ADA INSTRUMENTS 6D SERVOLINER Manual de usuario

Line Laser

OPERATING MANUAL

6D SERVOLINER /

6D SERVOLINER GREEN

adainstruments.com

2English

13 2

хy

2 1

THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT

HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN, COMPLETE

SET WITHOUT GIVING PRIOR WARNING.

APPLICATION

Line laser ADA 6D SERVOLINER / ADA 6D SERVOLINER GREEN is designed

to check the horizontal and vertical position of the surfaces of the elements

of building structures and also to transfer the angle of inclination of the

structural part to similar parts during construction and installation works.

SPECIFICATIONS

English

Laser beam

Light sources

Laser safety class

Accuracy

Self-leveling range

Working range (with detector)

Rotation/Fine adjustment

Power supply

Mounting thread

Operating temperature

Weight

Size

Dust / water protection

6D SERVOLINER

6D SERVOLINER GREEN

4 lines (H 360º), 4 lines (V 270º), 1 dot (plumb down)

635nm 520nm

2, <1 mWt

±1mm/10m

±3°

20 (70m) 40 (70m)

360°

Li-battery 12.6V, 2600mAh/8xAA 1,5V/charger

5/8"

-10°C ~ +40°C

1.5 kg

Ø 152x220 mm

IP54

4English

FUNCTIONAL DESCRIPTION

- 4 vertical lines (V), 4 horizontal lines (H) (360º), plumb down;

- The line laser is designed for operation indoor and outdoor.

- Electronic compensator for the faster self-leveling ±3º;

- The line laser begins to blink automatically, if the deviation from horizontal

plane is more than ±3º;

- Fine adjustment mechanism helps to find the object;

- Compensator blocks automatically, when the power is off. It protects the

compensator form vibrations during transportation.

FEATURES

1. Vertical laser window

2. Keypad

3. Horizontal laser window

4. Housing

5. Serial number plate

6. Limb 360º

7. Adjustable legs

8. Down point laser / mounting thread 5/8’’

9. Power indicator

10. Battery clip

11. Li-on battery / battery compartment

12. Fine adjustment switch

13. Connector for power unit

5English

OPERATION

1. Li-battery or battery adapter AA can be used for operation with line

laser. If using a battery adapter AA, install batteries in it. Open the

battery compartment cover. Insert the batteries into the battery

adapter. Close the battery compartment cover. Install Li-battery /

battery adapter AA (11) on the housing of the line laser. To replace

the Li-battery / battery adapter press clip (10) and release it from the

housing of the line laser.

2. To check the power level of the Li-battery use power indicator (9).

To do this, press the button with the battery icon. The number of

highlighted segments on the indicator shows the power level. It is

possible to use charger to operate with the tool. Use charger for

rechargeable batteries. Connect the charger to the connector for

power switch (13) that is located on the housing of the line laser. Line

laser will be ON and charge rechargeable batteries.

WARNING: Never use charger for ordinary batteries. Do not leave

the line laser unattended while using charger. Parameters of

the charger must correspond to the parameters of domestic

electricity. Output voltage must be no more than 12V.

KEYPAD

1. Horizontal switch (H)

2. P o w e r s w i t c h O n / O  ( P o w e r L E D )

3. Vertical switch (V)

4. Detector LED

5. Detector mode

6. Self-leveling mode

7. Self-leveling o LED

6English

3. Set up the line laser on the oor or the tripod. When using tripod,

screw the tripod screw into the centering hole. Use screw-adapter

to set a line laser on the mounts with bases. Level the line laser

with the bubble level with the help of adjustable legs (7) or tripod.

Press button (2) to switch on the line laser. Press buttons H (1) and

V (3) to switch and select vertical and horizontal lines. Switch o the

unnecessary lines to save battery power.

