Aaeon SBC-657B Manual de usuario

SBC-657B / HSB-657I

VIA C3EdenCPU

Half-Size CPU Card

With LCD, Ethernet, PC/104 &

CompactFlash, USB

SBC-657 Rev.B / HSB-657I Rev.A Manual 1

st Ed.

Nov. 2003

Half-Size CPU Card SBC-657B / HSB-657I

This document is copyrighted, 2003. All rights are reserved. The

original manufacturer reserves the right to make improvements to

the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in

this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no responsibility for its use, or for

any infringements upon the rights of third parties that may result

from its use.

The material inthis document is for product information only and

is subject to change without notice. While reasonable efforts have

been made in the preparation of this document to assure its

accuracy, AAEON assumes no liabilities resulting from errors or

omissions in this document, or from the use of the information

contained herein.

AAEON reserves the right to make changes in the product design

without notice to its users.

Half-Size CPU Card SBC-657B / HSB-657I

Acknowledgments

All other products’name or trademarks are properties of their respective

owners.

lAward is a trademark of Award Software International, Inc.

lCompactFlash™is a trademark of the Compact Flash Association.

lMicrosoft Windows®is a registered trademark of Microsoft Corp.

lIBM, PC/AT, PS/2, and VGA are trademarks of International Business

Machines Corporation.

Half-Size CPU Card SBC-657B / HSB-657I

iii

Packing List

Before you begin installing your card, please make sure that the

following materials have been shipped:

•1 SBC-657B & HSB-657I Half-Size CPU Card

•1 Quick Installation Guide

•1 CD-ROM for manual (in PDF format) anddrivers

•1Short copper and support

•1Jumper Cap

•1Cable Accessory

If any of these itemsshould bemissing or damaged, please contact

your distributoror sales representative immediately.

Half-Size CPU Card SBC-657B / HSB-657I

Contents

Chapter 1 General Information

1.1Introduction..................................................................................1-2

1.2Features .........................................................................................1-3

1.3Specifications ................................................................................1-4

Chapter 2 Quick Installation Guide

2.1 Safety Precautions........................................................................2-2

2.2 Location of Connectors and Jumpers........................................2-3

2.3Mechanical Drawing.....................................................................2-7

2.4List of Jumpers .............................................................................2-11

2.5 List of Connectors........................................................................2-12

2.6Setting Jumpers.............................................................................2-13

2.7COM2 Ring signal select (JP1)....................................................2-14

2.8Clear CMOS (JP2)........................................................................2-14

2.9 RS-232/422/485 Setting (JP4)....................................................2-14

2.10 RS-232/422/485 Setting (JP5)..................................................2-15

2.11 LCD Shift Clock Select (JP6)....................................................2-15

2.12 LCD Voltage Setting (JP7)........................................................2-15

2.13 Power Connector (ATX Power) (PWR1)................................2-16

2.14 FAN Connector (CN1)..............................................................2-16

2.15 Keyboard and Mouse Connector (CN2) .................................2-17

2.16 Parallel Port Connector (CN3) .................................................2-17

2.17 Floppy Connector (CN4) ..........................................................2-18

Half-Size CPU Card SBC-657B / HSB-657I

2.18 IR Connector (CN5)..................................................................2-18

2.19 Front Panel Connector (CN6)..................................................2-19

2.20 Optional PME Connector (CN7).............................................2-19

2.21 IDE Hard Drive Connector (CN8)..........................................2-20

2.22 USB Connectors (CN9/CN11)................................................2-21

2.23 CompactFlashDisk Connector (CN10)..............................2-22

2.24 10/100Base-T RJ-45 Ethernet Connector (CN12) ................2-23

2.25 COM1/3/4 RS-232 Serial Port Connector (CN13/CN21/CN22)

..............................................................................................................2-24

2.26 COM2 RS-232/422/485 Serial Port Connector (CN14).......2-24

2.27 VGA Display Connector (CN15).............................................2-25

2.28 TTL_LCD Connector (CN16/CN17).....................................2-25

2.29 Channel 1 LVDS Connector (CN18).......................................2-27

2.30 Channel 2 LVDS Connector (CN19).......................................2-27

2.31 Backplane ATX Power Connecotr (CN24).............................2-28

2.32 Internal Mouse Connector (CN25)..........................................2-28

2.33 Internal Keyboard Connector (CN26).....................................2-28

Chapter 3 Award BIOS Setup

3.1 System test and initialization.......................................................3-2

3.2 Award BIOS setup.......................................................................3-3

3.3 Standard CMOS Features ............................................................3-6

3.4 Advanced BIOS Features ............................................................3-7

3.5 Advanced Chipset Features.........................................................3-8

3.6 Integrated Peripherals..................................................................3-9

3.7 Power Management Setup...........................................................3-10

Half-Size CPU Card SBC-657B / HSB-657I

3.8 PnP/PCI Configurations.............................................................3-11

3.9 PC Health Status...........................................................................3-12

3.10 Frequency/Voltage Control......................................................3-13

3.11 Load Fail-Safe Defaults.............................................................3-14

3.12 Load Optimized Defaults..........................................................3-14

3.13 Set Supervisor/User Password .................................................3-14

3.14 Save & Exit setup.......................................................................3-15

3.15 Exit Without Saving...................................................................3-15

Chapter 4 Driver Installation

4.1 Installation 1..................................................................................4-3

4.2 Installation 2..................................................................................4-4

Appendix A Programming the WatchDog Timer

Programming......................................................................................A-2

Half-Size CPU Card SBC-657B / HSB-657I

Chapter 1 General Information 1-1

General

Information

Chapter

Half-Size CPU Card SBC-657B / HSB-657I

Chapter 1 General Information

1.1 Introduction

Half-size CPU Card, SBC-657B / HSB-657I, is powered by VIA

C3series microprocessor with a maximum of 800MHz high

process speed. Featured with CoolStreamarchitecture, it

performs as a strengthened single board computer with low

power consumption while no CPU fan required.

Onboard VIA ProSavagePN133 chipset integrates various

functions, including excellent display presentation ability.

Featured with AGP 4X, the throughput can reach as high as

1.07GB per second. LCD interface is both provided by TTL and

LVDS up to 36 bit. Also, supporting CRT and LCD to display at

the same time offers wider media applications.

One RJ-45 Ethernet connector comes with a maximum data

transfer rate of 100MB per second. The 7.3” x 4.8” computer

board is connected to the infinite LAN world. Four serial ports

are designed particularly for industry standard applications and

offering various devices connection ability. And, four USB ports

provide Plug-and-Play pleasant uses.

Implementing 16-bit Industry Standard Architecture (ISA)

interface makes it easy to apply onto a wide range of industry

fields. Industrial standard Type II CompactFlashslot performs

as a mobile memory device with utilization freedom. PC/104

socket is reserved for further function expansion interface.

Overall, this powerful CPU card is a high-end computer board

for implementation.

Half-Size CPU Card SBC-657B / HSB-657I

Chapter 1 General Information

1.2Features

•Supports VIA C3Processor up to 800MHz

•Integrated AGP 4X 2D/3D graphic accelerator

•36-bit TTL/LVDS TFT LCD

•10/100Mbps Fast Ethernet

•Supports Type II CompacFlashMemory

•PC/104 expansion interface

•ISA interface
