ZyXEL Communications Brochure Manual de usuario

Prestige 652H/HW Series

Benefits

ZyXEL’s Prestige 652H/HW ADSL security gateway is a powerful, all-in-one DSL device for SOHO and SMB applications as well

as enterprise branch offices. The security gateway integrates a high-speed ADSL port, 4-port 10/100Mbps auto MDI/MDIX

Ethernet switch and an optional wireless access point (Prestige 652HW only).

The Prestige 652H/HW provides superior Firewall/VPN network protection, while simultaneously offering the flexibility and

freedom of wireless access. The Prestige 652H/HW protects networks from network intrusions by providing robust Firewall

security features and standard IPSec Virtual Private Network tunneling.

Additional features such as auto fail-over/fail-back Dial Backup, Traffic Redirect, and IP layer QoS Bandwidth Management,

maximize performance while minimizing operation and maintenance costs. Management is further simplified with an intuitive

Multilingual (English, German, French) Web-based configurator and administrator wizards.

Scalable, secure, and easy-to-use, ZyXEL’s Prestige 652H/HW is the ideal secure broadband solution to meet today’s

business needs.

ADSL Security Gateway with

Wireless Ready

High-speed Internet Access

The Prestige 652H/HW is capable of supporting downstream transmission rates of up to 8Mbps and upstream rates of up to 832 Kbps.

Rate adaptation is also supported, which allows ADSL subscribers to select an Internet access speed that best suites their needs and budgets.

Robust, State-of-the-Art Firewall Security

The ICSA certified ZyNOS operating system ensures state-of-the-art Firewall performance and robust security from the Prestige 652H/HW.

Based on Stateful Packet Inspection and Denial of Service (DoS), it provides the first line of defense against hackers, network intruders, and

other hazardous threats.

VPN (Virtual Private Network) Support

The Prestige 652H/HW supports standard IPSec VPN, suitable for site-to-site and remote access deployment. Data encryption over the

Internet ensures secure transmission of data between two sites, and can be used to replace a private leased line or frame relay network,

allowing global interconnectivity at a minimal expense. The Prestige 652H/HW adopts ASIC DES accelerator which can enhance much

VPN performance.

Mobile Network with Optional Wireless LAN (Prestige 652HW only)

A wireless LAN can be easily established by inserting a ZyXEL ZyAIR WLAN PCMCIA card into the Prestige 652HW. The capability of

wireless expansion quickly extends the existing LAN and offers the advantage of mobility. Wireless connectivity is secured by standard

features including WEP encryption, MAC filtering and IEEE 802.1x authentication.

Auto Fail-over and Fail-back WAN Backup Solution

The Prestige 652H/HW supports fail-over and fail-back WAN Backup Solution by forwarding traffic to either a backup ISDN or analog

modem in the event of DSL connection failure. When the DSL connection is re-established, traffic returns. It also performs backup

functions by redirecting traffic to a specific gateway to ensure availability of the Internet. The WAN Backup Solution saves the cost of

device maintenance, and daily operation losses.

Effective Network Bandwidth Management

The Prestige 652H/HW enables network administrators to allocate network resources while guaranteeing Quality of Service (QoS).

Network Bandwidth Management increases productivity and efficiency by tailoring a system to specific demands such as time-sensitive

VoIP applications.

Models: • Prestige 652H ADSL Security Gateway with 4-port Switch over POTS

• Prestige 652H ADSL Security Gateway with 4-port Switch over ISDN/U-R2

• Prestige 652HW ADSL Security Gateway with Wireless Ready/4-port Switch over POTS

• Prestige 652HW ADSL Security Gateway with Wireless Ready/4-port Switch over ISDN/U-R2

INTERNET

Prestige 652H/HW Series

ADSL Security Gateway with Wireless Ready

Copyright© 2003 ZyXEL Communications Corporation. All rights reserved. The ZyXEL and ZyNOS logo are registered trademarks of ZyXEL Communications Co. Other trademarks and service names referenced are properties of their respective holders. All specifications are subject to change without notice.

Corporate Headquarters

ZyXEL Communications Co.

Tel: +886-3-578-3942

Fax: +886-3-578-2439

Email: [email protected]

http://www.zyxel.com

http://www.zyxel.com.tw

North America

ZyXEL Communications Inc.

Tel: +1-800-255-4101

Email: [email protected]

http://www.us.zyxel.com

Germany

ZyXEL Deutschland GmbH.