Variants of projections:

H button:

- 1 horizontal line (sector 120º)

- 2 horizontal lines (sector 180º)

- 4 horizontal lines (sector 360º)

- all horizontal lines are switched o

V button:

- one vertical line and plumb down

- two vertical lines and plumb down

- 4 vertical lines and plumb down

- all vertical lines are switched o

5. Switch On the line laser. Automatic self leveling begins. LED (7) blinks.

When the self-leveling is nished, LED (7) is OFF. If the LED (7) and

the laser beam begin to blink, the deviation of the line laser from the

horizontal plane is more than ±3º. Laser level can’t be self-leveled.

Adjust the line laser with the help of adjustable legs or tripod.

6. Rotate the housing of the line laser to aim the vertical beams. Use

switch (12) for ne adjustment. Use limb (6) to rotate the housing by

the specic angle:

- aim the vertical beam to the selected point.

- rotate the switch (12) to coincide the mark on the housing witht the

selected rotation angle value on the limb.

7English

MANUAL MODE

1. Switch the line laser ON. Auto leveling function is activated. Press but-

ton (6) to switch on the auto manual mode. LED indicator (7) will be ON

constantly.

2. It is possible to set the inclination of the laser beams along the axis

X and Y in the range of ±3º.

3. Press and hold button H (1) or V(3) to set the tilt angle along the axis X.

4. Press button (3) to set the tilt angle along the axis Y. Press and hold but-

ton H (1) or V (3) to set the tilt angle along the axis Y.

5. Laser lines begin to ash when reaching the full distance position. Press

button (6) to exit from the full tilt distance position or switch o the tilt

mode.

TO CHECK THE ACCURACY OF LINE LASER

(SLOPE PLANE)

Set up the line laser between two walls, the distance is 5 m.Turn

on the Line Laser and mark the point of cross laser line on the wall.

Set up the line laser 0,5-0,7m away from the wall and make, as described

above, the same masrks. If the dierence {a1-b2} and {b1-b2} is less then

the value of “accuracy” (see spesications), there is no need in calibration.

Example: when you check the accuracy of Line Laser the dierence

is {a1-a2}=5 mm and {b1-b2}=7 mm. The instrument’s error: {b1-b2}-

{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.

If the accuracy of Line Laser isn’t corresponding with claimed accuracy,

contact the authorized service center.

8English

TO CHECK LEVEL

Choose a wall and set laser 5M away from the wall. mark cross point on

the wall. Turn the line laser so that the beam is displaced approximately

2.5m to the left. Horizontal line must be in the “accuracy” range (see specif.)

at the same height with the cross point. Repeat the same steps, moving

the laser level to the right. NOTE: do not displace the rotating axis when

checking.

CHECK PLUMB

Choose a wall and set laser 5m away from the wall. Hang a plumb line 2,5

m long. Turn on the laser and aim the vertical laser line to the plumb. The

accuracy of the line is in the range, if the vertical line doesn’t exceed (up or

down) the half of the value of the accuracy that is shown in the specica-

tions (±3 mm/10 m).

PRODUCT LIFE

Product life of the tool is 7 years. The battery and the tool should never

be placed in municipal waste. Date of production, manufacturer’s contact

information, country of origin are indicated on the product sticker.

CARE AND CLEANING

Please handle line laser with care. Clean with soft cloth only after any use.

If necessary damp cloth with some water. If instrument is wet clean and

dry it carefully. Pack it up only if it is perfectly dry. Transport in original

container/case only.

SPECIFIC REASONS FOR ERRONEOUS MEASURING RESULTS

• Measurements through glass or plastic windows;

• Dirty laser emitting window;

English

• After line laser has been dropped or hit. Please check the accuracy;

• Large uctuation of temperature: if instrument will beused in cold areas

after it has been stored in warm areas (or the other way round) please wait

some minutes before carrying out measurements.

ELECTROMAGNETIC ACCEPTABILITY (EMC)

• It cannot be completely excluded that this instrument will disturb

other

• instruments (e.g. navigation systems);

• will be disturbed by other instruments (e.g. intensive electromagnet-

ic radiation nearby industrial facilities or radio transmitters).

LASER CLASS 2 WARNING LABELS ON THE LASER INSTRUMENT

LASER CLASSIFICATION

The instrument is a laser class 2 laser product accortding to DIN IEC 60825-

1:2014. It is allowed to use unit without further safety precautions.

