ICP Art. Nr. and SAP Art. Nr.

Art. No. Art. No. Description Notes

ICP SAP

Zero Channel RAID Products for U160/U320 SCSI and SATA (RAID 0/1/4/5/10)

8500 2073900 GDT8500RZ Zero-Channel-Disk-Array-Controller (RAID 0/1/4/5/10)

PCI-SATA-Disk-Array Controllers (RAID0/1/4/5/10)

8546 2074000 GDT8546RZ Four-Port-S-ATA 150-Disk-Array-Controller (RAID 0/1/4/5/10)

8586 2084000 GDT8586RZ Eight-Port-SATA 150-Disk-Array-Controller (RAID 0/1/4/5/10)

Low-Profile 64-Bit PCI Modular Hardware RAID Controller with Multiprocessor RISC Technology, Intel

80303 CPU, Cache-RAM 64MB onboard (with ECC) for use in RAIDIOS enabled PCI slots. Supports

Adaptec U160 or Adaptec/LSI U320 onboard SCSI silicon, incl. ICP

Low-Profile 64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU,

Cache-RAM 128MB onboard (with ECC), up to 150MB sync. data transfer rate per port, four internal S-

ATA connectors, ICP RAID Console and ICP RAID Navigato

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

128MB onboard (with ECC), up to 150MB sync. data transfer rate per port, eight internal SATA

connectors, ICP RAID Console and ICP RAID Navigator installati

PCI-SCSI-Disk-Array-Controllers for RAID 4/RAID 5 Applications

9803 2074500 GDT8523RZ Two-Channel-Ultra160-SCSI-Disk-Array-Controller (RAID 0/1/4/5/10)

9804 2074600 GDT8543RZ Four-Channel-Ultra160-SCSI-Disk-Array-Controller (RAID 0/1/4/5/10)

8514 2074700 GDT8514RZ 1+1-Channel-Ultra320-SCSI-Disk-Array-Controller (RAID 0/1/4/5/10)

8524 2074800 GDT8524RZ Two-Channel-Ultra320-SCSI-Disk-Array-Controller (RAID 0/1/4/5/10)

8524+ 2074900 GDT8524RZ+ 2ch-Ultra320-SCSI-RAID-Controller (RAID 0/1/4/5/10) prepared for BBU

8524B 2075000 GDT8524RZ+BBU 2ch-Ultra320-SCSI-RAID-Controller (RAID 0/1/4/5/10) with Battery Backup

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

32MB up to 256MB (one unbufferend PC133 DIMM with ECC), up to 160MB sync. data transfer rate per

channel, two external 68 pin UHD SCSI connectors, two inte

64-Bit Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

32MB up to 256MB (one unbuffered PC133 DIMM with ECC), up to 160MB sync. data transfer rate /

channel, two external 68 pin UHD SCSI connectors, four internal 6

Low-Profile 64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU,

Cache-RAM 128MB onboard (with ECC), up to 320MB sync. data transfer rate per channel, one external

68 pin UHD SCSI channel & connector, one internal 68 p

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

64MB up to 256MB (one unbufferend PC133 DIMM with ECC), up to 320MB sync. data transfer rate per

channel, two external 68 pin UHD SCSI connectors, two inte

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

64MB up to 256MB (one unbufferend PC133 DIMM with ECC), up to 320MB sync. data transfer rate per

channel, two external 68 pin UHD SCSI connectors, two inte

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

64MB up to 256MB (one unbufferend PC133 DIMM with ECC), up to 320MB sync. data transfer rate per

channel, two external 68 pin UHD SCSI connectors, two inte

PCI-SCSI-Disk-Array-Controllers for RAID 4/RAID 5 Applications and Clustering

9807 2075100 GDT8623RZ Two-Channel-Ultra160-SCSI-Disk-Array-Controller (RAID 0/1/4/5/10)

9808 2075200 GDT8643RZ Four-Channel-Ultra160-SCSI-Disk-Array-Controller (RAID 0/1/4/5/10)

PCI-Fibre-Channel-Disk-Array-Controllers for RAID 4/RAID 5 Applications

9822 2075300 GDT8522RZ Dual-Port Fibre-Channel-Disk-Array-Controller (RAID 0/1/4/5/10)

PCI-Fibre-Channel-Disk-Array-Controllers for RAID 4/RAID 5 Applications and Clustering

9824 2075400 GDT8622RZ Dual-Port Fibre-Channel-Disk-Array-Controller (RAID 0/1/4/5/10)

Firmware Upgrades

8798 RAIDYNE Firmware Upgrade

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

32MB up to 256MB (one unbuffered PC133 DIMM with ECC), up to 160MB sync. data transfer rate, two

external 68 pin UHD SCSI connector, two internal 68 pin co

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

32MB up to 256MB (one unbuffered PC133 DIMM with ECC), up to 160MB sync. data transfer rate, two

external 68 pin UHD SCSI connector, four internal 68 pin c

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

32MB up to 256MB (one unbuffered PC133 DIMM with ECC), up to 200 MB/s per FC-AL, one additional

