ZTE V6700
User Manual
-1-
Using your phone
Thanks for choosing the ZTE V6700. It’s a CDMA2000 1X EVDO
digital mobile phone, which we’ll simply call ‘phone’ from now on.
Under Android operating system, the phone supports 3G
high-speed Internet access, which brings you brand new
experiences.
And don’t worry if the pictures we use to demonstrate your phone’s
functions look a little different from what you see on its screen. It’s
the functions they show that matter.
-2-
Starting Up
How to insert the UIM card
1. Switch off your phone and disconnect any
external power.
2. Remove the back cover and then the battery.
3. Hold your UIM on the cut corner, and slide it
face down into the card holder.
4. Insert the battery.
5. Replace the back cover.
Inserting and removing a memory card
Note: Removing or inserting a memory card when your phone is
turned on could not only damage it and your phone, but also
destroy any data saved on the card.
1. Remove the back cover and insert the
memory card at the side of the phone.
2. Push tightly until the card is installed in the
right position and replace the back cover.
3. Before you take out the card, please open the
back cover and press the card inward to unlock.
-3-
Battery
The lithium ion battery of the mobile phone can be immediately
used after unpacking. A new battery performs best after performing
a full charge/discharge 3 times.
Installing the battery
1. Open the battery cover on the back of your phone.
2. Align the battery's contact points with those of the phone and
gently press the battery down into place.
3. Replace the battery cover clicking it back into position.
Removing the battery
1. Switch off your phone.
2. Open the battery cover.
3. Lift the battery up and out of your phone.
-4-
How to charge the battery
The rechargeable Li-ion battery that comes with your phone is
ready to use, but is not charged. That’s easy to do. We’ll show you
how below.
1. Connect the charger to your phone, and
plug it into an 110V/220V socket.
2. The battery indicator in the corner of the
screen will scroll to show you it’s charging.
3. When fully charged, the battery indicator
will stop scrolling. Disconnect the charger
from your mobile, and unplug.
Powering On/Off
Powering On
Press the End/Power key until the power-on icon appears.
Note:You may need to enter the Personal Identification Number
(PIN) or Draw unlock pattern if you have set a PIN or unlock
pattern.
Powering Off
Long press the End/Power key to display the menu Phone
options and select Power off.
-5-
Search Key
Touch screen
Menu key
Back key
Home key
Earpiece
Speaker
Camera
Power key
Headset jack
Volume keys USB port
Flashbulb
My Phone
-6-
Onscreen icons
Icons Descriptions Icons Descriptions
Signal strength No signal
Full battery Charging
Low battery In a call
Connected on 3G You have an unread
message.
Speakerphone on You have an unheard
voicemail.
Call forwarding on You have an unread
E-mail.
No memory card You have an unread
G-mail.
Call held Connected to a PC
Vibration mode Music playing
Silence mode New calendar reminder
Flight mode Alarm clock on
Missed calls Wi-Fi function on
Bluetooth®function is
on Receiving location data
from GPS
Roaming
-7-
Basic Operation
Screen control
You can control your phone through a series of operations on the
screen.
Press: you can press the items on the screen to select, open
the applications, or use the keyboard to input characters.
Slide: you can scroll up/down the page or scroll the page
left/right by sliding vertically or horizontally on the screen.
Long press: you can long press some items to get the item’s
available menu.
Drag: you can drag some items on the screen to realize some
operations.
Switch between landscape mode and portrait mode: you
can switch to the landscape mode by rotating your phone.
The landscape mode is only valid under some interfaces,
such as text input interface, message viewing interface, etc.
Open and close the Launcher
On the home screen, press the icon to open the Launcher.
You can slide the Launcher left or right to view more applications.
After opening the Launcher, press an icon to enter the
corresponding application. Press the Back key to return to the
previous screen. Press the Home key to return to the home
screen.
-8-
Switch to a recently used application
Press and hold the Home key. A window opens with icons of
applications that you’ve used recently.
Press an icon to open its application.
Home screen
Status bar
Screen Indicator
Notification bar
Display area
Icons
Tap the icon to open the
relevant application.
Messaging
Launcher icon
Tap the icon to view all installed
applications on the phone.
Tap and hold the icon to view the
home screen thumbnails.
Phone
-9-
Add icons to the home screen
Long press the empty area on the home screen to pop up the
Add to Home screen menu. Select Shortcuts, Widgets,
Folders, etc.
You can copy icons from the Launcher to the home screen by
long pressing an icon in the Launcher until the icon enlarges and
the phone vibrates.
Move icons on the home screen
1. Long press an icon until the icon enlarges and the phone
vibrates.
2. Drag the icon to your desired position and then release.
Delete icons on the home screen
1. Long press an icon until the icon enlarges and the phone
vibrates.
2. Drag the icon into at the lower part of the screen to
delete.
Change wallpaper
1. In idle mode, press the Menu key and select Wallpaper.
2. Press Gallery / Live wallpapers /Wallpapers to enter the
image library.
3. Select one image and press Set wallpaper.
