ABB FENA-21 Manual de instalación

Options for ABB drives, converters and inverters

Quick installation and start-up guide

FENA-21 Ethernet adapter module

Safety instructions

WARNING! Obey the safety instructions. If you ignore them, injury or death, or damage to the

equipment can occur. See the user’s manual.

Mechanical installation

Electrical installation

Layout of the module

1. Pull out the lock.

2. Install the module carefully to an option

module slot of the drive. See the drive

hardware manual.

3. Push in the lock.

4. Tighten the screw to torque 0.8 N·m using

a Torx TX10 screwdriver.

WARNING! Do not use excessive force,

or leave the screw too loose. Over-

tightening can damage the screw or

module. A loose screw decreases the EMC

performance, and can even cause an operation

failure.

No. Description

1Lock

2 Mounting and grounding screw

3 RJ-45 connector [X1] to Ethernet

4 RJ-45 connector [X2] for chaining another module

5 Diagnostic LEDs

6 MAC ID

Start-up

When the module is connected to the drive, the drive control program sets the applicable parameters.

See the appropriate drive manual.

Basic parameter settings

Protocol-specific parameter settings

To take the settings into use, validate and refresh the parameters with parameter 51.27 FBA par refresh.

Further information

Index Name Value

20.01 Ext1 commands Fieldbus A

22.11 Speed ref1 source FBAAref 1

28.11 Frequency ref1 source FBAAref 1

50.01 FBAAenable Enable (or select the option slot in which the module is installed).

This activates the communication module. The HOST LED becomes green.

50.02 FBAAcomm loss func Fault

PROFINET IO Ethernet/IP

Index Name Value Index Name Value

51.02 Protocol/Profile PNIO ABB Pro 51.02 Protocol/Profile EIP AC/DC

51.04 IP configuration Static IP 51.04 IP configuration Set the IP address

according your network

configuration.

51.05...08 IP address 0.0.0.0 51.05...08 IP address

51.09 Subnet CIDR 0 51.09 Subnet CIDR

52.01 FBAA data in1 SW 16bit 51.23 Speed scale 128

52.02 FBAA data in2 Act 16bit

53.01 FBAA data out1 CW 16bit Modbus/TCP

53.02 FBAA data out2 Ref1 16bit Index Name Value

51.02 Protocol/Profile Modbus/TCP

51.04 IP configuration Set the IP address

according your network

configuration.

Connectivity configuration 51.05...08 IP address

To access the configuration web page:

1. Open a web browser and type the IP address of the

adapter module in the address field.

2. Log in with a user name (admin) and a password (The

last six digits of the MAC address of the adapter module,

in upper case letters, without hyphens. Eg, if MAC ID is

00-1C-01-00-2F-73, the password is 002F73).

51.09 Subnet CIDR

See the latest version of FENA-01/-11/-21 Ethernet adapter

module user’s manual (3AUA0000093568 [English]) in

ABB library (www.abb.com/drives/documents).

For more information on fieldbus options and protocols

provided by ABB Drives, see the fieldbus

communications web page

(new.abb.com/drives/connectivity/fieldbus-connectivity).

3AXD50000158522 Rev A (EN) 2017-11-23

FENA-01/-11/-21 manual

Fieldbus communications web page

Otros manuales para FENA-21
