ZyXEL Communications VMG3625-T20A Manual de usuario

Quick Start Guide

VMG3625-T20A

Dual-Band Wireless AC/N Combo

WAN Gigabit Gateway with USB

ENGLISH

Connect the power cable and press the

power button.

Connect a computer using the yellow

Ethernet cable.

Connect a broadband modem or router

(3-a) using an Ethernet cable. OR

Connect a DSL splitter (3-b) or directly to

the telephone wall outlet using the gray

telephone cable.

Connect a 3G dongle (optional).

INTERNET LED

ON - The Internet connection is ready. Go

to Wireless Setup.

OFF - The Internet connection is not ready.

Go to Internet Setup.

EN 1

EN 3

EN 5

Hardware Connections

Internet Setup

Check the LEDs

1/2

VMG3625-T20A

SYY41WWXXXXXX

XXXXXXXXXXXX

MACAddress

SerialNumber

SSID(2.4G)

SSID(5G)

WirelessKey

Zyxel_XXXX

Zyxel_XXXX_5G

XXXXXXXXXX

DefaultIP Address:192.168.1.1

PowerRating: 12V 2A

PowerConsumption: 24 Wattmax.

ZyxelCommunications A/S

Generatorvej8D,2860 S borg,Denmark.

VMG3625-T20A

User Name

Password 1234

admin

User Name : admin

Password : 1234

(default)

http://192.168.1.1

6-1 6-2

VMG3625

-T20A

Open a web browser and go to

http://192.168.1.1. Enter the default User Name

(admin) and Password (1234), and then click

A wizard runs. Follow the wizard prompts.

6-1

6-2

Wizard (Quick Start)

LAN

POWER ON

3-a

3-b

POWER

INTERNET ON

INTERNET OFF

WAN DSL

Quick Start Guide

ENGLISH

Drill two holes at the distance of 104.9mm

apart. Insert screw anchors and screws

(not provided) into the holes.

Attach the bracket to your VMG3625-T20A

with the bracket holes facing down.

Hang it on the screws.

Wireless Setup

WPS

Press the WPS button until the WiFi 2.4G

and 5G LEDs light up in orange.

Press the WPS button on the client.If the

WPS method fails,perform the No WPS

method.

No WPS

The SSID and Wireless key are on the

device sticker.

Find the device with this SSID. Enter the

Wireless key to connect.

Connect the stand with the bracket holes

facing up.

Place the device vertically on a smooth

level surface.

WiFi 2.4G ON

WiFi 5G ON

/ WPS

Wireless Setup

/ NO WPS

More than 5 seconds.

within

minutes

SSID (2.4GHz)

SSID (5-GHz)

Wireless key

Zyxel_xxxx

Zyxel_xxxx_5G

XXXXXXXXXX

Desktop Installation

x2x2

SSID (2.4GHz)

Wireless key

XXXXXXXXXX

Zyxel_xxxx

Wall Mounting

104.9mm

See the User’s Guide at www.zyxel.com for more information, including customer support and safety warnings.

2/2

VMG3625-T20A

Dual-Band Wireless AC/N Combo

WAN Gigabit Gateway with USB

WPS ON