U160 SCSI channel, ICP RAID Console and ICP RAID Navigator

64-Bit PCI Hardware RAID Controller with Multiprocessor RISC Technology, Intel 80303 CPU, Cache-RAM

32MB up to 256MB (one unbuffered PC133 DIMM with ECC), up to 200 MB/s per FC-AL, one additional

U160 SCSI channel, ICP RAID Console and ICP RAID Navigator

2075800

bilingual

manual After the installation of the RAIDYNE upgrade, the controller supports disk arrays with RAID 0, RAID 1,

RAID 4, RAID 5 and RAID 10.

Connectivity Accessories

3510 2076400 Battery Pack Battery Backup Unit

3500 2076500 SATA/PATA Adapter SATA/PATA Adapter (specifically designed for GDT8546RZ)

3201 2076600 SATA Cable SATA Cable, 1 m

8859 2076700 Internal Internal Wide/Ultra320 SCSI cable, length 1,6 meters

Wide/Ultra320

Cable

3101 2076800 External Ultra320 External Wide/Ultra320 SCSI cable, length 1 meter

Cable

VHD-HD, 1m

3103 2076900 External Ultra320 External Wide/Ultra320 SCSI cable, length 3 meters.

Cable

VHD-HD, 3m

3111 2077000 External Ultra320 External Wide/Ultra320 SCSI cable, length 1 meter

Cable

VHD-VHD, 1m

3113 2077100 External Ultra320 External Wide/Ultra320 SCSI cable, length 3 meters.

Cable

VHD-VHD, 3m

8880 2077200 External External Wide/Ultra160 SCSI cable, length 1 meter

Wide/Ultra160

Cable

Spare Battery Pack only for GDT8524RZ+BBU. - Not for use with GDT8524RZ or any other controller

model.

Adapter for IDE HDDs to connect with a SATA controller (e. g. GDT8546RZ), with activity LED for HDD

identification, self-controlled adjustment to the particular HDD speed (e. g. UDMA 66, UDMA 100, UDMA

133), needs power (Floppy plug)

internal cable for connections between SATA controllers and SATA drives or SATA adapters.

Five 68pin HD connectors for hard disks, one HD connector for one controller and another 68pin

connector (face down) for a terminator. LVD and SE operation. Also for Wide/U160 and Ultra2 operation.

68 pin VHD and 68 pin HD connectors . LVD operation. Also for Wide/Ultra2 operation.

68 pin VHD and 68 pin VHD connectors (VDHC is stackable). LVD operation. Also for Wide/Ultra2

operation.

68 pin VHD and 68 pin VHD connectors (VDHC is stackable). LVD operation. Also for Wide/Ultra2

operation.

68 pin HD and 68 pin HD connectors. Also for Wide/Ultra2 operation.

3505 2077400 Wide/Ultra320 External Wide/Ultra320 SCSI Bracket.

SCSI Bracket

1 HD-VHD

8958 2077800 Internal LVDS/SE Internal MultimodeTerminator for LVDS SCSI Bus.

Terminator

8957 2078100 SCSI Director 19" Rackmount Wide/Ultra160 SCSI Expander - Dual Channel

RAM

8961 2078200 128MB ECC PC133 ECC DIMM for GDT8xy3RZ, GDT8xy2RZ, GDT8x24RZ

SDRAM-Module

DIMM

Cluster Kits

2x KIT 8623SD Please order the following parts:

"Light" 2 GDT8623RZ, Art. No. 2075100(GE)

2x 2078200 Ultra160 SCSI 2 128MB PC133 ECC DIMM, Art. No. 2078200

1x 2078100 1 SCSI Director, Art. No. 2078100

2x 2076900 2 Cable VHD-HD, 1 Meter length each, Art. No. 2076900

1x 2077200 1 Cable HD-HD, 1 Meter length each, Art. No. 2077200

2x KIT 8623SD Please order the following parts:

Ultra160 SCSI 2 GDT8623RZ, Art. No. 2075100(GE)

2x 2078200 2 128MB PC133 ECC DIMM, Art. No. 2078200

2x 2078100 2 SCSI Director, Art No. 2078100

4x 2076900 4 Cable VHD-HD, 1 Meter length each, Art. No. 2076900

2x 2077200 2 Cable HD-HD, 1 Meter length each, Art. No. 2077200

2075100GE or

2075100

2075100GE or

2075100

1 68 pin external VHD and 1 internal 68 pin HD connector. LVD and SE operation. Also for Wide/Ultra2

operation.

LVD and SE operation. For Wide/Ultra2, Wide/Ultra160 and Wide/Ultra 320 operation

Suitable for Clustering. Package includes SCSI Director and power cables.