Tel: +49 2405 6909 0

Fax: +49 2405 6909 99

Email: [email protected]

http://www.zyxel.de

Denmark

ZyXEL Communications A/S

Tel: +45 39 55 07 00

Fax: +45 39 55 07 07

Email: [email protected]

http://www.zyxel.dk

Norway

ZyXEL Communications A/S

Tel: +47 22 80 61 80

Fax: +47 22 80 61 81

Email: [email protected]

http://www.zyxel.no

Sweden

ZyXEL Communications A/S

Tel: +46 31 744 7700

Fax: +46 31 744 7701

Email: [email protected]

http://www.zyxel.se

Finland

ZyXEL Communications Oy

Tel: +358-9-4780 8400

Fax: +358-9-4780 8448

Email: [email protected]

http://www.zyxel.fi

65-100-065203

Features & Specifications

Application Diagram

ADSL Compliance

•Multi-Mode ADSL Standard

•RADSL (ANSI T1.413 Issue 2)

•G.dmt ADSL over POTS

(G.992.1 Annex A)

•G.dmt ADSL over ISDN

(G.992.1 Annex B and U-R2)

•G.lite (G.992.2)

•G.hs (G.994.1)

•Auto-negotiating Rate Adaptation

ATM Support

•8 PVCs Support

•RFC 1483/2684 Multiple Protocol

over AAL5

•RFC 2364 PPP over AAL5

•RFC 2516 PPP over Ethernet

•VC and LLC Multiplexing

•Traffic Shaping UBR, CBR, VBR-nrt

•ATM Forum UNI 3.1/ 4.0 PVC

•I.610 OAM F4/F5 loop-back, AIS, and

RDI OAM cells

Firewall Security

•Stateful Packet Inspection

•Access Control of Service

•Content Filtering

•IP & Generic Packet Filtering

•Real-time Attack Alert and Logs

•DMZ Interface for Public Server*

Virtual Private Network

•10 IPSec VPN Tunnels

•IKE and Manual Key Management

•AH and ESP Protocol

•DES and 3DES Encryption

(ASIC DES Engine)

•SHA-1 and MD5 Authentication

•Tunnel and Transport Mode

Encapsulation

Wireless (Optional)

•IEEE 802.11b Compliance

•64/128 bits WEP Encryption

•MAC Address Filtering

•IEEE 802.1x Port-based Authentication

•RADIUS Support for 802.1x

Routing Support

•IEEE 802.1d Transparent Bridging

•IP Routing: TCP, UDP, ICMP, ARP

•RIP1v1 and RIPv2

•IP Multicast IGMP v1/v2

IP Management

•SUA/Multi-NAT Internet Sharing

•Application/Multimedia Support

•DHCP Server/Relay/Client

•DNS Proxy

•Dynamic DNS

•UPnP Support

Network Management

•Multilingual Web based Configurator

(English/German/French)

•Command-line Interpreter (CLI)

•Telnet Remote Management

•SNMP Support

•FTP/TFTP firmware upgrade and

configuration backup/restore

•Built-in Diagnostic Tool

Application

•Dial Backup

•Traffic Redirect

•IP QoS Bandwidth Management*

•Port based VLAN for Ethernet & WLAN*

•Call Scheduling

•Budget Management

•ZyXEL CNM Support*

Hardware Specification

•ADSL: One RJ-11 or RJ-45 Port

•LAN: 4-Port Switch ,10/100M Auto

MDI/MDIX

•Wireless Ready Slot for WLAN

Card Connection

•Console/AUX: RS-232 DB9 Port

•CON/AUX Switch

•Reset Button

•Status LEDs Indicator

•Power: 12V AC

Physical Specifications

•Dimensions: 206(L) x 161(D) x 51(H) mm

•Weight: 572 g

Operating Environment

•Temperature: 0 ~ 40°C

•Humidity: 20 ~ 85 %

(non-condensing)

* For further release

Dial Backup

VPN Tunnel

Web Server

Mail Server

Internal Server

Data Base

Attack

Firewall

Content Filtering

Prestige 652HW

Prestige 652H/HW

Modem/ISDN TA

Internet Security/WLAN Applications

Virtual Private Network Applications

USB Stick (ZyAIR B-220)

PC Card (ZyAIR B-120)

Ethernet Adapter (ZyAIR B-420)

INTERNET

Headquarters

Mobile Users

(ZyXEL/SSH Sentinel VPN Client)

Hackers

World Wide Web

Prestige 652H/HW

Home/Branch Office
