Aaeon HSB-668I Manual de usuario

Half-size CPU Card HSB-668I

HSB-668I

Onboard VIA Mark CoreFusion CPU

Half-Size Card

Realtek 8100C/8110S Ethernet

AC97 Codec Audio

HSB-668I Manual Rev. A 2nd Ed.

April 2008

Half-size CPU Card HSB-668I

This document is copyrighted, 2008. All rights are reserved. The

original manufacturer reserves the right to make improvements

to the products described in this manual at any time without

notice.

No part of this manual may be reproduced, copied, translated,

or transmitted in any form or by any means without the prior

written permission of the original manufacturer. Information

provided in this manual is intended to be accurate and reliable.

However, the original manufacturer assumes no responsibility

for its use, or for any infringements upon the rights of third

parties that may result from its use.

The material in this document is for product information only

and is subject to change without notice. While reasonable

efforts have been made in the preparation of this document to

assure its accuracy, AAEON assumes no liabilities resulting

from errors or omissions in this document, or from the use of the

information contained herein.

AAEON reserves the right to make changes in the product

design without notice to its users.

Half-size CPU Card HSB-668I

Acknowledgments

All other products’ name or trademarks are properties of their

respective owners.

 Award is a trademark of Award Software International, Inc.

 VGA is a trademarks of International Business Machines

Corporation.

 DOC2000 is a registered trademarks of M-system Co., Ltd

 Microsoft Windows®is a registered trademark of Microsoft Corp.

 VIA is a trademark of VIA Technology, Inc.

 IBM, PC/AT, PS/2, and VGA are trademarks of International

Business Machines Corporation.

 Winbond is a trademark of Winbond Electronic Corp.

Please be notified that all other products’ name or trademarks

not be mentioned above are properties of their respective

owners.

Half-size CPU Card HSB-668I

iii

Packing List

Before you begin installing your card, please make sure that the

following materials have been shipped:

• 1 Floppy Cable

• 1 ATA-100 Cable

• 1 USB Cable

• 1 Keyboard Cable

• 1 Serial + Parallel Cable

• 1 ATX Cable

• 1 Serial Cable

• 1 Two Serial Ports Cable

• 1 Quick Installation Guide

• 1 Utility CD

• 1 HSB-688I Half-size CPU Card

If any of these items should be missing or damaged, please

contact your distributor or sales representative immediately.

