Aaeon PCM-8200 Manual de usuario

Compact Board PCM-8200

PCM-8200

Intel® Pentium® M and

Celeron® M processors

Compact Board

With LVDS LCD, TV-Out,

Ethernet, Audio, CompactFlash TM,

USB, 4 COMs & Mini PCI

PCM-8200 Rev. A Manual 1

st Ed.

Apr. 2004

Compact Board PCM-8200

This document is copyrighted, 2004. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products

described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in this

manual is intended to be accurate and reliable. However, the original

manufacturer assumes no responsibility for its use, or for any in-

fringements upon the rights of third parties that may result from its use.

The material inthis document is for product information only and is

subject to change without notice. While reasonable efforts have been

made in the preparation of this document to assure its accuracy, AAEON

assumes no liabilities resulting from errors or omissions in this document,

or from the use of the information contained herein.

AAEON reserves the right to make changes in the product design without

notice to its users.

Compact Board PCM-8200

Acknowledgments

All other product s’name or trademarks are properties of their respective owners.

lAward is a trademark of Award Software International, Inc.

lCompactFlash™is a trademark of the Compact Flash Association.

lIntel® ,Pentium®4, and Celeron® are trademarks of Intel® Corporation.

lMicrosoft Windows®is a registered trademark of Microsoft Corp.

lITE is a trademark of Integrated Technology Express, Inc.

lIBM, PC/AT, PS/2, and VGA are trademarks of International Business

Machines Corporation.

lSoundBlaster is a trademark of Creative Labs, Inc.

Compact Board PCM-8200

iii

Packing List

Before you begin installing your card, please make sure that the following

materials have been shipped:

•1 CPU Card

•1 Quick Installation Guide

•1 CD-ROM for manual (in PDF format) and drivers

•1 Jumper cap

If any of these items should be missing or damaged, please contact your

distributor or sales representative immediately.

Compact Board PCM-8200

Contents

Chapter 1 General Information

1.1Introduction ...................................................................................1-2

1.2Features ..........................................................................................1-4

1.3Specifications .................................................................................1-5

