ACS ACR30 Manual de usuario

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 1 of 13

Advanced Card Systems Ltd.

Room 302, 3/F., Shun Fat Industrial building,

17 Wang Hoi Road, Kowloon Bay,Kowloon, Hong Kong.

Tel: 852-2796 7873 Fax: 852-2796 1286

Website: www.acs.com.hk E-mail : [email protected]

ACR30

User Manual

ACR30 smart card reader/writer

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 2 of 13

Table of content

1. Introduction …………………………………………………………………………… 3

2. Technical specifications and system requirement ………………………….…. 4

3. Smart card reader installation/uninstallation by using installer……………… 5

3.1 Installation (Example : ACR30U, PCSC, Win2K)……………………………………. 5

3.2. Connection Diagrams ………………………………………………………………….. 7

3.3. Un-installation (Example : ACR30U, PCSC, Win2K) ………………………………. 8

4. Sample Applications ………………………………………………….……………… 9

4.1 ATM Demo ……………………………………………………………………………… 9

4.2 Screen Saver …………………………………………………………………………… 12

4.3 SIMmate 2000 …………………………………………………………..……………… 13

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 3 of 13

1. Introduction

The ACS Smart Card Reader/Writer ACR30 is an interface for the communication between a

computer (for example, a PC) and a smart card. Different types of smart cards have different

commands and different communication protocols. This prevents in most cases the direct

communication between a smart card and a computer. The ACR30 Reader/Writer establishes

a uniform interface from the computer to the smart card for a wide variety of cards. By taking

care of the card specific particulars, it releases the computer software programmer of getting

involved with the technical details of the smart card operation, which are in many cases not

relevant for the implementation of a smart card system.

The ACR30 Smart Card Reader/Writer is connected to the computer through a serial

asynchronous interface (RS-232) or USB interface. The reader accepts commands from the

computer, carries out the specified function at the smart card and returns the requested data

or status information.

The ACR30 is a compact, very cost-effective, single chip reader which supports all MCU-

based cards with T=0 or T=1 protocols as well as the popular memory cards in the market

today. It is ISO 7816-1/2/3 compliant, EMV and Microsoft PC/SC certified, and supports all

major PC platforms.

Being a single-chip solution, this reader is one of the most cost-effective solutions for e-

commerce, information security, access control, identification, and other smart card

applications. It is available in two types of interface: ACR30S and ACR30U. The ACR30 is

also available in two types of casing, the original Piano casing and the new CyberFrog casing.

Like the ACR20, the ACR30 is also supplied in module form (ACM30). This is an ideal

solution for easily integrating smart card access into any application. The module retains the

ACR30 Smart card reader/writer

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 4 of 13

full functionalities of the reader/writer, and can be easily integrated in payphones, parking

meters, vending machines, laundries, gaming machines, ATM's, sophisticated access control

systems, and more.

2. Technical specifications and system requirement

Standard features for the ACR30 reader series:

• ISO 7816-1/2/3 and PC/SC Compliant

• Certified by CE, FCC, EMV and Microsoft WHQL

• Read and write ALL microcontroller cards with T=0 and T=1 protocols

• Read and write the popular memory card types in the market:

o Siemens: SLE4406, SLE4418, SLE4428,SLE4432, SLE4442

o Atmel: AT88SC06, AT24C01-16

o STMicroelectronics: ST1305, ST14C02C, ST14C04C

Note: Card manufacturers using the above-mentioned chips may have different

names for their

cards. These cards are likewise supported by ACR30. Examples are:

- Gemplus: GPM103, GFM2K, GFM4K, GPM2K, GPM8K

- Schlumberger: Primeflex Store 2K/8K, Open 2K/4

• Interface library for efficient PC application software development

o 32-bit DLL files for Windows 95, 98,Me, NT and 2000

o PC/SC compliant IFD handler

Technical Specifications:

Interface RS-232 (Serial) or USB

Supply Voltage Regulated 5V DC

Supply Current <100mA (without smart card)

Operating Temperature 0 - 50 °C

CLK Frequency 3.68 / 4 MHz

Standards / Certifications ISO 7816-1/2/3, PC/SC, CE, FCC

Operating System Support Windows 95, 98, Me, NT, 2000 and XP, Linux

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 5 of 13

3. Smart card reader installation/uninstallation by using installer

3.1 Installation - Example : ACR30U, PCSC, Win2K

After the user run “setup.exe” which is

located in the “AC-Kit driver directory”. This

page will be shown.

