ABB Relion 620 Series Manual de usuario
Relion® 620 series
Advanced Recloser Protection and Control
RER620
IEC 60870-5-101/104 Point List Manual
Document ID: 1MAC302441-MB
Issued: 11/23/2010
Revision: A
Product version: 1.0
© Copyright 2010 ABB. All rights reserved.
Copyright
This document and parts thereof must not be reproduced or copied without written
permission from ABB, and the contents thereof must not be imparted to a third party, nor
used for any unauthorized purpose.
The software or hardware described in this document is furnished under a license and may
be used, copied, or disclosed only in accordance with the terms of such license.
Trademarks
ABB and Relion are registered trademarks of ABB Group. All other brand or product
names mentioned in this document may be trademarks or registered trademarks of their
respective holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB representative.
ABB Inc.
Distribution Automation
4300 Coral Ridge Drive
Coral Springs, FL 33065, USA
Toll-free: 1 (800) 523-2620
Phone: +1 954-752-6700
Fax: +1 954 345-5329
http://www.abb.com/substationautomation
Disclaimer
The data, examples and diagrams in this manual are included solely for the concept or
product description and are not to be deemed as a statement of guaranteed properties. All
persons responsible for applying the equipment addressed in this manual must satisfy
themselves that each intended application is suitable and acceptable, including that any
applicable safety or other operational requirements are complied with. In particular, any
risks in applications where a system failure and/or product failure would create a risk for
harm to property or persons (including but not limited to personal injuries or death) shall
be the sole responsibility of the person or entity applying the equipment, and those so
responsible are hereby requested to ensure that all measures are taken to exclude or
mitigate such risks.
This document has been carefully checked by ABB but deviations cannot be completely
ruled out. In case any errors are detected, the reader is kindly requested to notify the
manufacturer. Other than under explicit contractual commitments, in no event shall ABB
be responsible or liable for any loss or damage resulting from the use of this manual or the
application of the equipment.
Conformity
This product complies with the directive of the Council of the European Communities on
the approximation of the laws of the Member States relating to electromagnetic
compatibility (EMC Directive 2004/108/EC) and concerning electrical equipment for use
within specified voltage limits (Low-voltage directive 2006/95/EC). This conformity is
the result of tests conducted by ABB in accordance with the product standards EN 50263
and EN 60255-26 for the directive, and with the product standards EN 60255-6 and EN
60255-27 for the directive. The IED is designed in accordance with the international
standards of the IEC 60255 series and ANSI C37.90. The DNP protocol implementation
in the IED conforms to "DNP3 Intelligent Electronic Device (IED) Certification Procedure
Subset Level 2", available at www.dnp.org.
1MAC302441-MB A Table of contents
RER620 1
Point List Manual
Table of contents
Section 1 Introduction........................................................................... 3
This manual.............................................................................................. 3
Intended audience.................................................................................... 3
Product documentation ............................................................................ 4
Product documentation set ................................................................. 4
Document revision history................................................................... 5
Related documentation ....................................................................... 5
Symbols and conventions ........................................................................ 5
Safety indication symbols.................................................................... 5
Manual conventions ............................................................................ 6
Functions, codes and symbols............................................................ 7
Section 2 IEC 60870-5-101/104 data mappings ................................ 11
Overview ................................................................................................ 11
Point list for RER620 Ver. 1.0 ................................................................ 12
Section 3 IEC 60870-5-101/104 protocol implementation.................. 39
Section 4 Glossary ............................................................................. 51
Table of contents 1MAC302441-MB A
2 RER620
Point List Manual
1MAC302441-MB A Section 1
Introduction
RER620 3
Point List Manual
Section 1 Introduction
1.1 This manual
The point list manual describes the outlook and properties of the data points specific to the
IED. The manual should be used in conjunction with the corresponding communication
protocol manual.
1.2 Intended audience
This manual addresses the communication system engineer or system integrator
responsible for pre-engineering and engineering for communication setup in a substation
from an IED perspective.
The system engineer or system integrator must have a basic knowledge of communication
in protection and control systems and thorough knowledge of the specific communication
protocol.
Section 1 1MAC302441-MB A
Introduction
4 RER620
Point List Manual
1.3 Product documentation
1.3.1 Product documentation set
Figure 1: The intended use of manuals in different lifecycles
The engineering manual contains instructions on how to engineer the IED using the
different tools in PCM600. The manual provides instructions on how to set up a PCM600
project and insert IEDs in the project structure. The manual also recommends a sequence
for engineering of protection and control functions, LHMI functions, and communication
engineering for IEC 61850 and DNP3.
The installation manual contains instructions on how to install the IED. The manual
provides procedures for mechanical and electrical installation. The chapters are organized
in chronological order in which the IED should be installed.
The operation manual contains instructions on how to operate the IED once it has been
commissioned. The manual provides instructions for monitoring, controlling and setting
the IED. The manual also describes how to identify disturbances and how to view
calculated and measured power grid data to determine the cause of a fault.
The application manual contains application descriptions and setting guidelines sorted per
function. The manual can be used to find out when and for what purpose a typical
protection function can be used. The manual can also be used when calculating settings.
The technical manual contains application and functionality descriptions and lists function
blocks, logic diagrams, input and output signals, setting parameters and technical data
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning
Deinstalling & Disposal
Application manual
Operation manual
Installation manual
Engineering manual
Communication Protocol
manual
Technical manual
Protocol Points List
manual