SAFETY INSTRUCTIONS

• Please follow up instructions given in operators’ manual.

• Do not stare into beam. Laser beam can lead to eye injury (even from

greater distances).

• Do not aim laser beam at persons or animals. The laser plane should

be set up above eye level of persons. Use the instrument for measuring

jobs only.

• Do not open instrument housing. Repairs should be carried out by au-

thorized workshops only. Please contact your local dealer.

• Do not remove warning labels or safety instructions.

• Keep instrument away from children.

• Do not use instrument in explosive environment.

WARRANTY

This product is warranted by the manufacturer to the original purchaser to

be free from defects in material and workmanship under normal use for a

period of two (2) years from the date of purchase. During the warranty pe-

riod, and upon proof of purchase, the product will be repaired or replaced

(with the same or similar model at manufactures option), without charge

for either parts of labour.

In case of a defect please contact the dealer where you originally pur-

chased this product. The warranty will not apply to this product if it has

been misused, abused or altered. Without limiting the foregoing, leakage

of the battery, bending or dropping the unit are presumed to be defects

resulting from misuse or abuse.

EXCEPTIONS FROM RESPONSIBILITY

The user of this product is expected to follow the instructions given in op-

erators’ manual. Although all instruments left our warehouse in perfect

condition and adjustment the user is expected to carry out periodic checks

of the product’s accuracy and general performance.

The manufacturer, or its representatives, assumes no responsibility of re-

sults of a faulty or intentional usage or misuse including any direct, indi-

rect, consequential damage, and loss of prots.

The manufacturer, or its representatives, assumes no responsibility for

consequential damage, and loss of prots by any disaster (earthquake,

storm, ood ...), re, accident, or an act of a third party and/or a usage in

other than usual conditions.

The manufacturer, or its representatives, assumes no responsibility for

any damage, and loss of prots due to a change of data, loss of data and

interruption of business etc., caused by using the product or an unusable

product.

English

Otros manuales para 6D SERVOLINER

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Nivel láser de ADA INSTRUMENTS

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE 3-360 GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE 3D Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE MINI GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE 2-360 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS LASERTANK 3-360 GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS TOPLINER 3-360 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ROTARY 400 HV Servo Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS 6D SERVOLINER GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ProDigit 30 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ROTARY 400 HV-G SERVO Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS BASIS Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS TOPLINER 3-360 GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ProLevel 40 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE 2-360 GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ADA BASIS Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS 6D SERVOLINER GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ROTARY 500 HV SERVO Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS Phantom 2D Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ECO 2 XL Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE MINI Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE 360-2V GREEN Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ProDigit Mini Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS 3D Liner 2V Green Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS CUBE MINI Manual de usuario

Manuales populares de Nivel láser de otras marcas

Nedo

Nedo ET-5 Manual de usuario

geo-FENNEL

geo-FENNEL Maxi-Liner FL 65 HP Manual de usuario

LaserLiner

LaserLiner X2-Laser Manual de usuario

Spectra

Spectra LL300N Manual de usuario

geo-FENNEL

geo-FENNEL Selection PRO FLG 40-PowerCross GREEN SP Manual de usuario

Nedo

Nedo Crossliner 4 Manual de usuario

Lasertec

Lasertec FX360G Manual de usuario

Flex

Flex ALC 8 Manual de usuario

Black & Decker

Black & Decker LZR5 Manual de usuario

Johnson

Johnson 40-6692 Manual de usuario

Cocraft

Cocraft HL 20-SG Manual de usuario

Zircon

Zircon iLine Manual de usuario

HWH

HWH 310 SERIES Manual de usuario

Leica

Leica iCON robot 60 Manual de usuario

LaserLiner

LaserLiner SuperCross-Laser SCL 2 Manual de usuario

LaserLiner

LaserLiner ActiveFinder XP Manual de usuario

DeWalt

DeWalt DW082 Manual de usuario

imex

imex EL20 Manual de usuario
