M4 Firmware Update Guide
Copyright(C) 2023 ZOOM CORPORATION. All Rights Reserved.
Proper display is not possible on grayscale devices.
Introduction
■Item to prepare
■
Firmware update process
1. Download the firmware update file.
2. Extract the ZIP file.
3. Copy the extracted firmware update file to a microSD card.
4. Update the firmware.
5. Confirm that the firmware has been updated correctly.
Windows or macOS computer
with Internet access
M4
microSD card
Supported recording media
microSDHC: 4 GB – 32 GB
microSDXC: 64 GB – 1 TB
Always format microSD cards on the M4
after purchasing them new or using them with
a different device.
2
Updating the Firmware
This guide explains firmware update to version 1.10 as an example.
1. Download the firmware update file.
Download the ZIP file that contains the firmware update file from the M4 download page.
3
On Windows
2.
Extract the ZIP file
Select the folder that contains the downloaded ZIP file. Click ①“Compressed Folder Tools” and then click ②
“Extract all”. This extracts the ZIP file.
①
②
M4v1.10E.zip
M4Firmwa
reUpdate
GuideE.pdf
M4Firmwa
reVersion
HistoryE.p
df
M4SYSTEM
.BIN
M4v1.10E M4v1.10E
M4v1.10E
4
3.
Copy the firmware update file to a microSD card.
Copy the “M4SYSTEM.BIN” file to a microSD card.
Firmware update file
Copy the firmware update file
to a microSD card.
microSD
M4Firmwa
reUpdate
GuideE.pdf
M4Firmwa
reVersion
HistoryE.p
df
M4SYSTEM
.BIN
M4SYSTEM
.BIN
M4v1.10E M4v1.10E
M4v1.10E
M4SD(F:)
M4SD(F:)
5
On macOS
2.
Extract the ZIP file.
After downloading, open the ①“Downloads” folder which appears at the right end of the Dock by default.
Then, click ②. Downloaded files will be shown.
3.
Copy the firmware update file to a microSD card.
Copy the “M4SYSTEM.BIN” file to a microSD card.
① ②
M4SYSTEM.BIN
M4v1.10E
M4Firmware
Update...eE.pd
f
M4FirmwareVer
sion...oryE.pdf
microSD
Firmware update file
Copy the firmware update file
to a microSD card.
M4SD
M4SYSTEM.BIN
6
The following procedures are the same on both Windows and macOS.
4. Install new batteries in the M4 or connect an AC adapter.
NOTE
The firmware update is not possible if the remaining battery power is low.
5. Insert the microSD card into the M4.
6. Slide toward .
This turns the M4 power on and opens the Home Screen on the display.
7
7. Press .
This opens the Menu Screen on the display.
8. Use and to select “System” and press to confirm.
9. Use and to select “Firmware” and press to confirm.
8
10. Press .
11. Use and to select “Execute” and press to confirm.
12. Slide toward until “Goodbye! See You!” appears on the display.
9
13. Slide toward again.
The update will be executed automatically, and the REC indicator will blink slowly.
After about 1 minute, a completion screen will appear.
NOTE
During the firmware update, do not turn the power off or remove the microSD card.
If the update fails, the REC indicator will blink rapidly. If this happens, turn the power off once and confirm that
the microSD card is loaded correctly. Then, turn the power on and try updating again.
toward .
14.
Slide
This turns the M4 power off.
NOTE
If the firmware update failed, starting the unit might not be possible and the REC indicator might blink. Turn the
power off and repeat steps 1–6.
10
Confirming that the firmware has been updated correctly
Check the firmware versions used by the M4.
1. Press .
This opens the Menu Screen on the display.
to confirm.
2. Use and to select “System” and press
to confirm.
3. Use and to select “Firmware” and press
