SwitcHub-2se

&INO<GG<ODJI*<IP<G

Installation Manual

SwitcHub-2se

Smart

Fast Ethernet Switch

with one 10BASE-T/100BASE-TX Port

and one 100BASE-FX Port

No part of this document may be copied or reproduced in any form or by any means without the

prior written consent of Accton Technology Corporation.

Accton makes no warranties with respect to this documentation and disclaims any implied

warranties of merchantability, quality, or fitness for any particular purpose. The information in this

document is subject to change without notice. Accton reserves the right to make revisions to this

publication without obligation to notify any person or entity of any such changes.

,QWHUQDWLRQDO+HDGTXDUWHUV

No. 1 Creation Road III,

Science-based Industrial Park

Hsinchu 300, Taiwan, R.O.C.

Phone: 886-35-770-270

FAX: 886-35-770-267

BBS: 886-35-770-654

Internet: [email protected]

86$+HDGTXDUWHUV

1962 Zanker Road

San Jose, CA 95112

Phone: 408-452-8900

FAX: 408-452-8988

BBS: 408-452-8828

FAST FAX: 408-452-8811

Accton, SmartWatch and SwitcHub are trademarks or registered trademarks of Accton Technology

Corporation. Other trademarks or brand names mentioned herein are trademarks or registered

trademarks of their respective companies.

ES3002-TF

E0596-R01

150050-101

Package Contents i

Package Contents

Carefully unpack the contents of the package and verify them against the checklist

given below.

Package Checklist

æFast SwitcHub-2se

(Model No. ES3002-TF)

æAC power cord

æFour rubber foot pads

æInstallation manual

æOwner registration card

Please inform your dealer immediately should there be any wrong, missing or

damaged parts.

If possible, retain the carton, including the original packing materials. Use

them again to repack the unit in case there is a need to return it for repair.

To qualify for product updates and product warranty registration, fill in the

Owner Registration Card and return it to Accton Technology Corporation.

Quick Installation iii

Quick Installation

The Fast SwitcHub-2se contains 2 Ethernet ports that can operate at full-duplex or

half-duplex. One of these ports supports 100BASE-TX or 10BASE-T (twisted-

pair) connection, while the other port supports 100BASE-FX (fiber optic)

connection. The smart design built into the front display panel and configure

options, provides a friendly interface that simplifies installation and network

troubleshooting. If you are already familiar with basic network operations, you

should be able to install this switch as described below:

1. Unpack the Fast SwitcHub-2se.

2. Find a location close to the network devices you need to connect, and within

easy reach of an electrical outlet.

3. For 100BASE-TX or 10BASE-T devices, connect a workstation or server to

the Port 1 MDI-X station port. Otherwise, you can connect to another switch

or other network interconnection device by running straight-through twisted-

pair cable between the MDI daisy-chain port on one device (e.g., Port 1 on

this switch) to the MDI-X station port on the other device. Use 100W

Category 5 STP or UTP cable to connect to the switch, and be sure the

length of any twisted-pair connection does not exceed 100 meters.

For integrating legacy networks, Port 1 provides for connection via either

100BASE-TX or 10BASE-T. It uses auto-negotiation to dynamically set the

required transmission speed at 10 or 100 Mbps.

4. For 100BASE-FX devices, connect to Port 2 (i.e., connecting the Rx/Tx

jacks on the target device to the Tx/Rx jacks on the switch). When

connecting a node to Port 2, the maximum cable length is 2 kilometers if you

are have a dedicated link (i.e., full-duplex mode); otherwise, the maximum

length is 412 meters for a shared collision domain (i.e., a half-duplex

connection). Refer to Chapter 2 for a more detailed description of

calculating the maximum length permitted for fiber optic cable.

Fast SwitcHub-2se User’s Guide

iv Quick Installation

5. Set the transmission mode for each port to full or half-duplex. Full-duplex

communications can only be supported for a dedicated link (i.e., set the

communications to half duplex if you are connecting to a shared collision

domain). Transmission must be set to full duplex or half duplex depending

on the mode supported by the connected device. You must manually set the

required mode with the configure button (Chapter 2).

6. Verify network communications by ensuring that -

• you have made all the necessary connections

• you can access any connected resources

• the switch’s indicator LEDs are functioning properly

Note: For devices connected directly to either port on the switch, it will

automatically detect transmission speed (10/100 Mbps). However, unless

the connected devices are operating at half-duplex (i.e., system default), you

will have to manually set the transmission mode via the configure button.

(Refer to Full/Half Duplex Mode Selection in Chapter 2).

If you encounter any problems in installing the Fast SwitcHub-2se, refer to Chapter

2 for a detailed description of installation procedures, or to Appendix A for help

in troubleshooting.

About this Guide v

About this Guide

This guide is designed for the experienced network installer. It describes how

to install and operate Accton’s Fast SwitcHub-2se Ethernet switch. After

reading this manual, you should be able to use the front display panel and

configure options to manage all your network connections.

This manual covers the following topics:

Chapter 1 - Product Overview

Brief description of switching technology, followed by a description of this switch

and a summary of its important features and specifications.

Chapter 2 - Setup and Configuration

Installing a Fast SwitcHub-2se and making basic network connections. Shows

sample network configurations for a local area network.

Chapter 3 - Hardware Reference

Detailed description of indicator panel and ports.

Appendices - Troubleshooting, cable assignments, and product specifications.

