ABB Relion RED615 Manual de usuario

Relion® 615 series

Line Differential Protection and Control

RED615

DNP3 Point List Manual

Document ID: 1MRS756879

Issued: 03.07.2009

Revision: A

Product version: 2.0

This document and parts thereof must not be reproduced or copied without written

permission from ABB, and the contents thereof must not be imparted to a third

party, nor used for any unauthorized purpose.

The software or hardware described in this document is furnished under a license

and may be used, copied, or disclosed only in accordance with the terms of such

license.

Trademarks

ABB and Relion are registered trademarks of ABB Group. All other brand or

product names mentioned in this document may be trademarks or registered

trademarks of their respective holders.

Guarantee

Please inquire about the terms of guarantee from your nearest ABB representative.

ABB Oy

Distribution Automation

P.O. Box 699

FI-65101 Vaasa, Finland

Telephone: +358 10 2211

Facsimile: +358 10 22 41094

http://www.abb.com/substationautomation

Disclaimer

The data, examples and diagrams in this manual are included solely for the concept

or product description and are not to be deemed as a statement of guaranteed

properties. All persons responsible for applying the equipment addressed in this

manual must satisfy themselves that each intended application is suitable and

acceptable, including that any applicable safety or other operational requirements

are complied with. In particular, any risks in applications where a system failure and/

or product failure would create a risk for harm to property or persons (including but

not limited to personal injuries or death) shall be the sole responsibility of the

person or entity applying the equipment, and those so responsible are hereby

requested to ensure that all measures are taken to exclude or mitigate such risks.

This document has been carefully checked by ABB but deviations cannot be

completely ruled out. In case any errors are detected, the reader is kindly requested

to notify the manufacturer. Other than under explicit contractual commitments, in

no event shall ABB be responsible or liable for any loss or damage resulting from

the use of this manual or the application of the equipment.

Conformity

This product complies with the directive of the Council of the European

Communities on the approximation of the laws of the Member States relating to

electromagnetic compatibility (EMC Directive 2004/108/EC) and concerning

electrical equipment for use within specified voltage limits (Low-voltage directive

2006/95/EC). This conformity is the result of tests conducted by ABB in

accordance with the product standards EN 50263 and EN 60255-26 for the EMC

directive, and with the product standards EN 60255-6 and EN 60255-27 for the low

voltage directive. The IED is designed in accordance with the international

standards of the IEC 60255 series.

Table of contents

Section 1 Introduction.......................................................................3

This manual........................................................................................3

Intended audience..............................................................................3

Product documentation.......................................................................4

Product documentation set............................................................4

Document revision history.............................................................5

Related documentation..................................................................5

Document symbols and conventions..................................................6

Safety indication symbols..............................................................6

Document conventions..................................................................6

Functions, codes and symbols......................................................7

Section 2 DNP3 data mappings.......................................................9

Overview.............................................................................................9

Point list for RED615 Ver.2.0 DE01-03............................................10

Section 3 DNP3 protocol implementation.......................................19

DNP3 device profile..........................................................................19

DNP3 implementation table..............................................................21

Section 4 Glossary.........................................................................25

Table of contents

RED615 1

Point List Manual

Section 1 Introduction

1.1 This manual

Point List Manual describes the outlook and properties of the data points specific to

the IED. The manual should be used in conjunction with the corresponding

Communication Protocol Manual.

1.2 Intended audience

This manual addresses the communication system engineer or system integrator

responsible for pre-engineering and engineering for communication setup in a

substation from an IED perspective.

The system engineer or system integrator must have a basic knowledge of

communication in protection and control systems and thorough knowledge of the

specific communication protocol.

1MRS756879 A Section 1

Introduction

RED615 3

Point List Manual

1.3 Product documentation

1.3.1 Product documentation set

Planning & purchase

Engineering

Installing

Commissioning

Operation

Maintenance

Decommissioning

deinstalling & disposal

Application manual

Operation manual

Installation manual

Service manual

Engineering manual

Commissioning manual

Communication protocol

manual

Technical manual

Planning & purchase

Engineering

Installing

Commissioning

Operation

Maintenance

Decommissioning

deinstalling & disposal

Planning & purchase

Engineering

Installing

Commissioning

Operation

Maintenance

Decommissioning

deinstalling & disposal

Application manualApplication manual

Operation manualOperation manual

Installation manualInstallation manual

Service manualService manual

Engineering manualEngineering manual

Commissioning manualCommissioning manual

Communication protocol

manual

Communication protocol

manual

Technical manualTechnical manual

en07000220.vsd

IEC07000220 V1 EN

Figure 1: The intended use of manuals in different lifecycles

Engineering Manual contains instructions on how to engineer the IEDs. The

manual provides instructions on how to use the different tools for IED engineering.

It also includes instructions on how to handle the tool component available to read

disturbance files from the IEDs on the basis of the IEC 61850 definitions. It further

introduces the diagnostic tool components available for IEDs and the PCM600 tool.

Installation Manual contains instructions on how to install the IED. The manual

provides procedures for mechanical and electrical installation. The chapters are

organized in chronological order in which the IED should be installed.

Commissioning Manual contains instructions on how to commission the IED. The

manual can also be used as a reference during periodic testing. The manual

provides procedures for energizing and checking of external circuitry, setting and

configuration as well as verifying settings and performing directional tests. The

Section 1 1MRS756879 A

Introduction

4RED615

Point List Manual