Half-size CPU Card HSB-668I

Contents

Chapter 1 General Information

1.1 Introduction................................................................1-2

1.2 Features....................................................................1-3

1.3 Specifications............................................................1-4

Chapter 2 Quick Installation Guide

2.1 Safety Precautions....................................................2-2

2.2 Location of Connectors and Jumpers .......................2-3

2.3 Mechanical Drawing..................................................2-4

2.4 List of Jumpers..........................................................2-5

2.5 List of Connectors .....................................................2-6

2.6 Setting Jumpers ........................................................2-8

2.7 COM2 Pin 9 Function (RIB or +5V ) Selection (JP1) .......2-9

2.8 Clear CMOS (JP2) ....................................................2-9

2.9 LCD Voltage Selection (JP3) ....................................2-9

2.10 DOC2000 Address (Selection By BIOS).................2-9

2.11 Front Panel Connector (FP1)..................................2-9

2.12 Front Panel Connector (FP2)..................................2-10

2.13 RS232 Serial Port Connector(COM1/COM3/COM4)2-10

2.14 RS232/422/485 Serial Port Connector (COM2)......2-10

2.15 IrDA Connector (IR1)...............................................2-11

2.16 LPT Port Connector (LPT1) ....................................2-11

2.17 USB Connector (USB1) ..........................................2-12

Half-size CPU Card HSB-668I

2.18 Fan Connector (FAN1)............................................2-12

2.19 AC97 Connector (CN1)...........................................2-12

2.20 ATX Power Control Connector (CN2).....................2-13

2.21 LAN LED Connector (CN3/CN4).............................2-13

2.22 18/24Bit TTL Channel Connector (CN5).................2-13

2.23 36Bit TTL Channel Connector (CN6)......................2-14

2.24 LVDS Channel Connector (CN7)............................2-15

2.25 PS2 Keyboard/Mouse Connector (CN8).................2-15

2.26 Internal Keyboard Connector (CN9)........................2-16

Chapter 3 Award BIOS Setup

3.1 System Test and Initialization. ..................................3-2

3.2 Award BIOS Setup....................................................3-3

Chapter 4 Driver Installation

4.1 Installation.................................................................4-3

Appendix A Programming the Watchdog Timer

A.1 Programming ............................................................A-2

Appendix B I/O Information

B.1 I/O Address Map.......................................................B-2

B.2 1st MB Memory Address Map ...................................B-3

B.3 IRQ Mapping Chart...................................................B-4

B.4 DMA Channel Assignments......................................B-4

Half-size CPU Card HSB-668I

Chapter 1 General Information 1- 1

General

Chapter

Information

Half-size CPU Card HSB-668I

Chapter 1 General Information 1- 2

1.1 Introduction

HSB-668I is a new standard ISA bus half-size CPU Card with

onboard VIA Mark CoreFusion 533MHz processor integrating with

North Bridge. It supports up to 128MB memory on board and is

with one SO-DIMM that memory can support up to 512MB. The

HSB-668I performs as a strengthened single board computer with

low power consumption while no CPU fan required.

This product is integrated AGP 4X 2D/3D video accelerator with 2

channel TTL interface. It supports 36bit LVDS LCD/CRT, and up

to 32 MB frame buffer using system memory.

Excellent connectivity is provided by embedded 10/100Mbps or

Gigabit Ethernet connection. The HSB-668I also offers

comprehensive I/O support, including 3 USB ports for connecting

the latest peripherals and four serial ports for industry standard

applications. Other onboard feature is include a parallel port, an

IrDA port, and an AC-97 SoundBlaster compatible audio. The

SSD solution supports DOC2000 as external storage.

Overall, this powerful CPU card aims to be your most effective

choice and perform low power applications at real affordable price!

Half-size CPU Card HSB-668I

Chapter1GeneralInformation1-3

1.2 Features

• Onboard VIA CoreFusion 533MHz Processor (Fanless)

• Onboard Memory supports up to 128MB

• One SODIMM SDRAM, Memory Up To 512MB

• Integrated ProSavage4 Graphic, 2D/3D VGA Support

• 2 Channel 36-bit LVDS LCD Support

• Integrated AC97 Codec Audio (Daughter Board

Optional)

• Two 10/100 Base-TX Ethernet (One 10/100 & GbE

Optional)

• DOC2000 PC-104 Interface Socket

• Two Ultra ATA 100 Channel

• Supports PC-104 Interface Socket

• 3 USB 1.1 / 1 Parallel / 1 IrDA Port

• 4 COM Ports ( 3 RS-232, 1 RS-232/422/485)

• Watchdog Function 1 ~ 255 Sec.

• ISA High-driver Support

Half-size CPU Card HSB-668I

Chapter 1 General Information 1- 4

1.3 Specifications

System

 FormFactor ISAHalf-sizeSBC

 Processor Onboard VIA Mark

CoreFusion 533MHz CPU

 System Memory 1 x 144-pin 3.3V SDR

SODIMM Socket up to

512MB (on board

memory supports up to

128MB), supports

PC100/133 types

 Chipset Mark+VT82C686B

 VGA Controller Integrated on Mark, 32MB

frame buffer share system

memory

 Ethernet 10/100Mb or

10/100/1000Mb LAN

optional, RJ-45 x 2,

Realtek 8100C/8110S

Option

 Audio(Daughter Board) AC97 Codec, MIC-in/

Line-in/ Line-out/ CD-in

 BIOS Award Plug & Play ISA

BIOS – 4Mb ROM
