ZyXEL Communications NSA-220 Plus Manual

NSA-220 Plus Support Notes

NSA-220 Plus

Support Notes

Revision 1.00

Sept, 2008

NSA-220 Plus Support Notes

INDEX

Key applications.............................................................................................................................4

1. Auto upload service....................................................................................................................4

1.1 Network topology.............................................................................................................4

1.2 Auto-upload pictures to Flickr .........................................................................................5

1.3 Auto-upload video files to YouTube .............................................................................. 11

1.4 Auto-upload files to FTP server(s) (FTP uploadr) .........................................................18

2. Power management..................................................................................................................22

2.1 Power control schedule..................................................................................................22

2.2 Power resume.................................................................................................................23

2.2.1 Keep former status ..............................................................................................23

2.2.2 Always Power On................................................................................................24

2.2.3 Always power off................................................................................................24

3. Network Service.......................................................................................................................25

3.1 PPP over Ethernet (PPPoE)............................................................................................25

4. Link Capture.............................................................................................................................26

FAQ..............................................................................................................................................29

1. What is RAID?.........................................................................................................29

2. Which kind of RAID is supported in NSA-220 PLUS?...........................................29

3. What is the file system supported in NSA-220?......................................................29

4. What is the file system supported in NSA-220 PLUS? ...........................................29

6. What is “Jambo frame?” ..........................................................................................29

7. Does NSA-220\NSA-220 PLUS support Jambo frame? What is the benefit for

using Jambo frame?......................................................................................................30

8. Does the size of a Jambo frame automatically negotiate with NSA-220?...............30

9. How does the file transfer by USB port in NSA-220?.............................................30

10. How does it work after pressing copy button in the front panel of NSA-220?......30

11. What is the difference between "Scan" and "Repair" on NSA-220 PLUS?...........31

12. I do not want the Hard Disk idle time shutdown feature, how can I disable it? ....31

13. Which kind of the media server does NSA-220 PLUS apply?..............................31

14.Does NSA-220 PLUS support DLNA media server? ............................................31

15.Which kind of video file formats are supported by NSA-220 PLUS?...................31

16.Which kind of audiofile formats are supported by NSA-220 PLUS?....................32

17.Which kind of image file formats are supported by NSA-220 PLUS?..................32

18.What is the button in the front panel of NSA-220 PLUS?.....................................32

NSA-220 Plus Support Notes

19.Will all files in the monitored folder(s) be uploaded to Flikcr?.............................32

20.Will all files in the monitored folder(s) be uploaded to YouTube?........................32

21.Does auto-pload function can be activated for Flickr and YouTube at the same

time? 33

NSA-220 Plus Support Notes

Key applications

This document describes the detail configuration in some of new features in NSA-220 PLUS.

In final part, FAQ, you may also find more information in user guide or knowledge base in

ZyXEL service portal.

1. Auto upload service

ZyXEL NSA-220 PLUS provides users to automatically upload their pictures to Flickr website

(http://www.Flickr.com) and video files to You Tube website (http://www.youtube.com).

Additionally, automatical FTP uploading is supported in NSA-220 PLUS.

1.1 Network topology

The following network environment will be referred for the following auto upload scenarios.

PC and NSA-220 PLUS connect to switch and access to internet through switch.

NSA-220 Plus Support Notes

1.2 Auto-upload pictures to Flickr

For sharing pictures in Flickr website (http://www.Flickr.com), ZyXEL NSA-220 supports

automatically upload picture in given folder in NSA-220 PLUS.

Configuration Procedure:

zEnable auto-upload in Flickr service.

zConfigure the account Flickr account information.

zLink your NSA-220 with your Flickr account.

zSpecify the folders which you want NSA-220 to automatically upload your pictures.

zSpecify the grace period and other options in auto upload function.

zMove pictures to the folders you specify in previous step.

zCheck the result in Flickr website.

zCheck the system log in NSA-220 PLUS.

First, log into the web GUI page in NSA-220 PLUS, go to \Auto Upload\Flickr/YouTube.

Then, enable Flickr service as following figure.

NSA-220 Plus Support Notes

After enabling the Flickr service, you will see two more icons in the same page.

Press “config” icon to set more detail configuration. There will be several system notification

to warn that you are going to link to Flickr website. In the meanwhile, please make sure you

have Flickr account information.

After configuring the account information, system will warn you that the connection to Flickr.

In the following popup browser, you need to authorize the connection between your account

and your NSA-220.

NSA-220 Plus Support Notes

The following figure shows that you agree this link after press “OK” button.

After allowing the agreement in Flickr page, please also press the “Get ready” button in

NSA-220 PLUS.

NSA-220 Plus Support Notes

You also can check the service status in NSA-220 PLUS under “Auto Upload/Flickr/YouTube”

In his case, we can see the storage status in your Fickr account.

Afterwards, users need to set which folder(s) in your NSA-220 PLUS will be monitored and

uploaded to Flickr website. In this example, we are going to set folder named as

“ 2009_SpaceTraveling” under public folder to be monitored and uploaded all the pictures to

Flickr website.

NSA-220 Plus Support Notes

In this example, we configure the grace period as two minutes. This means that NSA-220

PLUS will upload any new added pictures in the folder you specify after fifteen minutes since

you press apply button.

Please specify the given folder that NSA-220 PLU will watch and upload the pictures after

applying configuration. PLEASE REMEMBER TO PRESS APPLY BUTTON.

NSA-220 Plus Support Notes

Please remember to press “APPLY” button after specifying the given folder. NSA-220 PLUS

will monitor any need added pictures in the folder you assigned after you press apply button.

After fifteen minutes, NSA-220 PLUS will upload new added photos to Flickr website. IN this

example, we can see one picture has been uploaded to Flcikr website.
