Acer Aspire S7-392

Quick Guide

Product registration

When using your product for the first time, it is recommended that you immediately

•Faster service from our trained representatives.

•Membership in the Acer community: receive promotions and participate in customer

surveys.

•The latest news from Acer.

Hurry and register, as other advantages await you!

How to register

To register your Acer product, please visit www.acer.com. Select your country, click

PRODUCT REGISTRATION and follow the simple instructions.

You will also be asked to register your product during the setup process, or you can

double-click the Registration icon on the desktop.

After we receive your product registration, you will be sent a confirmation email with

important data that you should keep in a safe place.

Obtaining Acer accessories

We are happy to inform you that Acer's warranty extension program and Notebook

accessories are available online. Come and visit our online shop and find what you need

at store.acer.com.

The Acer store is being progressively rolled out, and, unfortunately may not be available

in some regions. Please check back regularly to see when it will be available in your

country.

Acer Aspire S7-392 Quick Guide

Orignial issue: 4/2013

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

English

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the Setup Poster helps you get started with setting up your

computer.

The Quick Guide introduces you to the basic features and functions of your

new computer.

For more on how your computer can help you to be more productive, please

refer to the User’s Manual.The User’s Manual contains useful information

applying to your new computer. It covers basic topics such as using the

keyboard and audio, etc.

This guide contains detailed information on such subjects as system utilities,

data recovery, expansion options and troubleshooting. In addition it contains

warranty information and the general regulations and safety notices for your

notebook.

Follow these steps to access it:

1 Type "User" from Start.

2 Click on Acer User’s Manual.

Your Acer notebook tour

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster, let us show

you around your new Acer computer.Screen view

#Icon Item Description

1 Ambient light sensor Controls the keyboard and monitor backlights.

2 Touchscreen Displays computer output, supports multi-

touch input.

Power indicator

Indicates the computer’s power status.

Blue: The computer is turned on.

Amber, slow flash: The computer is in

Standby.

Amber, fast flash: The computer is entering

Hibernate / Deep Sleep.

Battery indicator

Indicates battery status.

Amber: The battery is charging.

Blue: The battery is fully charged.

4 Webcam

Web camera for video communication.

A light next to the webcam indicates that the

webcam is active.

English

Keyboard view

#Icon Item Description

1Keyboard

For entering data into your computer.

Caution: Do not use a keyboard protector or

similar cover as the keyboard includes

ventilation intakes for cooling.

2Touchpad

Touch-sensitive pointing device.

The touchpad and selection buttons form a

single surface. 

Press down firmly on the touchpad surface to

perform a left click.



Press down firmly on the lower right corner to

perform a right click.

Front view

#Icon Item Description

1Microphones Internal stereo microphones for sound

recording.

Your Acer notebook tour

English

Left view

2 31 4

#Icon Item Description

1DC-in jack Connects to an AC adapter.

2Power button

Turns the computer on and off.

Note: The computer will also turn on by

opening the lid.

3USB port Connects to USB devices.

4SD card reader

Accepts one Secure Digital card (SD or

SDHC).

Note: To remove the card, simply pull it from

the slot.

Warning: The card sticks from the side of the

computer. Ensure you don’t damage your

card.

Information on USB 3.0

• USB 3.0 compatible ports are blue.

• Compatible with USB 3.0 and earlier devices.

• For optimal performance, use USB 3.0-certified devices.

• Defined by the USB 3.0 specification (SuperSpeed USB).

English

Right view

1234

#Icon Item Description

1Headset/speaker jack Connects to audio devices (e.g., speakers,

headphones) or a headset with microphone.

2USB port with power-

off charging Connects to USB devices.

3HDMI port Supports high-definition digital video

connections.

4Acer Converter port

Connects to the Acer Converter cable,

allowing for easy connection to a LAN, an

external display or an additional USB device.

Note: There are different cables available.

Please check with your retailer to see which

are compatible with your computer.

Information on USB 3.0

• USB 3.0 compatible ports are blue.

• Compatible with USB 3.0 and earlier devices.

• For optimal performance, use USB 3.0-certified devices.

• Defined by the USB 3.0 specification (SuperSpeed USB).

• Supports power-off USB charging, allowing you to charge supported mobile

devices while the notebook is switched off.

Using the keyboard

English

Base view

Using the keyboard

The keyboard has full-sized keys and separate cursor, Windows, function, and

special keys.

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other

key(s) in the hotkey combination.

#Icon Item Description

1 Battery reset pinhole

Simulates removing and reinstalling the

battery

Insert a paperclip into the hole and press for

four seconds to reset the computer.

2 Speakers Deliver stereo audio output.

Hotkey Icon Function Description

<Fn> + <Q> Communication Enables / disables the computer's

communication devices.

<Fn> + <W> Sleep Puts the computer in Sleep mode.

English

Note: To use Function keys (such as F1, F2 ...) press <Fn> and the

corresponding number key. Thus, <Fn> + <1> for <F1> etc.



During boot up, press <Fn> + <2> to access BIOS.

<Fn> + <E> Display toggle

Switches display output between the

display screen, external monitor (if

connected) and both.

<Fn> + <R> Display off

Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> + <T> Touchpad toggle Turns the built-in touchpad on and

off.

<Fn> + <Y> Speaker toggle Turns the speakers on and off.

<Fn> + <U>Decrease backlight

brightness

Decreases the brightness of the

keyboard backlight.

<Fn> + <I>Increase backlight

brightness

Increases the brightness of the

keyboard backlight.

<Fn> + <U> + <I> Backlight toggle

Turns the keyboard backlight on and

off.

Note: This function is disabled if the

light sensor detects a bright

environment.

<Fn> + <O> Rotate screen Rotates the image displayed on the

screen.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness down Decreases the screen brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

Hotkey Icon Function Description

Ver.: 01.01.01
