2N Helios IP Safety Manual de usuario

www.2n.czVersion

®Helios IP Safety

Emergency IP Intercom

Installation Manual

2.1



The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of telecommunications

equipment.

The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways, private

branch exchanges (PBX), and door and lift communicators. 2N TELEKOMUNIKACE a.s. has

been ranked among the Czech top companies for years and represented a symbol of

stability and prosperity on the telecommunications market for almost two decades. At

present, we export our products into over 120 countries worldwide and have exclusive

distributors on all continents.

2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other

names mentioned herein are registered trademarks and/or trademarks or brands protected

by law.

2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find

information and to answer your questions about 2N products and services. On

www.faq.2n.cz you can find information regarding products adjustment and instructions for

optimum use and procedures „What to do if...“.

2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies

®Helios IP Safety

with all basic requirements and other relevant provisions of the 1999/5/EC directive. For

the full wording of the Declaration of Conformity see the CD-ROM enclosed or our website

at www.2n.cz.

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All

development, production and distribution processes of the company are managed by this

standard and guarantee a high quality, technical level and professional aspect of all our

products.

Content

1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.1ComponentsandAssociatedProducts ...............................6

1.2TermsandSymbols ..............................................9

2. Description and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.1BeforeYouStart .................................................11

2.2MechanicalInstallation ............................................12

2.3ElectricInstallation ...............................................23

2.4ExtendingModuleConnection ......................................27

3. Function and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

3.1Configuration ...................................................33

3.2Maintenance ....................................................36

4. Technical Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

5. Supplementary Information . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.1Troubleshooting .................................................40

5.2Directives,LawsandRegulations ...................................41

5.3GeneralInstructionsandCautions ...................................43

42N TELEKOMUNIKACE a.s., www.2n.cz

1. Product Overview

Here is what you can find in this section:

1.1 Components and Associated Products

1.2 Terms and Symbols

Basic Features

®Helios IP Safety is a highly resistant and reliable IP door access intercom

provided with a lot of useful above-standard functions. Supporting the SIP standard

and being compatible with the leading IP PBX and telephone suppliers, 2N

®Helios IP

can make use of all VoIP services. can work as aSafety 2N

®Helios IP Safety

standard or emergency door access intercom for buildings, entrances to premises or

garages, manufacturing halls, highways and so on.

®Helios IP Safety is equipped with two very sensitive microphones and an up to

10 W loudspeaker. Thanks to an integrated acoustic echo cancelling (AEC) system, the

product provides mutual audibility even of persons talking at the same time under

normal conditions.

®Helios IP Safety can be equipped with a colour wide-angle camera, which

displays the calling person on the called party's video telephone or PC monitor.

®Helios IP Safety can be provided with 1, 2 or 4 pre-programmed buttons. You

can set up to three telephone numbers and time profiles for each of the buttons to

increase the accessibility of the called party.

®Helios IP Safety can be equipped with a numerical keypad to be used as a code

lock for lock switch activating or telephone/subscriber number dialling.

®Helios IP Safety is equipped with an electric lock switch. You can control the

switch using a numerical keypad or, during a call, using any telephone set. An

additional switch module can be installed if necessary. A wide range of settings allow

for a variety of applications.

52N TELEKOMUNIKACE a.s., www.2n.cz

®Helios IP Safety can also be provided with RFID card reader modules.

®Helios IP Safety is very easy to install. All you have to do is connect the system

into your LAN via a network cable and feed it from a 12 V power supply or your PoE

supporting LAN.

Configure using your PC via any web browser. Use the 2N

®Helios IP Safety IP

to manage extensive systems easily and quickly.Manager 2N

®Helios IP Safety

Advantages of Use

Uncompromising Antivandal design

High coverage level – up to class IP69K

Variable mounting options (brick/plasterboard flush mounting, surface mounting)

Sensitive microphone and powerful loudspeaker

Bidirectional communication – acoustic echo cancelling

Integrated colour camera with wide-angle lens

Optional dial buttons including name tags and backlight

Optional numerical keypad with backlight

Integrated electronic lock switches with wide setting options

Optional integrated RFID card reader module

LAN (PoE) or external 12 V power supply

Configuration via web interface or dedicated PC application

SIP 2.0 support

Up to 999 telephone directory positions

Up to 20 user time profiles

Video codecs (H.263+, H.264, MPEG-4, JPEG)

Audio codecs (G.711, G.729)

HTTP server for configuration

SNTP client for time synchronisation with server

RTSP server for video streaming

SMTP client for e-mail sending

TFTP client for automatic configuration and firmware update

62N TELEKOMUNIKACE a.s., www.2n.cz

1.1 Components and Associated Products

Basic Units

9152101Part No.

1 button

9152101WPart No.

1 button, 10 W loudspeaker, IP69K

2N® Helios IP Safety is designed for outdoor applications and requires no additional

roof. W-including Part Nos. are intended for WAP pressure cleaning and extremely

noisy environments (such as highways, etc.).

2N® Helios IP Safety units can wall mounted without requiring any additional

accessories. Use the appropriate mounting box (see below) for plasterboard and flush

mounting.

72N TELEKOMUNIKACE a.s., www.2n.cz

Mounting Accessories

9152000Part No.

Mounting frame

orange

Aluminum

9151001Part No.

Brick flush mounting box

Stainless steel

9151002Part No.

Plasterboard flush mounting box

VoIP Telephones

91378351Part No.

Grandstream GXV3140 VoIP video telephone

91378354Part No.

Grandstream GXV3175 VoIP telephone

Electric Locks

932070EPart No.

BEFO 1211 12 V / 600

932080EPart No.

BEFO 1221with

momentum pin

932090EPart No.

BEFO 1211MBwith mechanical

blocking

82N TELEKOMUNIKACE a.s., www.2n.cz

Power Supply

Part No.

91378100E

Part No.

91378100US

PoE injector

91341481EPart No.

Adapter 12 V / 2 A

A stabilised power supply has to be used if

the Ethernet

(PoE) power supply is not available.

932928EPart No.

12 V transformer

Additional Modules

9151010Part No.

Additional switch with normally open/closed contact

and 12 V switched output.

Part No.

9159010

Security Relay

Part No.

9137410E

External IP

relay

92N TELEKOMUNIKACE a.s., www.2n.cz

1.2 Terms and Symbols

The following symbols and pictograms are used in the manual:

Safety

abide by this information to prevent persons from injury.Always

Warning

abide by this information to prevent damage to the device.Always

Caution

Important information for system functionality.

Tip

Useful information for quick and efficient functionality.

Note

Routines or advice for efficient use of the device.

102N TELEKOMUNIKACE a.s., www.2n.cz

2. Description and Installation

Here is what you can find in this section:

2.1 Before You Start

2.2 Mechanical Installation

2.3 Electric Installation

2.4 Extending Module Connection
