ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

■

Robust security without

sacrificing performance

■

Comprehensive support to IPv6

■

Robust hybrid VPN

(IPSec/SSL/2TP)

- Zero-configuration remote

access with EASY VPN

- Support L2TP VPN on mobile

device (iPhone and Android

phone)

■

ICSA Firewall, IPSec certification

■

Content filter stops malware

and Web threats

■

Powerful Email security

■

Non-stop Internet access with

multiple WAN and 3G backups

As broadband quickly becomes a necessity in the business world facing network security

threats,the breaches evolve into highly sophisticated attacks to paralyze networks and to

steal sensitive information.In response to such attacks,small businesses have to meet the

great challenge protecting their networks.

The ZyWALL USG 20/20W/50/100/200 Series is designed for small business to provide

real-time inspection and multi-layer network protection to prevent the network from threats.

The USG Series embodies Stateful Packet Inspection (SPI) Firewall, Anti-Virus (AV), Intrusion

Detection and Prevention (IDP),Content Filtering, Anti-Spam and VPN (IPSec/SSL/L2TP)

features in one box. In addition, the USG Series not only offers complete security license to

fulfill your demand but also guarantees the continuous firmware upgrades to save your cost.

Incorporating comprehensive security features in the connected devices, the USG Series

safeguards your organization’s customer and company records, intellectual properties as well

as critical resources from both external and internal threats.

Benefits

Robust security without sacrificing performance

The ZyWALL USG 20/20W/50/100/200 Series is built with a powerful Integrated High-Performance

Security architecture that provides real-time inspection to prevent networks from threats without

sacrificing performance. Corporate networks are not only flawlessly secured but also get significant

performance enhancements on productivity and efficiency since file loading,emailing and

information searching applications are processed at higher speeds.

Comprehensive IPv6 support smoothly connects future-ready

networks

The ZyWALL USG Series is IPv6-ready today and is certified with “IPv6 Ready” gold

logo.With IPv6 feature enabled, the USG Series ensures businesses with a smooth

migration path from the IPv4-based networks to the full IPv6 infrastructure. It assigns

IPv6 addresses to clients and passes the IPv6 traffics through the IPv4 environment.The USG Series

supports dual-stack and IPv4 tunneling (6rd and 6to4 transition tunnel) implementations for

Internet connectivity to access IPv6 applications.

Security on a New Level

-The Future Is Ahead. Stay Ahead with ZyXEL USGs.

ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

EASY VPN reduces operation cost and time

Establishing a VPN tunnel is a good way to build secure connections among remote offices,branch offices and partners; however it is difficult for

non-technical employees, such as sales people, to use because of complicated configuration.The ZyWALL USG Series is equipped with the “EASY VPN”

solution to push configuration files to the VPN clients automatically; this eliminates the configuration efforts while securing the access at the same time.In

addition, the USG Series supports L2TP VPN technology on iPhones,Android phones and many other mobile devices as L2TP VPN enables employees in

remote places to connect to the headquarters with easy and free access.

Content filter for safer Web surfing

The World Wide Web has become the main target for network threats,since the Internet itself is a very effective malware delivery mechanism.With threats

hidden directly in contents such as cookies, add-ons and rootkits, it makes malware exceptionally difficult to detect.

The ZyWALL USG Series content filter solution provided by Blue Coat and Commtouch,the leading providers, reduces costs and extends protection by

combining a comprehensive, integrated database featuring millions of URLs, IP addresses and domains.With the solution, the USG Series not only enables

real-time protection that deters emerging Web threats including malware and phishing, but also blocks or monitors certain sites to maintain employee

productivity.

Powerful Email security

The ZyWALL USG Series delivers industry-leading protection, powered by Commtouch, against spam, phishing and virus-laden emails.The extremely high

performance of Commtouch technology comes from the unique recurrent pattern detection (RPD) mechanism that possesses its superior capability

through analyzing millions of new patterns each day (24x7x365) to block all the associated messages real-time. In addition, the ZyWALL USG applies

sender-based IP reputation to remove over 80% of unwanted mails and to take advantage of the zero-hour virus outbreak protection feature, which is

capable of blocking or delaying suspicious messages hours before commercial anti-virus signatures are available.

