Contents

TravelMate Notebook Series

Quick Guide

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

TravelMate Notebook Series Quick Guide

Original Issue: 05/2010

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your computer.

The TravelMate Series Generic User Guide contains useful information applying

to all models in the TravelMate product series. It covers basic topics such as

using the keyboard and audio, etc. Please understand that due to its nature, the

AcerSystem User Guide mentioned below will occasionally refer to functions or

features which are only contained in certain models of the series, but not

necessarily in the model you purchased. Such instances are marked in the text

with language such as "only for certain models".

This Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster,

let us show you around your new Acer notebook.

Top view

#Icon Item Description

1 Microphones Stereo internal microphones for sound

recording.

2 Acer Crystal Eye

webcam

Web camera for video communication.

(only for certain models)

3 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output (Configuration

may vary by model).

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key

in the hotkey combination.

4 Keyboard For entering data into your computer.

5AcerBio-

Protection

fingerprint reader

The center button serves as the Acer Bio-

Protection fingerprint reader, supporting

Pre-Boot Authentication (PBA) computer

protection, Acer FingerLaunch.

6 Click buttons

(left and right)

The left and right buttons function like

the left and right mouse buttons.

7 Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

8 Power switch Turns the computer on and off.

9 Communication

indicator

Indicates the computer’s wireless

connectivity device status.

PAcer PowerSmart

key

Puts your computer into power-saving

mode (configuration may vary by model).

P key Programmable key (configuration may

vary by model).

10 Optical drive eject

button

Ejects the optical disk from the drive.

Hotkey Icon Function Description

<Fn> + <F3> Communication Enables / disables the computer’s

communication devices.

(Communication devices may vary by

configuration.)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle Switches display output between the

display screen, external monitor (if

connected) and both.

#Icon Item Description

English

Closed front view

<Fn> + <F6> Display off Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> + <F7> Touchpad

toggle

Turns the touchpad on and off.

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness

down

Decreases the screen brightness.

#Icon Item Description

1 Power indicator Indicates the computer's power

status.

Battery indicator Indicates the computer's battery

status.

1. Charging: The light shows amber

when the battery is charging.

2. Fully charged: The light shows

blue when in AC mode.

HDD indicator Indicates when the hard disk drive

is active.

Hotkey Icon Function Description

342

English

Rear view

Note: Your computer may be equipped with a different battery to

the one in the picture.

2 Multi-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory

Stick (MS), Memory Stick PRO (MS

PRO), xD-Picture Card (xD).

Note: Push to remove/install the

card. Only one card can operate at

any given time.

3Microphone-in jack Accepts inputs from external

microphones.

Headphones/speaker/

line-out jack

Connects to audio line-out devices

(e.g., speakers, headphones).

4 Speakers Front left and front right speakers

deliver stereo audio output.

#Icon Item Description

1 Battery Provides power for the computer to be used while

unplugged.

#Icon Item Description

English

Left view

Right view

#Icon Item Description

1 DC-in jack Connects to an AC adapter.

2 Ventilation slots Enable the computer to stay cool,

even after prolonged use.

3 Acer EasyPort

connector

Connects to the Acer EasyPort.

4 External display

(VGA) port

Connects to a display device (e.g.,

external monitor, LCD projector).

5 USB 2.0 port Connects to USB 2.0 devices (e.g.,

USB mouse, USB camera).

#Icon Item Description

1 Optical drive Internal optical drive; accepts CDs or

DVDs.

2 Optical disk access

indicator

Lights up when the optical drive is

active.

21345

213456