Chapter 2 Quick Installation Guide

2.1 Safety Precautions .........................................................................2-2

2.2 Location of Connectors and Jumpers .........................................2-3

2.3 Mechanical Drawing......................................................................2-5

2.4 List of Jumpers ..............................................................................2-7

2.5 List of Connectors .........................................................................2-8

2.6 Setting Jumpers..............................................................................2-10

2.7 LCD Voltage Selection (JP2) .......................................................2-11

2.8 Audio Out Selection (JP3)............................................................2-11

2.9 Clear CMOS (JP4).........................................................................2-11

2.10 COM2 RS-232/422/485 Selection (JP5, JP6 & JP7)..............2-11

2.11 COM2 Ring/+5V/+12V Selection (JP8).................................2-12

2.12 Channel2 LVDS Connector (CN1)...........................................2-12

2.13 VGA Display Connector (CN2) ................................................2-13

2.14 Front Panel Connector (CN3)...................................................2-13

2.15 FAN Connector (CN4)...............................................................2-13

2.16 Channel1 LVDS Connector (CN5)...........................................2-14

2.17 ATX Power Connector (CN6) ..................................................2-14

Compact Board PCM-8200

2.18 LAN LED Connector (CN7) ....................................................2-15

2.19 Option PME Connector (CN8).................................................2-15

2.20 Audio Connector (CN9).............................................................2-15

2.21 TV_Out Connector (CN10) ......................................................2-16

2.22 DVI Connector (CN11) .............................................................2-16

2.23 Audio 5.1 Channel/SPDIF Connector (CN12).......................2-17

2.24 USB Connector (CN13 & CN14).............................................2-17

2.25 LPT Port Connector (CN15).....................................................2-18

2.26 FAN Connector (CN16)............................................................2-18

2.27 IrDA Connector (CN17) ............................................................2-19

2.28 Digital I/O-2Connector (CN18) ..............................................2-19

2.29 Keyboard/Mouse Connector (CN19) ......................................2-20

2.30 RS-232/422/485 Serial Port Connector (CN20).....................2-21

2.31 Digital I/O-1 Connector (CN21) ..............................................2-22

Chapter 3 Award BIOS Setup

3.1 System Test and Initialization. .....................................................3-2

3.2 Award BIOS Setup........................................................................3-3

3.3 Standard CMOS Features .............................................................3-6

3.4 Advanced BIOS Features .............................................................3-7

3.5 Advanced Chipset Features ..........................................................3-8

3.6 Integrated Peripherals ...................................................................3-9

3.7 Power management Setup............................................................3-10

3.8 PnP/PCI configuration ................................................................3-11

3.9 PC Health Status............................................................................3-12

3.10 Frequency/Voltage Control .......................................................3-13

Compact Board PCM-8200

3.11 Load Fail-Safe Defaults ..............................................................3-14

3.12 Load Optimized Defaults...........................................................3-15

3.13 Set Supervisor/User Password ..................................................3-16

3.14 Save &Exit Setup........................................................................3-17

3.15 Exit without Saving .....................................................................3-18

Chapter 4 Driver Installation

4.1 Installation......................................................................................4-3

Appendix A I/O Information

A.1 I/O Address Map .................................................................... A-2

A.2 1st MB Memory Address Map ................................................ A-2

A.3 IRQ Mapping Chart ................................................................ A-3

A.4 DMA Channel Assignments .................................................. A-3

Appendix B Programming the Watchdog Timer

B.1 Programming.............................................................................B-2

B.2 IT8712 Watchdog Timer Initial Program ..............................B-6

Compact Board PCM-8200

Chapter 1 General Information 1-1

General

Information

Chapter

Compact Board PCM-8200

Chapter 1 General Information

1.1 Introduction

PCM-8200 series are powered by the IntelPentiumM processor with

the Intel® 855GME chipset and new Intel6300ESB I/O Controller

South Bridge integrated.PCM-8200 is delicately designed for

working-efficiency with low power consumption and simple voltage input

required application.(5V only workable)

Outstanding Power Efficiency

The PCM-8200 supports IntelPentiumM / CeleronM processorsup

to 1.60GHz with 400MHz FSB. System memory holds up to 1GB with fast

DDR 333MHz providing high calculate and graphic ability but with extreme

low power consumption.This feature is especially suitable for Video,

Automation controller, Multimedia application.

Besides the excellent CPU performance, PCM-8200 also provides multiple

display functions, it allows user to display different content on CRT/LCD,

CRT/DVI,CRT/TV,LCD/DVI or LCD/TVthis feature opens a shortcut

to multi-display demander with cheaper solution. PCM-8200 does really the

most power efficiency board that you can find at this moment.

Maximum Expansion Interface

PCM-8200 provides interface capabilities of two ports serial ATA controller;

USB 2.0 host controller support up to 4 USB ports (Support Embedded

USB DOM); four serial I/O ports support and Watchdog Timer support. In

addition, the excellent 48/24/18-bit LVDS supports high quality

Compact Board PCM-8200

Chapter 1 General Information

LCD display resolution. The TV-out (NTSC & PAL) function extendsthe

display options to CRT, LCD, TV and etc. One Type III mini PCI socket

can be used for wireless LAN interface. And onboard Intel82541

Ethernet controller stands for fast 1 Gigabyte transferring speed. All

featured expansion interfaces have been enhanced in this 8” x 5.75”

computer board.

The PCM-8200 is the ideal choice for dust/temperature-sensitive high end

Industrial Automation application. For space-constrained environments

such automobile, PCM-8200 is also a perfect fit.Even is great for KIOSK

and POS implementations with low power consumption and pleasant

multimedia presentations.