Contents

vii

Chapter 1: Introduction...........................................................1-1

Switching Technology...............................................................................................1-1

Accton’s Smart Extender...........................................................................................1-2

Switching Methods....................................................................................................1-3

Features of the Fast SwitcHub-2se............................................................................1-4

Chapter 2: Setup and Configuration......................................2-1

Pre-Installation Requirements ...................................................................................2-1

Connecting the Switch System..................................................................................2-1

Making RJ-45 Connections..................................................................................2-2

Making Fiber Optic Connections..........................................................................2-3

Providing Power to the SwitcHub.............................................................................2-4

Diagnostic Tests........................................................................................................2-5

Upon Power On ..............................................................................................2-5

During Normal Operation...............................................................................2-5

Setting the Display Mode..........................................................................................2-5

Selections Available.............................................................................................2-6

Bandwidth Utilization.....................................................................................2-6

Packet Forwarding Ratio.................................................................................2-6

Packet Filtering Ratio .....................................................................................2-7

Collision Ratio................................................................................................2-7

Full/Half Duplex Mode Selection...................................................................2-7

Diagnostic Function........................................................................................2-8

Verifying Port Status.................................................................................................2-8

Verifying System Operation......................................................................................2-9

Fast SwitcHub-2se User’s Guide

viii Contents

Chapter 3: Hardware Reference.............................................3-1

Front Panel ...............................................................................................................3-1

Configure Button..................................................................................................3-2

SmartWatch Indicator Panel.................................................................................3-3

Power..............................................................................................................3-3

Statistical Display for System Performance....................................................3-4

Setting the Communication Mode ..................................................................3-6

Diagnostics Display Mode..............................................................................3-7

Port Status Display..........................................................................................3-8

Rear Panel ...............................................................................................................3-10

Ethernet Ports.......................................................................................................3-10

Power Socket........................................................................................................3-11

Appendix A: Troubleshooting................................................A-1

Diagnosing Hub Indicators........................................................................................A-1

System Diagnostics ...................................................................................................A-2

Installation............................................................................................................A-2

Configuration........................................................................................................A-2

Switch Integrity....................................................................................................A-3

Appendix B: Port and Cable Assignments.............................B-1

RJ-45 Port ...............................................................................................................B-1

Appendix C: Specifications....................................................C-1

Product Specifications...............................................................................................C-1

Fast SwitcHub-2se User’s Guide

Contents ix

Appendix D: Regulatory Standards Compliance..................D-1

EMI Warning ............................................................................................................D-1

FCC Class B Certification....................................................................................D-1

Voluntary Control Council for Interference (VCCI-2).........................................D-2

EN55022 Declaration of Conformance ................................................................D-3

Safety Compliance.....................................................................................................D-4

Underwriters Laboratories Compliance Statement...............................................D-4

Sicherheitshinweise..............................................................................................D-5

Appendix E: Product Support Services ................................E-1

Product Registration..................................................................................................E-1

Problem Report .........................................................................................................E-1

Hardware Repair Service...........................................................................................E-1

Software Update and Upgrade Service......................................................................E-2

Bulletin Board Service (BBS) ...................................................................................E-2

Interactive Fast Fax (U.S.A. office) ..........................................................................E-2

Technical Support .....................................................................................................E-3

Limited Warranty......................................................................................................E-4

Customer Remedies..............................................................................................E-4

Return Process......................................................................................................E-5

Accton Offices...........................................................................................................E-6

Ordering Information ................................................................................................E-6

Glossary

Index

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Accton Technology

Accton Technology

Accton Technology USB204A Manual de usuario

Accton Technology

Accton Technology ETHERHUB-16MI+ E0398-R01 Manual de usuario

Accton Technology

Accton Technology Zilla Dual-Speed Hub-3008R Manual de usuario

Accton Technology

Accton Technology CheetaHub Power-3008P Manual de usuario

Accton Technology

Accton Technology ETHERHUB-16MI+ E0398-R01 Manual de usuario

Accton Technology

Accton Technology Classic-2040 Manual de usuario

Accton Technology

Accton Technology Fast EtherHub-8s Manual de usuario

Accton Technology

Accton Technology SuperSmart EtherHub-16se Manual de usuario

Accton Technology

Accton Technology VM2524 Manual de usuario

Accton Technology

Accton Technology Volare Sensor 2 Manual de usuario

Accton Technology

Accton Technology USB204B Manual de usuario

Accton Technology

Accton Technology CheetaHub Power-3012B Manual de usuario

Accton Technology

Accton Technology EtherHub-16 Manual de usuario

Accton Technology

Accton Technology CheetaHub Power-3008A Manual de usuario

Accton Technology

Accton Technology VS4512DC Manual de programación

Accton Technology

Accton Technology CheetahSwitch Workgroup-2027 Manual de usuario

Accton Technology

Accton Technology ES3616 Manual de programación

Accton Technology

Accton Technology EH3008D Manual de usuario

Accton Technology

Accton Technology CheetahSwitch Workgroup-3627 Manual de usuario

Accton Technology

Accton Technology EH2045S Manual de usuario

Accton Technology

Accton Technology CHEETAHUB POWER-3012A Manual de usuario

Accton Technology

Accton Technology CheetahSwitch Workgroup-3726M Manual de usuario

Accton Technology

Accton Technology 24/48 10/100 Ports + 2GE Manual de programación

Accton Technology

Accton Technology CheetaHub Power-3004E Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