More 3G card support

The ZyWALL USG Series not only supports multiple WAN ports but also 3G networks through USB or PC cards.With 3G connections, the USG Series enables

load sharing or failover to deliver highly reliable network connectivity; it also supports more 3G cards with generic driver to ensure excellent

interoperability. Since the customers don’t have to purchase specific 3G cards to save cost.

High performance

The ZyXEL USG Series is built with a powerful

Integrated High Performance Security

architecture. It provides real-time inspection to

prevent networks from threats without sacrificing

performance.Take the USG 50 as an example: its

excellent performance delivers sufficient speed

boost to meet all small business needs.

Key Applications

250

200

150

100

ZyWALL 5 FG-30B TZ100 ZyWALL

USG 50

10000

7500

5000

2500

ZyWALL 5 TZ100FG-30B ZyWALL

USG 50

Competitive Comparison:

Firewall Throughput in Mbps

* Source: Performance figures from ZyXEL, SonicWALL and Fortinet Websites.

Competitive Comparison: Sessions

EASY VPN — zero configuration

remote access

When establishing VPN tunnels, it could

be quite difficult for non-technical

employees to use due to the

complicated configuration.

The ZyWALL USG Series is equipped with

the“EASY VPN”solution to push

configuration files to the VPN clients

automatically; this eliminates the

configuration efforts while securing the

access at the same time.

Content Filter stops malware

and Web threats

The ZyWALL USG Content Filter enables

businesses to protect their users and

networks from malware and abuse such

as spyware, phishing attacks and

inappropriate P2P or IM usage.It keeps

office computers from getting infected

by dangerous malware and

comprehensively protects business

network environments.

Non-stop Internet access with

multiple WAN and 3G backups

The ZyWALL USG supports not only WAN

traffic load balancing to increase the overall

network throughput but also flexible 3G

backup as a WAN alternative to enhance

network reliability. Network

Provider

(IP VPN)

LAN

ZyWALL USG 300

Unified Security

Gateway

Vantage CNM

Centralized Network

Management

Remote Office

Corporate

Headquarters

BRAS

Host by SI or Customer

Operating in

Active/Passive Mode

Network

WAN2 (3G)

WAN1

Primary

Backup

ADSL Fiber

Last-Mile

IPSec or GRE Tunnel for

Secure Connection

ZyWALL USG fail

over and fail back

between WAN1

(ADSL/Fiber) &

WAN2 (3G WAN)

ZyWALLUSG300

PWR

SYS

AUX

RESET

CARD1

CARD2

10/100/1000

1234567USB

CONSOLE

AUX

P2P

Virus

Spyware

Phishing

Sit

VPN

Client to Site

IPSec VPN

Internet

Branch

ZyWALLUSG300

PWR

SYS

AUX

RESET

CARD1

CARD2

10/100/1000

1234567USB

CONSOLE

AUX

Mobile User

Branch

ZyWALLUSG300

PWR

SYS

AUX

RESET

CARD1

CARD2

10/100/1000

1234567USB

CONSOLE

AUX

User

Server Farm

ZyWALL USG

Unified Security

Gateway

Network

Extend

Application Server

(Inventory, Store...)

Web-based

Application

Remote

Desktop

File

OA, ERP System

CRM System

System

Server

Headquarters

IPSec

VPN Client

IPSec

VPN Client

Conguration

File

Easy provisioning for ZyWALL IPSec VPN client

- USG automatically provides configuration file to the client.

Specifications

Product Photo

Note:

*1:Testing Methodologies:Maximum performance based on RFC 2544 (UDP packets,1,518 bytes).

*2: VPN (AES) throughput measured using UDP traffic with 1,424 bytes packet size,based on RFC 2544.

