com

From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080

Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our Web site.

ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101

Specifications published here are current as of the date of publication of this document. Because we are continuously

improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may

verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.

views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features

contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
