A4Tech RFKBTX-5-1 Manual de usuario

Radio Wireless Keyboard

User

’

s Guide

MODEL: RFKBTX-5-1

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING

TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE

MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED

OPERATION.

Federal Communications Commission Requirements

The equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause

harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

lReorient of relocate the receiving antenna.

lIncrease the separation between the equipment and receiver.

lConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.

lConsult the dealer or an experienced radio/TV technician for help.

The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to

operate the equipment.

Quick Start Guide

Getting Ready

1. Turn off the power of your computer.

2. Remove the existing keyboard (and mouse for the A4Tech®Wireless Desktop).

3. Install the AA alkaline batteries in the Wireless keyboard. Remove the battery compartment cover on the bottom of

the keyboard by squeezing the cover in from the tab to release it.

Setting Up the Keyboard or Wireless Desktop

1. Make sure that your computer is turned off.

2. Connecting the Receiver’s Keyboard Cable:

(a) When connecting to an IBM AT keyboard port, use the 5-pin DIN connector already attached to the

keyboard cable.

(b) When connecting to a PS/2-style, 6-pin DIN keyboard port, remove the AT adapter.

3. Place the receiver eight inches (20 centimeters) from any

electromechanical device.

Installing the Keyboard Software-

iKeyWorksOffice

Before you can take advantage of the many features your keyboard offers, you

must install the driver. The driver is in the installation diskette that came

packaged with your mouse and keyboard

Windows 95/98/Me/2000/NT4.0 installation

Insert the installation diskette into your floppy disk drive.

Click the Start button and then click Run.

Inthe Run dialog window, typeA:\setup, where “A”is the letter of your floppy disk drive.

ClickOKand follow the instructions on your screen to complete the installation.

Selecting the Frequency Channel

The Wireless keyboard operates on two frequency channels.. Refer to the following to change the

frequency channel for your keyboard: Set the frequency channel on the receiver to1or 2. Setthe

frequency channel on the keyboard to 1 or 2.

The Wireless keyboard ID code

Each keyboard is assigned a unique ID code at manufacture, so the

receiver only picks up the signal from your mouse and prevents other Wireless keyboard radio signals from

operating on your computer. This feature can also be disabled, allowing other Wireless pointing devices to

operate your computer.

Connecting the Wireless Keyboard ID Code

Manually establish communication between the receiver and keyboard.

(a)Pressany key from the keyboard

(b) Press the ID Connect button on the receiver the green LED light will show you the keyboard ID be

connect. If the green LED light is off then keyboard ID is disconnect.

Using the iKeyWorksOffice Software

To launch the iKeyWorksOfficeTM software, double-click the iKeyWorksOffice icon on the Windows Taskbar.

This iKeyWorksOffice software, brings you closer and keeps you in better touch with your desktop world. Set up and organize your keyboard in your way. Using the

Hotkeys and the iKeyWorksOffice software, customize your keyboard so you can be at your Internet home page, or favorite chat room, and run your e-mail

application with the push of a button. The Hot Keys are divided into two groups, as defined by their functions.

Access customize function

Hotkeys Setting Options

Setting On-Screen

Hot Keys to default function

Show the On-Screen display

Customize hotkey

System default function

MS Office hotkey group

Using the 12 Hot Keys

There are 12 programmable Hotkeys, which you must setup theiKeyWorksOffice software before using.

Hot

Keys Default Functions Microsoft Office program functions

MyHomekey:Accesses your home web page for favorite internet address Word: Access Microsoft word application

E-mailkey: Launches an e-mail application E-mailkey: Launches an e-mail application

Favoritekey:Starts an application, accesses a web site and web sites + Font Size: Increase font size.

Searchkey: Displays a menu of internet search engines -Font Size:Decrease font size.

Previous Track Key:Playsthe previous track. Next Doc.: Open next document

Next Track key: Plays the next track. Previous Doc.: Open Previous Document

Play/Pausekey: Plays or pauses the CD/DVD. Excel: AccessMicrosoftExcel application

Stopkey: Stops play. Open document: Access my documents

Volume Up key: Increase sound volume. Zoom In:To magnify the view of a document.

Volume Down key: Decreases sound volume. ZoomOut:To demagnify the view of a document.

Mutekey:Dramatically reduces the sound volume. My Document: Access the My Document function

Suspendkey: Access the Windows Shut Down dialog box, where you can put

your system on stand-by or shut down windows. Office Tools: Show the Office tools

Customize your Hot Keys

You can define the hotkey as Shell Execution, Keystrokes, Office shortcut and Generic Command to meet your personal needs.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO

OR TV INTERFERENCE CAUSED BY UNAUTHORIZED

MODIFICATIONS TO THIS EQUIPMENT. SUCH

MODIFICATIIONS COULD VOID THE USER’SAUTHORITYTO

OPERATE THE EQUIPMENT.

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

Designed to provide reasonable protection against harmful interference in a

Residential installation. This equipment generated, uses and can radiate radio

Frequency energy and, if not installed and used in accordance with the

Instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

- Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the

Receiver is connected.

Consult the dealer or an experienced radio / TV technician for help.

Customize your Hotkeys

Keystrokes

Generic Command

Disable the Hot key Show the name of the hot key

Email address book

Type the name of file, folder…

Browse File

Browse Folder

My favorite

Selectcommandtype

Shell execution

Office shortcut
