ZyXEL Communications GS-105A Manual de usuario

Application Diagram

GS-105A/GS-108A

High Performance

With non-blocking switching and full duplex standard, the GS-105A/GS-108A reaches speeds of up to 2000Mbps on

each port, good for today’s and tomorrow’s media-rich applications.

Simple to Use

The GS-105A/108A features auto-sensing 100/1000 Mbps ports that automatically detect the speed and duplex mode of

attached servers, workstations, or hubs. Plug-and-Play functionality makes installation easy and fast.

Smart Features

The IEEE 802.3x standard-based flow control allows the GS-105A/108A to prevent pending traffic congestion by

informing attached devices to stop data transmission. When the switch detects that each port’s buffer is nearly full, the

attached devices are requested to wait until they can accept new data. Meanwhile, support for IEEE802.1p priority tagging

optimizes quality of service.

Durable and Compact Design

The durable metal chassis with its compact design is sized to save space and easily fits on a desk or mounts to the wall.

Flexible installation capabilities make the GS-105A/108A perfect for home and small business applications.

Benefits

ZyXEL 5-port and 8-port Gigabit Ethernet switches provide high flexibility and high bandwidth connectivity to servers,

workstations and other attached devices. With Gigabit connectivity, the GS-105A and GS-108A speed up data

transmission by transferring large files across a network while remaining interoperable with all 10, 100, and 1000Mbps

devices. The compact designs fit easily on a desk or mount easily to a wall, and with true non-blocking switching

capability, are ideal solutions for home and small office network applications.

DSL/Cable Modem

Firewall

Mail

Server

Database

Server

INTERNET

GS-105A/108A

Desk PCs with

GN670-T installed

5-port/8-port

Desktop Gigabit Switch

SOHO/Home

GS-105A/GS-108A

5-port /8-port Desktop Gigabit Switch

65-100-108001

Features

• Forwards and filters packets at non-blocking, full wire speed

• Optimizes quality of service with IEEE 802.1p priority tagging support

• IEEE802.3x flow control efficiently prevents pending traffic congestion

• Supports NWAY auto-negotiation to automatically set up network speed and protocol

• Auto-MDI/MDI-X automatically adjusts for straight-through or crossover cables

• Supports PC or Mac‚ OS (OS independent)

Specifications

Technical Specification

• Standard Compliance

IEEE 802.3 Ethernet

IEEE 802.3u Fast Ethernet

IEEE 802.3ab Gigabit Ethernet

IEEE 802.3x Flow Control

• RJ 45 Interface

10BASE-T, 100BASE-TX & 1000BASE-T

UTP/STP Cable Recognition for straight-through or

crossover cables (Auto MDI/MDI-X on each port)

• MAC Address Size: 4K

• Back-plane Bandwidth

10Gbps (GS-105A)

16Gbps (GS-108A)

• Switching Method

Store-and-Forward

• Packet Buffer Memory: 1Mbps

• Packet Forwarding Rate

14,880pps for 10BASE-T

48,800pps for 100BASE-TX

1,488,000pps for 1000BAES-T

Hardware Specification

• Network Ports

5 ports 10/100/1000 Mbps (GS-105A)

8 ports 10/100/1000 Mbps (GS-108A)

• LEDs Indicators

Speed (100/1000), Activity/Link, Duplex/Collision for

each port

Power indicator for each unit

Power Requirement

• Power Consumption

Max. 7.5W (GS-105A)

Max.13.2 Watt (GS-108A)

• Power Supply

12V DC/1.3A

Physical Specification

• Dimensions: 165(L) x100(D) x 32.5(H) mm

• Weight: 0. 6Kg (GS-105A); 1Kg (GS-108A)

Operating Environment

• Temperature: 0ºC ~ 45ºC (32º ~ 113ºF)

• Humidity: 10% to 90% (non-condensing)

Certification

• FCC Class B, CE, UL, CUL, C-Tick

System Requirement

• UTP/STP CAT 5 cable or better

• Network adapter for each PC or server

Copyright© 2004 ZyXEL Communications Corporation. All rights reserved. The ZyXEL and ZyNOS logo are registered trademarks of ZyXEL Communications Corp. Other trademarks and service names referenced are properties of their respective holders. All specifications are subject to change without notice.

Corporate Headquarters

ZyXEL Communications Corp.

Tel: +886-3-578-3942

Fax:+886-3-578-2439

Email: [email protected]

http://www.zyxel.com

http://www.zyxel.com.tw

Denmark

Tel: +45 39 55 07 00 Fax: +45 39 55 07 07

Email: [email protected]

http://www.zyxel.dk

Finland

Tel: +358-9-4780 8400 Fax: +358-9-4780 8448

Email: [email protected]

http://www.zyxel.fi

France

Tel: +33 (0)4 72 52 97 97 Fax: +33 (0)4 72 52 19 20

Email: [email protected]

http://www.zyxel.fr

Germany

Tel: +49 2405 6909 0 Fax: +49 2405 6909 99

Email: [email protected]

http://www.zyxel.de

North America

Tel: +1-714-632-0882 Fax: +1-714-632-0858

Email: [email protected]

http://www.us.zyxel.com

Norway

Tel: +47 22 80 61 80 Fax: +47 22 80 61 81

Email: [email protected]

http://www.zyxel.no

Spain

Tel: +34 902 195 420 Fax: +34 913 005 345

Email: [email protected]

http:// www.zyxel.es

Sweden

Tel: +46 31 744 7700 Fax: +46 31 744 7701

Email: [email protected]

http://www.zyxel.se