Click “Next” button

Note:

1) Please do NOT connect the ACR30 reader with

PC until the instruction by installer.

The user should select the appropriate smart

card reader from the list.

Note

U – USB

SP- Serial Pnp

S – Serial RS-232

For example, ACR30U is selected.

Click “Next” button

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 6 of 13

Click “Next” button

Note:

1) Please do NOT connect the ACR30 reader with

PC until the instruction by installer.

2) For the ACS30S (PCSC), the user will be asked

to select their COM port.

Please make sure the ACS USB reader is

disconnected.

Click “OK” button

Please connect the reader.

Click “Yes” button for the Digital signature

dialog box.

Click “OK” button

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 7 of 13

Click “Finish” button

Note

1) The user may be asked for reboot the system

under Win 98, Win Me platforms.

2) To ensure the PCSC driver is installed properly,

the LED will be turn on when the card is inserted.

3.2. Connection Diagrams

Connection diagram of RS-

232 Serial Interface Smart

Card Reader

Connection diagram o

USB Interface Smart Card

Reader

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 8 of 13

3.3. Un-installation (Example : ACR30U, PCSC, Win2K)

For the un-installation, the user just need to

run the installer again.

After the user run “setup.exe” which is

located in the “AC-Kit driver directory”. This

page will be shown.

Click “Next” button

The installer can detect your existing driver.

Click “Next” button to remove the driver

Re-boot the system to make sure the driver

can be removed successfully.

Click “Next” button to re-boot

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 9 of 13

4. Sample Applications (available from www.acs.com.hk)

All the sample applications are developed for ACOS1 MCU card only.

Note: You will need to install the ACS Proprietary drivers for these applications.

4.1 ATM Demo

4.1.1 Program Description

This application demonstrates the use of ACOS card as a combo ID and stored-value card

with a built-in PIN-protected security access layer. The program provides a simulated Online

Bank module and a simulated E-Shop module. In both cases, the smart card can be used to

transact business using ACS smart card readers.

In the banking application, the smart card can be used to transfer money from the simulated

bank module to the card. In addition to this functionality, the money can also be withdrawn

from the value stored on the smart card. In the e-shop application, the smart card can be

used to purchase items from the simulated store module. The total value of purchase shall be

checked against the value stored on the card and the transaction can be consummated if the

value stored on the card is enough to cover for the total value of purchases made.

The application also provides the functionality to format the smart card for the use of the

application. During this stage, the smart card shall store basic information of the cardholder,

and the cardholder’s PIN. The card money value is stored in the special account module

present only in ACOS smart cards. The PIN shall be used as a security access for all

processes that involve the amount of money stored on the smart card.

The program also displays a window that shows the various APDU commands and responses

that occur for the whole duration of program execution.

4.1.2 Platform and driver

Suggested Operating System Driver

Windows 98 SE

Windows ME

Windows 2000 Professional

ACS Proprietary Driver

ACR30 - User Manual V 1.08, July 2002

Advanced Card Systems Ltd. Page 10 of 13

4.1.3 Installation

The demonstration program is provided herein as an executable file. The user needs to install

the ACS smart card reader using the ACS Proprietary driver before running the program. The

user is also required to copy the file, Des.dll, into either the System directory or the directory

where the demonstration program resides.

4.1.4 Function Keys and Processes

When the program is run, the user will be prompted into the Main Menu window as shown

below.

The user is required to select the Port to which

the ACS smart card reader is connected. The

Output window on the right half of the screen

will display the APDU command and responses

for the various processes that may be invoked

for the duration of the program execution.

Connect – When the proper port is selected,

enables the rest of the Function buttons

Exit – Terminates the demonstration program

Personalize – Displays the Card Personalization window as shown below (Input boxes with

red label are required data)

Personalize Card – Formats the smart card

and writes the information provided by the user

into the card

Reset Form – Erases contents of all input

boxes in the window