*3: UTM (AV+IDP) throughput measured using industry standard IXIA IxLoad test tool against HTTP protocol with 1,460 bytes packet size.Testing done with multiple flows.

*4: 11n (20 MHz),security type: WPA2-PSK

*5: Max sessions measured using industry standard IXIA IxLoad test tool.

Hardware Specifications

10/100/1000 Interfaces (Copper) 4 x LAN/DMZ, 4 x LAN/DMZ, 4 x LAN/DMZ, 5 x LAN/DMZ, 5 x LAN/DMZ,

1 x WAN 1 x WAN 2 x WAN 2 x WAN 2 x WAN, 1 x OPT

USB Ports 1 1 2 2 2

Card Slot - - - 1 1

System Capacity & Performance

SPI Firewall Throughput*1 (Mbps) 175 175 225 225 250

VPN Throughput (AES)*2 (Mbps) 75 75 90 90 90

UTM Throughput (AV+IDP)*3 (Mbps) - - 30 30 40

Unlimited User Licenses Yes Yes Yes Yes Yes

Max. Sessions*4 10,000 10,000 10,000 20,000 40,000

New Session Rate 1,000 1,000 1,200 1,200 1,200

Max. Concurrent IPSec VPN Tunnels 5 5 10 50 100

Max. Concurrent SSL VPN Users 1 1 5 25 25

Included SSL VPN Users 1 1 2 2 2

Customizable Zone Yes Yes Yes Yes Yes

IPv6 Support Yes Yes Yes Yes Yes

Built-in Wireless LAN

Standards - 802.11 b/g/n - - -

Antennas - 2 detachable - - -

WiFi Throughput

(Mbps) - 80 - - -

Maximum Output Power - - - -

Radio Sensitivity - - - -

Power Requirement

Input Voltage 100 - 240 V AC, 100 - 240 V AC, 100 - 240 V AC, 100 - 240 V AC, 100 - 240 V AC,

50/60 Hz, 1.2 A 50/60 Hz, 1.2 A 50/60 Hz, 1.2 A 50/60 Hz, 1.2 A 50/60 Hz, 1.2 A

Power Rating 15 W Max 16 W Max 17 W Max 　20 W Max 20 W Max　

Physical Specifications

Item dimensions (WxDxH)(mm/in.) 216 x 140 x 33/ 216 x 140 x 33/ 242 x 167 x 35.5/ 242 x 175 x 35.5/ 242 x 175 x 35.5/

8.50 x 5.51 x 1.30 8.50 x 5.51 x 1.30 9.53 x 6.57 x 1.40 9.53 x 6.89 x 1.40 9.53 x 6.89 x 1.40

Item weight (kg/lb.) 0.38/0.84 0.42/0.93 1.2/2.65 1.2/2.65 1.2/2.65

Packing dimensions (WxDxH)(mm/in.) 305 x 205 x 106/ 305 x 205 x 106 / 375 x 238 x 108/ 296 x 158 x 241/ 296 x 158 x 241/

12.01 x 8.07 x 4.17 12.01 x 8.07 x 4.17 14.76 x 9.37 x 4.25 11.65 x 6.22 x 9.49 11.65 x 6.22 x 9.49

Packing weight (kg/lb.) 1/2.20 1.1/2.43 2.4/5.29 2.7/5.95 3/6.61

Environmental Specifications

Operating temperature 0°C to 40°C/32°F to 104°F

Storage temperature -30°C to 60°C/-22°F to 140°F

Operating humidity 5% to 90% (Non-condensing)

802.11b:

18.5 dBm@11 Mbps

802.11g:

15.5 dBm@54 Mbps

802.11n:

15.5 dBm@20 Mbps,

12.5 dBm@40 MHz

802.11b:

≤-83 dBm@11 Mbps

802.11g:

≤-70 dBm@54 Mbps

802.11n:

