2N IP Vario

Door Entry IP Intercom

Installation Manual

Version: 2.12

The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of

telecommunications equipment.

The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,

private branch exchanges (PBX), and door and lift communicators. 2N

TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years

and represented a symbol of stability and prosperity on the telecommunications

market for almost two decades. At present, we export our products into over 120

countries worldwide and have exclusive distributors on all continents.

2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other

names mentioned herein are registered trademarks and/or trademarks or brands

protected by law.

2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find

information and to answer your questions about 2N products and services. On www.

faq.2n.cz you can find information regarding products adjustment and instructions for

optimum use and procedures „What to do if...".

2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies with all

basic requirements and other relevant provisions of the 1999/5/EC directive. For the

full wording of the Declaration of Conformity see the CD-ROM (if enclosed) or our

website at www.2n.cz.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All

development, production and distribution processes of the company are managed by

this standard and guarantee a high quality, technical level and professional aspect of

all our products.

2N TELEKOMUNIKACE a.s., www.2n.cz 4/106

Content:

1. Product Overview

1.1 Components andAssociated Products

1.2 Terms and Symbols

2. Description and Installation

2.1 Before You Start

2.2 Mechanical Installation

2.3 Electric Installation

2.4 Completion

2.5 Extending Module Connection

3. Function and Use

3.1 Configuration

3.2 Intercom Control as Viewed by External User

3.3 Display-Equipped Intercom as Viewed by External User

3.4 Intercom Control as Viewed by Internal User

3.5 Maintenance

3.6 Downloads

4. Technical Parameters

5. Supplementary Information

5.1 Troubleshooting

5.2 Directives, Laws and Regulations

5.3 General Instructions and Cautions

2N TELEKOMUNIKACE a.s., www.2n.cz 5/106

1. Product Overview

Here is what you can find in this section:

1.1 Components andAssociated Products

1.2 Terms and Symbols

2N TELEKOMUNIKACE a.s., www.2n.cz 6/106

Basic Features

2N IP Vario

®is a highly reliable IP door access intercom provided with a lot of useful

above-standard functions. Supporting the SIP standard and being compatible with the

leading IP PBX and telephone suppliers, can make use of all VoIP 2N IP Vario

services.

2N IP Vario

®can be equipped with a colour camera, which displays the calling person

on the called party's video telephone or PC monitor.

2N IP Vario

® can be provided with up to 54 pre-programmed buttons. You can set up

to three telephone numbers and time profiles for each of the buttons to increase the

accessibility of the called party.

2N IP Vario

®can be equipped with a numerical keypad to be used as a code lock for

lock switch activating or telephone/subscriber number dialling.

2N IP Vario

®is equipped with an electric lock switch. You can control the switch using

a numerical keypad or, during a call, using any telephone set. An additional switch

module can be installed if necessary. A wide range of settings allow for a variety of

applications.

2N IP Vario

®can also be provided with RFID card reader modules.

2N IP Vario

®is very easy to install. All you have to do is connect the system into your

LAN via a network cable and feed it from a 12 V power supply or your PoE supporting

LAN.

Configure using your PC via any web browser. Use the 2N IP Vario

®2N Access

to manage extensive systems easily and quickly.Commader 2N IP Vario

2N TELEKOMUNIKACE a.s., www.2n.cz 7/106

Advantages of Use

Bidirectional communication – acoustic echo cancelling

Integrated colour camera

Optional dial buttons including name tags with backlight

Optional numerical keypad with backlight

Integrated electronic lock switches with wide setting options

Optional integrated RFID card reader module

LAN (PoE) or external 12 V power supply

Configuration via web interface or dedicated PC application

SIP 2.0 support

Up to 54 buttons pre-programmed buttons

Up to 1999 telephone directory positions

Up to 20 user time profiles

Video codecs (H.263, H.263+, H.264, MPEG-4, JPEG)

Audio codecs (G.711, G.729, G.722, L16/16 kHz)

HTTP server for configuration

SNTP client for time synchronisation with server

RTSP server for video streaming

SMTP client for e-mail sending

TFTP client for automatic configuration and firmware update

2N TELEKOMUNIKACE a.s., www.2n.cz 8/106

1.1 Components andAssociated Products

Basic Units

Part No.

9137111(C)U

1 button

control of one electric lock

possibility of connecting card reader, extenders or

information panel or additional switch

available option with camera (C)

Part No.

9137131(C)U

3 buttons

control of one electric lock

possibility of connecting card reader, extenders or

information panel or additional switch

available option with camera (C)

2N TELEKOMUNIKACE a.s., www.2n.cz 9/106

Part No.

9137161(C)U

6 buttons

control of one electric lock

possibility of connecting card reader, extenders or

information panel or additional switch

available option with camera (C)

Part No.

9137111(C)KU

1 button

keypad

control of one electric lock

possibility of connecting card reader, extenders or

information panel or additional switch

available option with camera (C)

2N TELEKOMUNIKACE a.s., www.2n.cz 10/106

Part No.

9137131(C)KU

3 buttons

keypad

control of one electric lock

possibility of connecting card reader, extenders or

information panel or additional switch

available option with camera (C)

Part No.

9137161(C)KU

6 buttons

keypad

control of one electric lock

possibility of connecting card reader, extenders or

information panel or additional switch

available option with camera (C)