≤-64 dBm@20 Mbps,

≤-61 dBm@40 MHz

Model ZyWALL USG 20 ZyWALL USG 20W ZyWALL USG 50 ZyWALL USG 100 ZyWALL USG 200

Firewall

• ICSA-certified firewall

• Routing and transparent (bridge) mode

• Zone-based access control list

• Stateful packet inspection

• User-aware policy enforcement

• SIP/H.323 NAT traversal

• ALG supports custom ports

IPv6 Support

• IPv6 Ready gold logo certified

• Dual stack

• IPv4 tunneling (6rd and 6to4 transition tunnel)

• Host/Router/Firewall

Virtual Private Network (VPN)

• ICSA-certified IPSec VPN

• Algorithm: AES/3DES/DES

• Authentication: SHA-1/MD5

• Key management: Manual key/IKE

• Perfect forward secrecy (DH groups)

support 1, 2, 5

• IPSec NAT traversal

• Dead peer detection/relay detection

• PKI (X.509) certificate support

• Centralize VPN support

• Simple wizard support

• Auto reconnect VPN

• VPN HA (redundant remote VPN gateways)

SSL VPN

• Clientless secure remote access

• Support reverse proxy mode and full tunnel

mode

• Unified policy enforcement

• Supports two-factor authentication

• Customizable user portal

Intrusion Detection and Prevention

(IDP)

(ZyWALL 50/100/200)

• Routing and transparent (bridge) mode

• Zone-based IDP inspection

• Customizable protection profile

• Protect over 2000 attack

• Automatic signature updates

• Custom signatures

• Protocol anomaly detection and protection

• Traffic anomaly detection and protection

• Flooding detection and protection

• DoS/DDoS protection

Anti-Virus

(ZyWALL 50/100/200)

• Support Kaspersky and ZyXEL Anti-Virus

• Stream-based Anti-Virus engine

• Zone base AV protection

• HTTP/FTP/SMTP/POP3/IMAP4 protocol support

• Automatic signature updates

• No file size limitation

• Blacklist/whitelist support

Application Patrol

(ZyWALL

50/100/200)

• Application, IM/P2P, stream base media, VoIP

granular access control

• Detail access control of IM (chat, file transfer,

video)

• Application and IM/P2P bandwidth control

• User authentication support

• IM/P2P signature auto update

• Support more than 15 catalogs IM and P2P

• Real-Time statistical reports

• Maximum/guaranteed bandwidth

Anti-Spam

• Zone to zone protection

• Transparently intercept mail via SMTP/POP3

protocols

• POP3/SMTP port configurable

• Sender-based IP Reputation Filter

• Commtouch RPD Query

• Zero-hour Virus Outbreak Protection

• X-Header Support

• Blacklist/whitelist support

• Support DNSBL checking

• Spam tag support

• Statistics report

High Availability (ZyWALL 100/200)

• Active-Passive mode

• Device failure detection and notification

• Support ICMP and TCP ping check

• Link monitoring

• Auto-Sync configurations

Content Filtering (BlueCoat and

Commtouch)

• Social networking control

• Web security—Security threat category

(powered by BlueCoat)

• URL blocking, keyword blocking

• Profile base setting

• Exempt list (blacklist and whitelist)

• Blocks java applet,cookies and active X

• Dynamic URL filtering database (powered by

BlueCoat and Commtouch)

• Unlimited user licenses support

• Customize warning messages and redirect URL

Networking

• Routing mode/bridge mode/mixed mode

• Layer 2 port grouping

• Ethernet/PPPoE

• NAT/PAT

• Tagged VLAN (802.1Q)

• Virtual interface (alias interface)

• Policy-based routing (user-aware)

• Policy-based NAT (SNAT)

• Dynamic routing (RIP v1/v2, OSPF)

• DHCP client/server/relay

• Dynamic DNS support

• WAN Trunk more than 2 port

(ZyWALL 50/100/200)

• Per host session limit

• Guaranteed bandwidth

• Maximum bandwidth

• Priority-bandwidth utilization

ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

Features

5-100-00811007 01/12

For more product information, visit us on the web at www.ZyXEL.com

ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their

respective owners. All specifications are subject to change without notice.

ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

ZyWALL USG

20/20W/50/

100/200

Unified Security Gateway

Authentication

• Local user database

• Microsoft Windows active directory integrate

• External LDAP/RADIUS user database

• Xauth over RADIUS for IPSec VPN

• Forced user authentication (transparent

authentication)

• IP/MAC address binding

System Management

• Role-Based administration

• Multiple administrator login

• Multi-Lingual web GUI (HTTPS/HTTP)

• Object-based configuration

• Command line interface (console/web

console/SSH/TELNET)

• SNMP v2c (MIB-II)

• System configuration rollback

• Firmware upgrade via FTP/FTP-TLS/web GUI

Logging/Monitoring

• Comprehensive local logging

• Syslog (send to up to 4 servers)

• E-mail alert (send to up to 2 servers)

• Real-Time traffic monitoring

• Built-in daily report

• Advanced reporting (Vantage Report)

• Centralized Network Management (Vantage

CNM) manageable

Certification

• Emission (EMC)

■

FCC Part15 (Class B)

■

CE EMC (Class B)

Note:

*1: Available for USG 50/100/200 models with a ZyWALL Intrusion

Detection/Prevention (IDP) subscription.

*2: Available for USG 50/100/200 models with a ZyWALL Anti-Virus

subscription.

*3: Available for all USG models with a ZyWALL Content Filtering

subscription.

Please visit http://www.zyxel.com/products_services/smb_security_appliances_and_services.shtml and find the following path:

ZyWALL Unified Security Gateways USG product pages to see the 3G Card Compatibility List for supported USB devices.

3G Card Support

Otros manuales para ZYWALL USG 20W

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Puerta de ZyXEL Communications

ZyXEL Communications

ZyXEL Communications P-660HN-5x Series Manual de usuario

ZyXEL Communications

ZyXEL Communications SBG3500-N Series Manual de usuario

ZyXEL Communications

ZyXEL Communications P-660HN-51 - Manual de usuario

ZyXEL Communications

ZyXEL Communications ZyWALL USG 100 Series Manual

ZyXEL Communications

ZyXEL Communications EMG2926-Q10A Manual de usuario

ZyXEL Communications

ZyXEL Communications NSG50 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZyXEL ZyWALL 2WE Manual de usuario

ZyXEL Communications

ZyXEL Communications EX5510-B0 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL 20W - Manual de usuario

ZyXEL Communications

ZyXEL Communications P-660HW-T - V2 Manual de usuario

ZyXEL Communications

ZyXEL Communications USG1900 Manual de usuario

ZyXEL Communications

ZyXEL Communications P-660HNT1 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZyAIR G-4100 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZyXEL ZyAIR B-220 Manual de usuario

ZyXEL Communications

ZyXEL Communications P-2302R-P1C Manual de usuario

ZyXEL Communications

ZyXEL Communications P-660H Series Manual de usuario

ZyXEL Communications

ZyXEL Communications P-870HW-I1 Manual de usuario

ZyXEL Communications

ZyXEL Communications AMG1001-T Series Manual de usuario

ZyXEL Communications

ZyXEL Communications P-660HW-Tx v3 Series Manual

ZyXEL Communications

ZyXEL Communications EMG3425-Q10A Manual de usuario

ZyXEL Communications

ZyXEL Communications VSG1432 Manual de usuario

ZyXEL Communications

ZyXEL Communications P-660HWP-D1 Manual de usuario

ZyXEL Communications

ZyXEL Communications P-793H 601156 Manual de usuario

ZyXEL Communications

ZyXEL Communications Internet Security Gateway ZyWALL 100 Manual

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario

RTA

RTA 460MCBC-N2E Hoja de especificaciones
